Black plate (10,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
3-10 Seats and Restraints
Second Row Seats The second row seats can be folded
for additional cargo space or folded
and tumbled for easy entry and exit
to the third row seat, if equipped.
The seat has either the manual fold
and tumble feature or the automatic
seat release fold and tumble
feature.
Reclining Seatbacks
(Bucket Seats Only) On vehicles with second row bucket
seats, the seatbacks can be
reclined. To recline the seatback:
1. Lift the lever on the outboard
side of the seat.
2. Move the seatback to the
desired position, and then
release the lever to lock the
seatback in place.
3. Push and pull on the seatback
to make sure it is locked. To return the seatback to the upright
position:
1. Lift the lever fully without
applying pressure to the
seatback, and the seatback will
return to the upright position.
{ WARNINGIf either seatback is not locked, it
could move forward in a sudden
stop or crash. That could cause
injury to the person sitting there.
Always push and pull on the
seatbacks to be sure they are
locked.
2. Push and pull on the seatback to
make sure it is locked.

Black plate (12,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
3-12 Seats and Restraints
3. Lift the lever again to release the
rear of the seat from the floor.
The seat will tumble forward. Folding and Tumbling the Seat
from the Third Row Seat
{ WARNINGUsing the third row seating
position while the second row is
folded, or folded and tumbled,
could cause injury in a sudden
stop or crash. Be sure to return
the seat to the passenger seating
position. Push and pull on the
seat to make sure it is locked into
place.
To fold and tumble the seat from the
third row seat, if equipped:
1. Make sure that there is nothing
under, in front of, or on the seat.
Notice: Folding a rear seat with
the safety belts still fastened may
cause damage to the seat or the
safety belts. Always unbuckle the
safety belts and return them to
their normal stowed position
before folding a rear seat. 60/40 Split-Bench Seat Shown,
Bucket Seat Similar
2. Lift the lever, on the bottom rear
of the second row seat on the
inboard side, to release the
seatback. The seatback will fold
forward.
3. Lift the same lever again to
release the rear of the seat from
the floor. The seat will tumble
forward.

Black plate (13,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
Seats and Restraints 3-13Automatic Fold and Tumble
Feature The transmission must be in
P (Park) for this feature to work.
{ WARNINGAutomatically folding and
tumbling the seat when someone
is sitting in the seat, could cause
injury to the person sitting there.
Always make sure there is no one
sitting in the seat before pressing
the automatic seat release button.
Folding and Tumbling the Second
Row Seat from the Third Row Seat
or Outside the Vehicle
{ WARNING
Using the third row seating
position while the second row is
folded, or folded and tumbled,
(Continued) WARNING (Continued) could cause injury in a sudden
stop or crash. Be sure to return
the seat to the passenger seating
position. Push and pull on the
seat to make sure it is locked into
place.
To fold and tumble the seat from the
third row seat, if equipped:
1. Make sure that there is nothing
under, in front of, or on the seat.
Notice: Folding a rear seat with
the safety belts still fastened may
cause damage to the seat or the
safety belts. Always unbuckle the
safety belts and return them to
their normal stowed position
before folding a rear seat. Driver Side Rear Panel Button
Shown
2. Press the automatic seat release
button on the panel behind the
rear doors.
The seatback automatically
folds flat and the seat tumbles
forward. There will be a slight
delay between the folding of the
seatback and the tumbling of
the seat.

Black plate (14,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
3-14 Seats and Restraints Returning the Seat to the
Sitting Position To return the seat to the sitting
position from the tumbled position:
1. Pull the seat down until it latches
to the floor. The seatback cannot
be raised if the seat is not
latched to the floor.
{ WARNINGIf either seatback is not locked, it
could move forward in a sudden
stop or crash. That could cause
injury to the person sitting there.
Always push and pull on the
seatbacks to be sure they are
locked.
2. Lift the seatback and push it
rearward. Push and pull on the
seatback to make sure it is
locked. { WARNINGA safety belt that is improperly
routed, not properly attached,
or twisted will not provide the
protection needed in a crash. The
person wearing the belt could be
seriously injured. After raising the
rear seatback, always check to
be sure that the safety belts are
properly routed and attached, and
are not twisted.
3. For the 60/40 split-bench seat,
make sure the safety belt in the
center seating position is not
caught between the two seats
and is not twisted. Third Row Seats If the vehicle has a third row seat,
the seatback can be folded, and
the entire seat can be tumbled or
removed from the vehicle.
Folding the Seatback To fold the seatback:
1. Open the liftgate to access the
controls for the seat.
2. Remove all items on the seat
cushion.
Notice: Folding a rear seat with
the safety belts still fastened may
cause damage to the seat or the
safety belts. Always unbuckle the
safety belts and return them to
their normal stowed position
before folding a rear seat.

Black plate (15,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
Seats and Restraints 3-15
3. Lift the release lever “ 1, ” on the
bottom rear of the seatback on
the outboard side of the seat,
and the seatback folds forward. Returning the Seatback to the
Upright Position To return the seatback to the upright
position:
1. Open the liftgate to access the
controls for the seat.
2. Raise the seatback to the
upright position.
{ WARNINGIf either seatback is not locked, it
could move forward in a sudden
stop or crash. That could cause
injury to the person sitting there.
Always push and pull on the
seatbacks to be sure they are
locked.
3. Push and pull on the seatback to
make sure it is locked. Tumbling the Third Row Seat To tumble the seat:
1. Open the liftgate to access the
controls for the seat.
2. Make sure the headrests are
completely lowered and there is
nothing under, in front of, or on
the seat.
3. Fold the seatbacks forward
using lever “ 1 ” and the
instructions listed previously
under “ Folding the Seatback. ”
The seat cannot be unlatched
from the floor unless the
seatback is folded.

Black plate (16,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
3-16 Seats and Restraints
4. Unlatch the seat from the floor
by lifting lever “ 2 ” next to the
carrying handle on the rear of
the seat, near the bottom.
5. Lift the rear of the seat up from
the floor.
6. Tilt the seat fully forward to lock
it into place.
7. Push and pull on the seat to
make sure it is locked.
Put the seat in this position only
when necessary for additional cargo
space. Returning the Third Row Seat
from a Tumbled Position To return the seat to the normal
seating position:
1. Open the liftgate to access the
controls for the seat.
2. Make sure there is nothing that
could become trapped under
the seat.
3. Release the seat from the
tumbled position by lifting lever
“ 2 ” next to the carrying handle at
the bottom rear of the seat.
4. Pull the seat down until it latches
to the floor. The seatback cannot
be raised to the upright position
unless the seat is latched to the
floor.
5. Raise the seatback to the
upright position. { WARNINGIf either seatback is not locked, it
could move forward in a sudden
stop or crash. That could cause
injury to the person sitting there.
Always push and pull on the
seatbacks to be sure they are
locked.
6. Push and pull on the seatback to
make sure it is locked.
Removing the Third Row Seat To remove the seat:
1. Open the liftgate to access the
controls for the seat.
2. Fold the seatbacks forward
using lever “ 1 ” and the
instructions listed previously
under “ Folding the Seatback. ”
The seat cannot be unlatched
from the floor unless the
seatback is folded.

Black plate (17,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
Seats and Restraints 3-17
3. Unlatch the seat from the floor
by pulling the handle at the rear
of the seat “ 3 Removal Only ”
toward the rear of the vehicle.
4. Roll the seat out of the vehicle.
There is a track in the floor to
guide the seat wheels out of the
vehicle. Installing the Third Row Seat To install the seat:
1. Open the liftgate to access the
rear of the vehicle.
2. Slide the front outboard seat
wheels into the track on the floor
and roll the seat forward. The
front latches should lock into
place. If the latches do not lock,
try tilting the rear of the seat
upward slightly.
3. Lower the rear of the seat and
push down on the seat to
engage the rear floor latches.
{ WARNING
A seat that is not locked into
place properly can move around
in a collision or sudden stop.
People in the vehicle could be
injured. Be sure to lock the seat
into place properly when
installing it. 4. Push and pull on the seat to
make sure it is locked into place.
The seatback cannot be raised
to the upright position unless the
seat is latched to the floor.
5. Raise the seatback to the
upright position.
{ WARNINGIf either seatback is not locked, it
could move forward in a sudden
stop or crash. That could cause
injury to the person sitting there.
Always push and pull on the
seatbacks to be sure they are
locked.
6. Push and pull on the seatback to
make sure it is locked.

Black plate (22,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
3-22 Seats and Restraints
How to Wear Safety Belts
Properly This section is only for people of
adult size.
Be aware that there are special
things to know about safety belts
and children. And there are different
rules for smaller children and
infants. If a child will be riding in the
vehicle, see Older Children on
page 3 ‑ 51 or Infants and Young
Children on page 3 ‑ 53 . Follow those
rules for everyone's protection.
It is very important for all occupants
to buckle up. Statistics show that
unbelted people are hurt more often
in crashes than those who are
wearing safety belts.
Occupants who are not buckled up
can be thrown out of the vehicle in a
crash. And they can strike others in
the vehicle who are wearing safety
belts. First, before you or your
passenger(s) wear a safety belt,
there is important information you
should know.
Sit up straight and always keep your
feet on the floor in front of you. The
lap part of the belt should be worn
low and snug on the hips, just touching the thighs. In a crash, this
applies force to the strong pelvic
bones and you would be less likely
to slide under the lap belt. If you slid
under it, the belt would apply force
on your abdomen. This could cause
serious or even fatal injuries. The
shoulder belt should go over the
shoulder and across the chest.
These parts of the body are best
able to take belt restraining forces.
The shoulder belt locks if there is a
sudden stop or crash.
