001001002002003003004004 COMFORT ACCESS MONITORINGDRIVING
Instrument panel
29 Indicator and warning lamps
38 Gauges and indicators
42 Adjustment buttons
43 Clock
44Tr i p c o m p u ter
48Electronic key - remote control
56 Boot
57 Alarm
59 Electric windows
61 Cockpit glass roof
63 Fuel tank
64 Misfuel prevention (Diesel)
68 Front seats
73 Rear seats
76Mirrors
77 Steering wheel adjustment
78 Interior fi ttings
82Boot fi ttings
83Tr i a ngle (stowing)
84Heating and Ventilation
86 Dual-zone digital air conditioning
90 Rear screen demist - defrost
94Starting-switching off the engine
97Electric parking brake
105 Hill start assist
106 Manual gearbox
107 Gear effi ciency indicator
108Automatic gearbox
112 6-speed electronic gearboxsystem
116 Stop & Start
119Lane departure warning system
120 Head-up display
123 Speed limiter
125 Cruise control
127 Parking sensors
129Reversing camera

Familiarisation

Automatic headlamp dipping

This system automatically changes between
dipped and main beam, depending on the
driving conditions, using a camera located in
the interior rear view mirror.
137

Front and rear parking sensors
This systems warns you of the presence of obstacles located in front of or behind thevehicle during parking manoeuvres.
12
7

Temporary puncture repair kit
This kit is a complete system consisting of a compressor and a sealant car tridge, to allow
the temporary repair of a tyre.
18
0
Exterior
Reversing camera

This system, available only with satellite
navigation, is activated automatically onengaging reverse gear and provides an imagein the colour screen.
129

14 . Controls for electric windows/electric child lock/central locking.
15. eMyWay controls.
16.Gear lever.
17. Heating/air conditioning controls.
18
. Audio system.
19.Hazard warning lamps.
20.Multifunction screen.21. Central adjustable air vents. 22.Clock.
23.Star ting with the STA R T/STOP button.
24.Electronic key reader.
25. Wiper/screenwash/trip computer stalk.
26. Audio equipment steering wheel controls.

Instruments and controls
1.
Bonnet release lever.2.
Headlamp height adjustment. 3.
Side adjustable air vents.4.
Front door window demisting/defrosting
vents.
5. Quarter light demisting windows.
6.Head-up display.7. Windscreen demisting/defrosting vent.8.Passenger's airbag. 9.
Glove box/Passenger's airbag deactivationinside.10.12 V accessory socket. 11.
Rear electric window controls.12.Central armrest with storage.
USB por t /auxiliary socket.13.Electric parking brake.
27. Driver's airbag.
Horn. 28. Cruise control/speed limiter controls.29.
Switch panel (see previous page).30.
Door mirror adjustment.
31.Lighting and direction indicator stalk32.
Instrument panel. 33.
Seat belt and airbag warning lamps. 34.Courtesy lamp. 35.Head-up display controls. 36.Controls for glass roof panel blind.37.CITROËNLocalised Emergency Call -
CITROËNLocalised Assistance Call(depending on country of sale).

17Familiarisation
Sitting comfortably


Door mirrors

Adjustment
1.
Selection of the left or right mirror.2.Adjusting the position of the mirror glass. 3.De-selection of the mirror.
4.
Folding the mirror.
7
6
Rear view mirror
77
1.Automatic detection of day/night mode.2. Rear view mirror adjustment.


Front seat belts
170
1.
Fastening.2.Adjusting for height.

Operation indicator lamps
If one of the following indicator lamps comes on in the instrument panel and/or instrument panel screen, this confirms that the corresponding system has come into operation.

Warning/indicator lampStateCauseAction/Observations




Left-handdirection indicatorflashing with buzzer. The lighting stalk is pushed down.




Right-handdirection indicatorflashing with buzzer. The lighting stalk is pushed up.





Sidelampsfixed.The lighting stalk is in the
"Sidelamps" position.



Dipped beamheadlampsfixed.The lighting stalk is in the "Dippedbeam headlamps" position.




Main beam headlampsfixed.The lighting stalk is pulled towardsyou. Pull the stalk to return to dipped beam headlamps.



Front foglampsfixed.The front foglamps are switched on. Turn the ring on the stalk rear wards twice to switch off
the front foglamps.

For more information on the lighting controls, refer to the "Visibility" section.




Automatic headlamp dipping
fixed.The lighting stalk has been pulled
towards you and the button (to the right of the steering wheel) has beenpressed.
Its warning lamp is on. The camera
, located in the interior rear view mirror,authorises or not switching between main and dipped beam, depending on the exterior lighting and thedriving conditions.
Pull the lighting stalk to return to dipped beam.

Electronic key
remote control
Unlocking the vehicle
Complete unlocking
Selective unlockin
g Unlocking the boot
System which permits central unlocking or
locking of the vehicle using the lock or from adistance. It is also used to locate and start thevehicle, as well as providing protection against
theft.
This settin
g is done in the configuration menu.
Complete unlocking is activated bydefault.


Unlocking is confirmed by rapid flashing of the direction indicators for around two seconds.
At the same time, depending onversion, the door mirrors unfold.

Locking the vehicle


Locking is confirmed by fixed lighting of the direction indicators for approximately two seconds.
The door mirrors fold at the same time.
)To u n l o c k o n ly the driver's door,press the open padlock once.)Press the closed padlock to lock
the vehicle completely. Hold the button down until the
windows close completely.

)
Press this button until you hear
th
e boot unlock. The vehicle is completely unlocked.

Be aware of children when operatingthe windows.
)
Press the open padlock to unlock
the vehicle.
) To unlock the other doors and the boot,
press the open padlock again.

Access
Unlocking the vehicle




















"Keyless Entry and Starting" system


System that allows the opening, closingand star ting of the vehicle while keeping theelectronic key on your person.
It can also be used as a remote control; see the"Remote control" section.
Complete unlocking
)
With the electronic key on your personand in the defined zone A
, pass your hand behind the door handle to unlock thevehicle, then pull on the handle to open the door.
Yo u r p a s s e ngers can also open their doors,
as soon as the electronic key is in the defined zone around the vehicle.



Selective unlocking
This setting is done via the configuration menu.
By default, complete unlocking is activated.
)
To unlock only the drivers door, withthe electronic key on your person, passyour hand behind the driver's door handle
then pull on the door handle to open.
) To unlock the complete vehicle, pass your hand behind one of the passenger door handles on the same side of the vehicle asthe electronic key is located, then pull on
the door handle to open.



Unlocking is confirmed by rapidflashing of the direction indicators for approximately two seconds.
The door mirrors unfold at the sametime.
If the alarm is on, the audible warningwhen opening a door with the key(integral with the remote control), willstop on star ting the engine.

Locking the vehicle
)With the electronic key in the definedzone A , press with a finger on one of
the door handles (at the markings) to lock
the vehicle.
Maintain pressure with your finger until
the windows close completely.

Locking is confirmed by fixed lighting of the direction indicators for approximately two seconds.The door mirrors fold at the same time.
If one of the doors or the boot is still open or if the key for Keyless Entry and Starting has been left inside the vehicle,the central locking does not take place.
When the vehicle is locked, if it isunlocked inadvertently, it will relockautomatically after about thir ty secondsunless a door is opened.
The folding and unfolding of the door mirrors by the remote control can bedeactivated by a CITROËN dealer or a qualified workshop.

As a safety measure (children onboard), never leave the vehicle without taking the key for the Keyless Entry andStarting system, even for a shor t period.Guard against theft when the key for the Keyless Entry and Starting systemis in the defined zone with the vehicle unlocked. After a long period of parking, the automatic detection functionsof the key are inhibited so as to notdischarge the vehicle's battery. You
should then use the remote controlfunction of the key to unlock the vehicle.
Ensure that no one prevents the correct operation of the windows.Be aware of children when operatingthe windows.This
function allows you to identify your vehicle from a distance, particularly in poor light. Your vehicle must be locked.
Locating your vehicle
)Press the closed padlock on the remotecontrol.
This will switch on the cour tesy lamps and thedirection indicators will flash for a few seconds.
