2011.5 Citroen DS5 HYBRID4 RHD display

05
7
8
9
10
1

A virtual keypad is displayed on the
screen: enter a code with at least 4 digitsand conform with OK.

A message is displayed on the screen of the
telephone: enter the same code and confi rm.
A message appears in the screen to confi rm the result of theconnection.
Pairin
g can also be initiated from the telephone by searching for detected Bluetooth devices.
Accept the connection to the telephone.

I
f pairing fails, try again; the number of attempts is not limited. The director
y and the calls list can be accessed after the
synchronisation period (if the telephone is compatible).

Automatic connection must be confi gured in the telephone to allow
the connection each time the vehicle is started.

In some cases, the reference number of the tele
phone or the
Bluetooth address may appear instead of the name of the telephone.
Pair/connect the telephone then listen: see the AUDI
O section.








STREAMING - PLAYING AUDIO FILES
VIA BLUETOOTH

1
2
3
4
05
5
325
USING THE TELEPHONE

The telephone connection automatically includes hands free operation
and audio streaming.
The abilit
y of the system to connect to just one profi le depends on the
telephone. Both profi les may connect by default.
Pr
ess MENU .
Select " Bluetooth connection" andconfi rm. Indicates connection of the audio steamin
g profi le.


MANAGING CONNECTIONS
Select " Connections management"and confi rm. The list of paired
telephones is displayed.
Select a telephone and confi rm. Indicates connection o
f the hands-free profi le.

Th
en select and confi rm:


- " Connect telephon
e
"/"Disconnect
telephone ": to connect/disconnect
the telephone or the hands-free
connection only.
-
"Connect media player"/r" Disconnect media player":rto connect/disconnect only streaming.

- " Connect tele
phone + mediaplayer
"/"rDisconnect telephone +media player
": to connect/disconnect rthe telephone (hands-free andstreaming).
-
"Delete connection ": to deletethe pairing. In
dicates that a device is connected.

1
2
1
4
2
33
05USING THE TELEPHONE
To display the "TELEPHONE
" menu:
- Make alon
g press on SOURCEor
SRC.
- Or, press OK
to display thecontextual menu. Select " Call" and confi rm.
-
Or, press MENU
, select "Telephone
" and confi rm. Select " Call" andconfi rm.


Select "Dial " to enter a number andconfi rm.
Repeat the previous step 1
to displaythe "TELEPHONE" menu.

Select OKand confi rm to start
the call.

Select "Calls list
" and confi rm.


MAKING A CALL - DIALLING

Select numbers one at a time using
the and buttons and confi rm.

MAKING A CALL - RECENTLY CALLED
NUMBERS *

Select the number and confi rm
to start the call.

The calls list includes calls sent and received in the vehicle usin
gthe connected telephone.

*

Depending on the compatibility of the telephone.
Correction allows numbers to be deleted one at a time.

It is possible to make a call directl
y from the telephone; park the
vehicle fi rst as a safety measure.

1
2
1
4
2
3
05
SRC
SR
C
327
USING THE TELEPHONE
Repeat the previous step 1to display
the " TELEPHONE" menu.

Select "Directory
" and confi rm.
An incoming call is announced by a ring and a superimposed displayin the multifunction screen.
M
obile
(depending on the informationavailable in the contact records of
the telephone connected).
"
YES
" to accept the call is selected by default.

Press OK
to accept the call.

Select " NO
" and confi rm to reject thecall.

or
Press one o
f these buttons to accept
the call.

MAKING A CALL -
FROM THE DIRECTORY
Select a contact then confi rm.

RECEIVING A CALL

Select the number and confi rm.
A long press on ESC
or on TEL ,
SOURCEor SRCalso rejects anincoming call.

Business
Home

1
2a2c
2b
05
SRC
USING THE TELEPHONE
During a call, press OK
to display the contextual menu.

Han
g up

In the contextual menu:

-
select "Telephone mode"
to transfer the call to the telephone.

-
deselect " Telephone mode
"
to transfer the call to the vehicle. In th
e contextual menu:
-
select " Micro OFF
" to switch off
the microphone.
-
deselect " Micro OFF" to switchthe microphone on.
In certain cases, the combined mode has to activated
from
the telephone.
If the contact has been cut off, when
you reconnect on returning to
the vehicle, the Bluetooth connection will be restored automatically (depending on the compatibility of the telephone).


MANAGING CALLS


A long press on one of these buttons also ends the call.
In the contextual menu, select " Hang up" to end the call.
Secret - Mute

(so that the caller cannot hear)

Combined mode

(to leave the vehicle without ending the call)

1
2
3
06
331

Press ‘
to display the audio settingsmenu.

The settin
gs available are:


-
Ambience,


- Bass,

-
Treble,

- Loudness,

- Distribution: Personalised or Driver,

- Left/ri
ght balance,

- Fader
(front/rear balance),

-
Auto. volume.



SCREEN C


The distribution (or spatialisation using the Arkamys© system), is©
an audio process which allows the sound quality to be improved
according to the setting chosen, corresponding to the position of the
listeners in the vehicle.
AUDIO SETTINGS
Select and confi rm " Other settings…"
to display the next setting in the list. The Ambience, Treble and Bass audio settin
gs are different andindependent for each sound source.
Arkamys©: in a vehicle, the sound quality suffers from the physicalconstraints imposed by the safety standards and the requirement
to optimise the space available in the passenger compartment. Speakers are fi tted in the doors, which can result for the driver and passenger in the sound being too one-sided, either "all on the right"or "all on the left".
The Arkamys© software installed in your audio system processes©
the digital signal from the media players (radio, CD, MP3, ...) and recreates a natural musical scene, with harmonious placement
of instruments and voices in the space facing passengers, at the height of the windscreen.

5
63
4
07
2
1
6












SETTING THE DATE AND TIME
Select the setting to be modifi ed.Confi rm by pressing OK
, then make
the change and confi rm again
to save the modifi cation.
Using the arrows, select "Displayconfi guration
" and confi rm.
Press MENU.
Using the arrows, select "Personalisation-confi guration"and confi rm.
SCREEN C
Using the arrows, select "
Date and
time adjustment" and confi rm.

Ad
just the settings one by one,confi rming by pressing the OKbutton. Next select the "
OK " tab on
the screen then confi rm to exit from
the " Date and time adjustment"menu.

08 SCREEN MENU MAP






Personalisation-
Configuration
Defi ne the vehicle parameters
Access to the vehicle

Plip action
Drivin
g position setting

Unlocking boot only
Driving assistance
Rear wipe in reverse gear
Parkin
g brake automatic

Speeds memorised
Vehicle lighting
Daytime lights
Directional headlampsInterior li
ghting
Welcome lighting
Follow-me-home headlamps

Choice of language
Displa
y confi guration
Choice of unit
s
Date and time adjustment
Display parameters
Brightness

Choice of sounds
1
2
3
3
3
2
3
3
3
2
3
3
2
3
3
1
1
2
2
2
2
1
