2011 Acura MDX srs

Your Vehicle at a Glance(main controls)
....................................................................................................................
3
Driver and Passenger Safety (seat belts, SRS, and child protection)
...........................................................................
5
Instruments and Controls (indicators, gauges, multi-information display, dashboard, and steering column)
...........
63
Features (
climate control, audio, rear entertainment, steering wheel, security, cruise control, and other convenience items
)..
179
Before Driving (fuel, vehicle break-in, and cargo loading)
.......................................................................................
417
Driving (engine and transmission operation)
...........................................................................................................
433
Maintenance (minder, fluid checking, minor services, and vehicle storage)
...........................................................
499
Taking Care of the Unexpected (flat tire, Jump starting, overheating, and fuses)
...................................................
543
Technical Information (vehicle specifications, tires, and emissions controls)
........................................................
569
Warranty and Client Relations (U.S. and Canada only) (warranty and contact information)
...............................
585
Index
..............................................................................................................................................................................
I
INDEX
Service Information Summary (fluid capacities and tire pressures)
...............................................................
last page
Contents
1
10/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

This section gives you important
information about how to protect
yourself and your passengers. It shows
you how to use seat belts. It explains
how your airbags work. And it tells you
how to properly restrain infants and
children in your vehicle.
Important Safety Precautions
..............
6
Your Vehicle's Safety Features
............
8
Seat Belts
.....................................
9
Airbags
.......................................
10
Protecting Adults and Teens
.............
12
1. Close and Lock the Doors
..........
12
2. Adjust the Front Seats
...............
14
3. Adjust the Seat-Backs
................
15
4. Adjust the Head Restraints
.........
15
5. Fasten and Position the Seat Belts
...................................
16
6. Maintain a Proper Sitting Position
...............................
18
Advice for Pregnant Women
..........
19
Additional Safety Precautions
........
20
Additional Information About Your Seat Belts
...............................
21
Seat Belt System Components
.......
21 Lap/Shoulder Belt
........................
22
Automatic Seat Belt Tensioners
.....
23
Seat Belt e-pretensioners
...............
24
Seat Belt Maintenance
..................
25
Additional Information About Your
Airbags
...................................
26
Airbag System Components
..........
26
How Your Front Airbags Work
......
29
How Your Side Airbags Work
........
32
How Your Side Curtain Airbags Work
......................................
34
How the SRS Indicator Works
.......
35
How the Side Airbag Off Indicator Works
.....................................
35
How the Passenger Airbag Off Indicator Works
.......................
36
Airbag Service
.............................
37
Additional Safety Precautions
........
38
Protecting Children －General
Guidelines
..............................
39
All Children Must Be Restrained
...............................
39
All Children Should Sit in a Back Seat
........................................
40
The Passenger's Front Airbag Can Pose Serious Risks
...................
40 If You Must Drive with Several
Children
..................................
42
If a Child Requires Close Attention
.................................
42
Additional Safety Precautions
........
43
Protecting Infants and Small Children
.................................
44
Protecting Infants
.........................
44
Protecting Small Children
.............
45
Selecting a Child Seat
......................
47
Installing a Child Seat
......................
48
Installing a Child Seat with LATCH
...................................
49
Installing a Child Seat with a Lap/
Shoulder Belt
...........................
52
Installing a Child Seat with a Tether
.....................................
53
Protecting Larger Children
...............
56
Checking Seat Belt Fit
..................
56
Using a Booster Seat
....................
57
When Can a Larger Child Sit in Front
.......................................
58
Additional Safety Precautions
........
59
Carbon Monoxide Hazard
................
60
Safety Labels
..................................
61
Driver and Passenger Safety
5
Driver and Passenger Safety
10/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

AirbagsYour vehicle has a supplemental
restraint system (SRS) with front
airbags to help protect the heads and
chests of the driver and a front seat
passenger during a moderate to
severe frontal collision (see page 29
for more information on how your
front airbags work).
Your vehicle also has side airbags to
help protect the upper torso of the
driver or a front seat passenger
during a moderate to severe side
impact (see page 32 for more
information on how your side airbags
work).
In addition, your vehicle has side
curtain airbags to help protect the
heads of the driver, front passenger,
and passengers in the outer rear
seating positions during a moderate
to severe side impact or rollover (see
page 34 for more information on how
your side curtain airbags work).
Your Vehicle's Safety Features1010/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

Additional Safety Precautions●
Never let passengers ride in thecargo area or on top of a folded-
down back seat.
If they do, they
could be very seriously injured in a
crash.
●
Passengers should not stand up or change seats while the vehicle is
moving.
A passenger who is not
wearing a seat belt during a crash
or emergency stop can be thrown
against the inside of the vehicle,
against other occupants, or out of
the vehicle.
●
Two people should never use the
same seat belt.
If they do, they
could be very seriously injured in a
crash.
●
Do not put any accessories on seat
belts.
Devices intended to improve
occupant comfort or reposition the
shoulder part of a seat belt can
reduce the protective capability of
the belt and increase the chance of
serious injury in a crash.
●
Do not place hard or sharp objects between yourself and a front
airbag.
Carrying hard or sharp
objects on your lap, or driving with
a pipe or other sharp object in your
mouth, can result in injuries if your
front airbag inflates.
●
Keep your hands and arms away
from the airbag covers.
If your
hands or arms are close to an
airbag cover, they could be injured
if the airbag inflates.
●
Do not attach or place objects on
the front airbag covers.
Objects on
the covers marked ‘‘SRS AIRBAG ’’
could interfere with the proper
operation of the airbags or be
propelled inside the vehicle and
hurt someone if the airbags inflate.
●
Do not attach hard objects on or
near a door.
If a side airbag or a
side curtain airbag inflates, a cup
holder or other hard object
attached on or near the door could
be propelled inside the vehicle and
hurt someone.
●
Do not cover or replace front seat- back covers without consulting
your dealer.
Improperly replacing
or covering front seat-back covers
can prevent your side airbags from
inflating during a side impact.
Protecting Adults and Teens2010/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

The lap/shoulder belts in the center
seat of the second row and both of
the third row seats are equipped with
a detachable anchor that has two
parts: a small latch plate and a
buckle.
The detachable seat belt should
normally be latched whenever the
seat-backs are in an upright position.
For more information about the
detachable seat belt, see page 154.Automatic Seat Belt Tensioners
For added protection, the front seat
belts are equipped with automatic
seat belt tensioners. When activated,
the tensioners immediately tighten
the belts to help hold the driver and a
front passenger in position.
The tensioners can be activated
during a collision in which the front
airbags
do not deploy.
In this case, the
airbags would not be needed, but the
extra tension in the seat belt could be
helpful.
If the tensioner is activated, the SRS
indicator comes on and the tensioner
must be replaced.
DETACHABLE ANCHOR
CONTINUED
Additional Information About Your Seat Belts
23
Driver and Passenger Safety
10/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

Airbag System Componentsꭧ: On models with CMBS(5) Side Airbags
(6) Driver's Seat Position Sensor
(7) Front Passenger's Weight Sensors
(8) Passenger Airbag Off Indicator
(9) Occupant Position Detection System
(OPDS) Sensors
(10) Front Passenger's Weight Sensors/OPDS
Sensors Control Unit
(11) SRS Indicator
(1) (11)
(8)
(6) (2)
(3)
(5)
(10)
(9)
(7)
(4)
(5)
(4)
(1) Driver's Front Airbag
(2) Passenger's Front Airbag
(3) Control Unit
(4) Front Seat Belt Tensioners/Seat Belte-pretensioners
ꭧ
(12) e-pretensioner Control Unit
ꭧ
(13) Front Impact Sensors
(14) Side Curtain Airbags
(15) Side Impact Sensors (First)
(16) Side Impact Sensors (Second)
(17) Safing Sensor
(13) (13)
(14)
(15) (16) (16)
(17)
(12)
(14)
Additional Information About Your Airbags2610/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

Your Airbag System (SRS) includes:●
Two SRS (Supplemental Restraint
System) front airbags. The driver's
airbag is stored in the center of the
steering wheel; the front
passenger's airbag is stored in the
dashboard. Both are marked‘‘SRS
AIRBAG ’’(see page 29).
●
Two side airbags, one for the
driver and one for a front
passenger. The airbags are stored
in the outer edges of the seat-
backs. Both are marked ‘‘SIDE
AIRBAG ’’(see page 32).
●
Two side curtain airbags, one for
each side of the vehicle. The
airbags are stored in the ceiling
above the side windows. The front
and rear pillars are marked ‘‘SIDE
CURTAIN AIRBAG ’’(see page 34).
●
On models with CMBS, front seat
belt e-pretensioners (see page 24).
●
Automatic front seat belt
tensioners (see page 23).
●
Sensors that can detect a moderate
to severe front impact, side impact,
or if your vehicle is about to
rollover.
●
Sensors that can detect whether a
child is in the passenger's side
airbag path and signal the control
unit to turn the airbag off (see
page 33).
●
Sensors that can detect whether
the driver's seat belt and the front
passenger's seat belt are latched or
unlatched (see page 21).
●
A driver's seat position sensor that
monitors the distance of the seat
from the front airbag. If the seat is
too far forward, the airbag will
inflate with less force (see page
30).
CONTINUED
Additional Information About Your Airbags
27
Driver and Passenger Safety
10/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

The total time for inflation and
deflation is one-tenth of a second, so
fast that most occupants are not
aware that the airbags deployed until
they see them lying in their laps.
After a crash, you may see what
looks like smoke. This is actually
powder from the airbag's surface.
Although the powder is not harmful,
people with respiratory problems
may experience some temporary
discomfort. If this occurs, get out of
the vehicle as soon as it is safe to do
so.
Dual-Stage, Multiple-Threshold FrontAirbags (SRS)Your vehicle is equipped with dual-
stage, multiple-threshold front
airbags (SRS). During a frontal crash
severe enough to cause one or both
front airbags to deploy, the airbags
can inflate at different rates,
depending on the severity of the
crash, whether or not the seat belts
are latched, and/or other factors.
Front airbags are designed to
supplement the seat belts to help
reduce the likelihood of head and
chest injuries in frontal crashes.
Advanced AirbagsYour front airbags are also advanced
airbags. The main purpose of this
feature is to help prevent airbag-
caused injuries to short drivers and
children or small statured adults who
ride in front.
For both advanced airbags to work
properly:●
Occupants must sit upright and
wear their seat belts properly.
●
Do not spill any liquids on or
under the seats, cover the sensors,
or put any objects or metal items
under the front seats.
●
Objects placed or pushed under
the front passenger's seat may
cause the sensor to malfunction,
increasing the risk of injury in a
crash.
Failure to follow these instructions
could damage the sensors or prevent
them from working properly.
Additional Information About Your Airbags3010/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu
