Familiarisation
Instruments and controls
1. Heated seat control. 2.
Gear lever, CVT gearbox.3.
Steering lock and ignition.
4.
Wiper / screenwash control stalk. 5.
Steering mounted control paddles for the CVT gearbox.
6.Windscreen demisting vent.
7. Passenger's airbag. 8.Glove box.
Passenger's airbag deactivation switch.
Back-up star ting unit (with the "Keyless
Entry and Star ting" system).9. Front door glass demisting vent.

18
Familiarisation
Monitoring

Manual headlamp adjustment.
Side switch panel
137
1.Open the glove box.
2. Inser t the key.3.
Select the position:"OFF"(deactivation), with "rear facing"child seat, "ON"
(activation), with front passenger or "forwards facing" child seat. 4.Remove the key keeping the switch in the
new position.

Passenger's front airbag
155
B.Deactivation of the ASC/ TCL system.
127 C
.Deactivation of the parking sensors.
148

Passenger safety
120
D.
Deactivation of the Stop & Start(Auto Stop & Go) function.

Starting



- Position 1: LOCK

- Position 2: ACC

- Position 3: ON

- Position 4: STA RT

Each press on the START/STOPbutton,
without action on the pedals, changes the mode of the vehicle.


- First press: ACC mode


- Second press: ONmode

- Third press: OFF mode
106
107


Ignition switch

START/STOP button

1
33
Monitoring
Screen 1Screen 2CauseSolution - ActionObservations
Fault with the "Keyless Entry andStarting" system. Contact a CITROËN dealer.
F
ault with the electronic anti-theftsystem. Switch off the ignition, then start theengine. If the problem persists, contact aCITROËN dealer.
The electronic key is not detected. Inser t the electronic key into the
housin
g located in the glove box. Remember to remove the electronickey from the housing after star ting
the vehicle.
The electronic ke
y has not been removed from the housing in the glove box. Remove the electronic ke
y from the
housing in the glove box.
The steering column is locked. Switch the ignition on and turn the
steering wheel slightly to unlock the
steering column.
The en
gine is off but the gear lever
is not in position P . P Place the gear lever in position P.P Only for vehicles fitted with a "CVT"gearbox.

98
Comfort























Front fi ttings

Sun visor. 2.
Glove box.3.
Portable ashtray.
4.
Cigarette lighter
12 V socket (120 W max).5. Armrest with storage compar tments.
6.Cup holder.
7. Bottle holder.

99
3
Comfort











Mat

When removing the mat on the driver's side, move back the seat as far as possible and
remove the fixings.
When refitting, position the mat correctly on thepins and clip the fixings. Check that the mat issecured firmly.
To prevent any risk of jamming under thepedals:


- only use mats suited to the fixings already present in the vehicle; it is imperative that
these fixings are used.

- never fit one mat on top of another.






Sun visor










Glove box


It has dedicated locations for storing a water bottle, the vehicle's handbook pack... )
To open the glove box, raise the handle.
It is illuminated when the lid is opened.
It houses the front passenger airbag deactivation switch A.
If the vehicle is fitted with air conditioning, it has a ventilation nozzle B
, distributing the sameconditioned air as the vents in the passenger compartment.
If your vehicle is fitted with the "Keyless Entryand Starting" system, it contains the back-upstarting unit C.
The sun visors fold for wards, and to the sidewhen they are unhooked.
They are fitted with a cour tesy mirror and a
ticket holder.

109
4
Driving
Once the engine has started, you can remove the electronic key from itshousing A
and close the glove box.


Back-up starting with the
electronic key
The message is displayed
when you open the driver's
door and the electronic keyhas not been removed fromits location A. Remember to take the electronic key with you when you leave the vehicle.
) Press the brake pedal on vehicles fitted
with a CVT gearbox or depress the clutch
pedal fully on vehicles with a manual gearbox.
) Press the "STA R T/STOP
" button.

When the electronic ke
y is in the defined zone
and your vehicle does not star t after pressingthe "START/STOP" button: )Open the glove box. )Inser t the electronic key in the location A.


Emergency stop with the
electronic key

During an emergency stop, the braking servo assistance and steering power assistance functions are no longer provided. Take great care.
In the event of an emergency only, theyengine can be stopped without any conditions.
To do this, press and hold the "STA R T/STOP " button for about 3 seconds or make 3
successive presses on the button.
The engine stops and the vehicle goes into
"ACC" mode.

154
Safety
Airbags
System designed to maximise the safety of the
occupants (with the exception of the rear centrepassenger) in the event of violent collisions.
It supplements the action of the force-limiting seat belts (with the exception of the rear centrepassenger).
If a collision occurs, the electronic detectors record and analyse the front and side impacts sustained in the impact detection zones:
- in the case of a serious impact, the airbagsare deployed instantly and protect the
occupants of the vehicle (with the exception
of the rear centre passenger); immediately after the impact, the airbags deflate rapidlyso that they do not hinder visibility or the
exit of the occupants,
- in the case of a minor or rear impact or incer tain roll-over conditions, the airbags
will not be deployed; the seat belt alone is
sufficient to provide optimum protection in
th
ese situations.
The airbags do not operate when the ignition is switched off. This equipment will only deploy once.
If a second impact occurs (during thesame or a subsequent accident), theairbag will not be deployed again.
Deployment of the airbag(s) is accompanied by a slight emission of harmless smoke and a noise, due to theactivation of the pyrotechnic cartridgeincorporated in the system.This smoke is not harmful, but sensitiveindividuals may experience slight irritation.
The noise of the detonation may result in a slight loss of hearing for a shorttime.

Impact detection zones
A.
Front impact zone. B.
Side impact zone.
Front airbags


Deployment

The airbags are deployed simultaneously,
unless the passenger's front airbag is
deactivated, in the event of a serious front
impact applied to all or par t of the front impact
zone A , in the longitudinal centreline of the
vehicle on a horizontal plane and directed from
the front to the rear of the vehicle.
The front airbag inflates between the front
occupant of the vehicle and the dashboard to
cushion their forward movement.
System which protects the head and chest of
the driver and front passenger in the event of a
front impact.
The driver's airba
g is fitted in the centre of the steering wheel; the front passenger's airbag is
fitted in the dashboard above the glove box.

322
