2011 Alfa Romeo 159 Owner handbook (in English)

295
SOUND SYSTEM
ADVICE
Road safety
You are advised to learn how to use the var-
ious radio functions (e.g.: storing stations)
before starting to drive.
Reception conditions
Reception conditions change constantly
when driving. Reception may be disturbed
by the presence of mountains, buildings or
bridges particularly when far away from the
station being listened to.
IMPORTANT When receiving traffic informa-
tion, the volume may be higher than nor-
mal.
I I
N N
T T
R R
O O
D D
U U
C C
T T
I I
O O
N N
The car sound system, fitted with CD player
(radio with Compact Disc player) or MP3 CD
player (radio with MP3 CD player) has been
designed in accordance with the special fea-
tures of the passenger compartment, with a
personalised design that blends with the style
of the dashboard. The sound system cannot
be adapted to other vehicles and for this rea-
son it cannot be removed.
The radio is installed in a user-friendly posi-
tion for the driver and passenger and the
graphics on the front panel make location of
the controls quick, facilitating use.
The CD Changer is available at Lineaccessori
Alfa Romeo.
In the following pages you will find the in-
structions for use, which you are advised to
read through carefully. The instructions also
contain the procedure for controlling the CD
Changer (if provided) through the radio. For
the instructions for use of the CD Changer
refer to the specific manual.
Too high a volume when
driving can put the driver’s
life at risk and that of other peo-
ple. Therefore the volume should
always be adjusted in such a way
that it is always possible to hear
the noises of the surrounding en-
vironment (e.g.: horns, ambulance,
police sirens, etc.).
WARNING
Care and maintenance
The radio structure ensures long operation
with no need for particular maintenance.
In the event of a fault, contact Alfa Romeo
Authorized Services.
To clean the front panel only use a soft, an-
tistatic cloth. Cleaning and polishing prod-
ucts might spoil the surface.
293-318 Alfa 159 GB 8-04-2009 10:56 Pagina 295

296
SOUND SYSTEM
❒Never use chemical products for cleaning
(e.g.: spray cans, antistatic or thinners) as
they might damage the surface of Com-
pact Discs;
❒After use, put Compact Discs back in their
container, to avoid marks or scratches that
may cause skipping when playing;
❒Do not expose Compact Discs to direct sun-
light, high temperatures or damp for pro-
longed lengths of time to prevent them
from bending;
❒Do not stick labels or write on the record-
ed surface of Compact Discs.
To remove a Compact Disc from its container,
press the centre and raise the disc careful-
ly, holding it by the outer circumference.Always hold Compact Discs by the outer cir-
cumference. Never touch the surface.
To remove fingerprints and dust, use a soft
cloth starting from the centre of the Com-
pact Disc outwards.
Do not use highly scratched, cracked, or dis-
torted discs, etc. The use of these discs will
involve malfunctioning or damage to the
player.
For optimal playing use original CDs only.
Regular operation is not guaranteed if using
R/RW CDs not properly mastered and/or
CDs with max. capacity higher than 650
MB.
IMPORTANT Do not use the protective sheets
for CD in commerce or discs with stabilisers,
etc. as they might get stuck in the internal
mechanism and damage the disc. Compact Disc
Remember that dirt, marks or distortion on
Compact Disc can cause skipping. To obtain
optimum playing conditions we give the fol-
lowing advice:
❒Only use Compact Discs which have the
following brand:
❒Carefully clean all Compact Discs of fin-
gerprints and dust using a soft cloth. Sup-
port Compact Discs from the outer cir-
cumference and clean from the centre out-
wards;
293-318 Alfa 159 GB 8-04-2009 10:56 Pagina 296

297
SOUND SYSTEM
IMPORTANT The CD player can read most of
the compression systems currently on sale
(e.g.: LAME, BLADE, XING, FRAUNHOFER)
however, due to the evolution of these sys-
tems, reading of all compression formats
is not guaranteed.
IMPORTANT When loading a multi-session
CD, only the first session will be played. IMPORTANT Should copy-protected CDs be
used, then, few seconds may be required
for playing them. Moreover, due to the pro-
liferation of always new and different pro-
tection methods, it is not guaranteed that
the CD player can play whatever protected
disc. Copy protection is often indicated on
the CD cover in small letters or hard to read
characters. Usually it is indicated by writings
like: “COPY CONTROL”, “COPY PROTECT-
ED”, “THIS CD CANNOT BE PLAYED ON A
PC/MAC”, or it is identified by symbols like:
TECHNICAL DATA
Radio
Maximum power: 4x40W
Speakers
The system includes:
– 2 tweeters with 30 W max. power,
set at dashboard ends;
– 2 mid-woofers with a diameter of 165
mm and 30W max. power, set in front
doors;
– 2 tweeters with 30 W max. power,
set in rear doors;
– 2 mid-woofers with a diameter of 165
mm and 30W max. power, set in rear
doors.
Protected discs (and their cover) very often
are not marked with the audio CD identifica-
tion symbol:
293-318 Alfa 159 GB 8-04-2009 10:56 Pagina 297

298
SOUND SYSTEM
HI-FI BOSE SYSTEM
(for versions/markets,
where provided)
The HI-FI BOSE system installed on your car
has been accurately designed to offer out-
standing sound quality and reproduce the
musical realism of a live concert, for all the
seats in the passenger compartment.
The system’s features include outstanding
faithful reproduction of crystalline treble
tones and full, rich basses which among oth-
er things, make the Loudness function su-
perfluous. In addition, the complete range
of the sounds is reproduced in the whole pas-
senger compartment enveloping the occu-
pants with the natural spatial sensation that
is felt when listening to live music.
The components adopted are patented and
are the result of the most sophisticated tech-
nology, but at the same time they are easy
and intuitive to use, so that even less expert
people can use the system.Technical data
The system includes:
– 2 tweeters with 50 W max. power,
set at dashboard ends;
– 2 mid-woofers with a diameter of 165
mm and 90 W max. power, set in front
doors;
– 2 rear tweeters with 50 W max.
power, set in rear doors;
– 2 mid-woofers with a diameter of 165
mm and 90 W max. power, set in rear
doors;– 1 mid-tweeter (Centerfill) with a
diameter of 80 mm and 50 W max.
power, set in the middle of the dashboard;
– 1 Sub-woofer (Saloon versions), with
a diameter of 250 mm and 200 W max.
power, set on the rear window parcel
shelf;
– 1 Bass-box reflex (Sportwagon ver-
sions) 130 mm diameter, 200 W max.
power, set in the boot;
– Power amplifier with 6 independent
channels, set on the rear window parcel
shelf and controlling all installed speakers.
293-318 Alfa 159 GB 8-04-2009 10:56 Pagina 298

299
SOUND SYSTEM
Q Q
U U
I I
C C
K K

G G
U U
I I
D D
E EAUDIO SECTION
❒Loudness function (excluding versions
with Bose HI-FI system)
❒Standard equalization (excluding versions
with Bose HI-FI system)
❒Personal equalization (excluding versions
with Bose HI-FI system)
❒Automatic volume changing according to
car speed (SPEED VOLUME)
❒MUTE function
RADIO SECTION
❒Traffic information reception (TA)
❒Automatic storage of 6 stations in the
dedicated FM band - FMT (AS – Auto-
store)
CD / MP3 CD SECTION
❒Play / Pause
❒Previous / next track selection
❒FF / FR
❒Previous / next directory selection
Button
ON/OFF
Mode
Brief knob pressing
Long knob pressing
Knob rotation LH/RH
A0E0531m
GENERAL FUNCTIONS
On
Off
Volume adjustment
293-318 Alfa 159 GB 8-04-2009 10:56 Pagina 299

300
SOUND SYSTEM
Button
FM AS
AM
CD
MUTE
AUDIO
MENU
Button
÷N
˜
O
1 2 3 4 5 6
Button
ı
÷˜
N
O
GENERAL FUNCTIONS
Radio band selection FM1, FM2, FM Autostore
Radio band selection MW, LW
Audio source selection (radio/CD/CD-Changer)
Volume on/off (MUTE / PAUSE)
Audio settings: bass (BASS), treble (TREBLE),
right/left sound adjustment (BALANCE),
front/rear sound adjustment (FADER)
Advanced functions adjustmentMode
Brief cyclic button pressing
Brief cyclic button pressing
Brief cyclic button pressing
Brief button pressing
Menu activation: brief button pressing
Adjustment selection: press button
NorOValue adjustment: press button ÷or˜
Menu activation: brief button pressing
Adjustment selection: press button NorOValue adjustment: press button ÷or˜
RADIO FUNCTIONS
Radio station tuning:
•Automatic tuning
•Manual tuning
Current radio station storage
Stored station recallMode
Automatic tuning: press button ÷or˜(long pressing for fast forward)
Manual tuning: press button NorO(long pressing for fast forward)
Long button pressing
respectively for preset/memories from 1 to 6
Brief button pressing
respectively for preset/memories from 1 to 6
CD FUNCTIONS
CD ejection
Previous/next track playback
CD track fast forward/backward
Previous/next CD playback (for CD Changer)
Previous/next directory playback (for MP3 CD)
Mode
Brief button pressing
Brief pressing on buttons
÷or˜
Long pressing on buttons ÷or˜
Brief pressing on buttons NorO
Brief pressing on buttons NorO
293-318 Alfa 159 GB 8-04-2009 10:56 Pagina 300

301
SOUND SYSTEM
STEERING WHEEL CONTROLS
(where provided)
Button
^
+
–
SRC
N
O
÷
˜
FUNCTION
AudioMute on/off
(with sound system on)
Volume up
Volume down
Radio frequency
(FM1, FM2, FMT, MW, LW) and audio source
(Radio - CD - MP3 - CD Changer) selection button
Radio: recall preset stations (1 to 6)
MP3: select next directory
CD Changer: select next CD in the CD Changer
Radio: recall preset stations (6 to 1)
MP3: select previous directory
CD Changer: select previous CD in the CD Changer
Radio: automatic tuning to previous station
CD player: select previous track
CD Changer: select previous track
Radio: automatic tuning to next station
CD player: select next track
CD Changer: select next trackMode
Brief button pressing
Press button
Press button
Press button
Press button
Press button
Press button
Press button
A0E0532m
293-318 Alfa 159 GB 8-04-2009 10:56 Pagina 301

302
SOUND SYSTEM
On multimedia CDs in ad-
dition to sound tracks also
data tracks are recorded.
Playing one of these CDs may
cause rustling and such a volume
as to compromise road safety, as
well as causing damage to the fi-
nal stages and speakers.
MP3 CD section
❒MP3-Info function (ID3-TAG);
❒Directory selection (previous/next);
❒Track selection (forward/backward);
❒Fast forward/backward;
❒MP3 CD data display: directory name,
ID3-TAG info, time elapsed from start of
track, file name);
❒Playing audio CDs and R/RW CDs.
Audio section
❒Mute/Pause function;
❒Soft Mute function;
❒Loudness function (excluding versions
with Bose HI-FI system);
❒7 band graphic equalizer (excluding ver-
sions with Bose HI-FI system);
❒Separate bass/treble adjustment;
❒Right/left channel balancing. Compact Disc section
❒Direct disc selection;
❒Track selection (forward/backward);
❒Fast forward/backward;
❒CD Display function: displaying CD
name/time elapsed from start of track;
❒Playing audio CDs and R/RW CDs.
GENERAL
The set possesses the following functions:
Radio section
❒PLL tuning with FM/AM/MW/LW fre-
quency bands;
❒RDS (Radio Data System) with TA (traf-
fic announcements) - TP (Program Type)
- EON (Enhanced Other Network) - REG
(Regional programmes);
❒AF: alternative frequency search selection
in RDS mode;
❒emergency alarm presetting;
❒automatic/manual station tuning;
❒FM Multipath detector;
❒manual storage of 36 stations: 18 in the
FM band (6 in FM1, 6 in FM2, 6 in
FMT), 6 in the MW band and 6 in the LW
band;
❒automatic storage (AUTOSTORE function)
of 6 stations in FM band;
❒SPEED VOLUME function (excluding ver-
sions with Bose HI-FI system): automat-
ic volume adjustment with car speed;
❒automatic Stereo/Mono switching.
293-318 Alfa 159 GB 8-04-2009 10:56 Pagina 302
