4. Find the jacking location from the diagram aboveand use the corresponding cutouts located in the
plastic molding.
The front location is (A) 8.5 inches (21 cm) from
the rear edge of the front wheel well, and the rear
location (B) is 3.5 inches (8.5 cm) from the front
edge of the rear wheel well.
The notches may also be labeled JACK with an
arrow pointing to the jacking location on the
vehicle.
{WARNING:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack, you
could be badly injured or killed. Never get under a
vehicle when it is supported only by a jack.
{WARNING:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to fit the jack
lift head into the proper location before raising the
vehicle.
Notice: If you position the jack under the rocker
molding and attempt to raise the vehicle, you could
break the molding and/or cause other damage to
your vehicle. Always position the jack so that when
the jack head is raised, it will fit firmly in the notch
located inboard from the rocker molding.
5. Turn the jack handle counterclockwise to lower the jack lift head until the jack fits under the vehicle.
