2010 VOLVO XC90 display

02 Instruments and controls
Information display
02
58
Message in the text windows
G026979
When a warning light in the instrument panel
comes on, a message is also displayed in the
text window. After you have read the message,
you can erase it by pressing button A (see illus-
tration).
NOTE
Certain messages cannot be erased until
the condition has been corrected.
If a warning message is displayed when e.g.
you are using the trip computer, this message
must be erased before you can access thefunction of your choice. Press button A to erase
the warning message.
You can scroll through the stored messages by
pressing button A (see illustration). The text
window can be cleared (the message will be
returned to memory) by pressing button A
again.
MessageMeaning
STOP SAFELYStop the car in a safe place and switch off the engine to help prevent the risk of serious damage.
STOP ENGINEStop the car in a safe place and switch off the engine to help prevent the risk of serious damage.
SERVICE URGENTTake your vehicle to a trained and qualified Volvo service technician for inspection immediately.
SEE MANUALRefer to your owner's manual. For additional information, please contact your Volvo retailer.
SERVICE REQUIREDTake your vehicle to a trained and qualified Volvo service technician for inspection at your convenience
(but preferably before the next scheduled maintenance service).
FIX NEXT SERVICEHave the system affected inspected at the next scheduled maintenance service.

02 Instruments and controls
Information display
02
59
MessageMeaning
TIME FOR REGULAR SERVICEThis message will be displayed at 7,500 mile (12,000 km) intervals, after 750 hours of driving or after
12 months, whichever occurs first, to remind the driver that the service interval has been exceeded. The
message will be displayed for 2 minutes each time the vehicle is started until reset by a trained and qualified
Volvo service technician.
OIL LEVEL LOW – FILL OILACheck the oil level and top up if necessary, see page 209.
OIL LEVEL LOW – STOP SAFELYBStop as soon as possible and switch off the engine, check the oil level and top up if necessary, see
page 209.
OIL LEVEL LOW – STOP ENGINEBStop as soon as possible and switch off the engine, check the oil level and top up if necessary, see
page 209.
OIL LEVEL LOW – SEE MANUALBStop as soon as possible and switch off the engine, check the oil level and top up if necessary, see
page 209.
DSTC SPIN CONTROL OFFThe stability system's spin control function has been turned off, see page 147 for details.
AThe yellow warning symbol also lights up (see page 54).BThe red warning symbol also lights up (see page 54).

02 Instruments and controls
Trip computer
02

* Option/accessory, for more information, see Introduction.71 Trip computer*
G026956
READ (press to acknowledge/confirm/
erase a message)
Thumb wheel (used to scroll among the trip
computer menus)
RESET
The trip computer stores information gathered
from several systems in your vehicle and has
four menus that can be displayed in the text
window.
•Driving distance on current fuel reserve
•Average fuel consumption
•Current fuel consumption
•Average speed
•Current speed in mph (Canadian models
only)
•DSTC (see page 147 for detailed informa-
tion)
NOTE
Warning messages from the vehicle's moni-
toring systems will override the trip com-
puter function. If a warning message is dis-
played in the text window while you are
using the trip computer, you must acknowl-
edge the message by pressing button A.
Press button A again to return to the trip
computer function.
1. Trip computer controls and functionsThe trip computer functions can be accessed
by twisting INFO (B) one step at a time in either
direction. Twisting a final time returns you to
the original function.
The trip computer can be reset (current data
will be erased from system memory) by press-
ing RESET (button C).
2. Driving distance on current fuel
reserve
This function shows the approximate distance
that can be driven on the fuel remaining in the
tank. The calculation is based on average fuel
consumption during the last 20 miles (30 km)of driving and the amount of fuel remaining in
the tank when the reading was taken.
When
"----" is displayed in the text window,
refuel as soon as possible.
3. Average fuel consumptionThis value indicates fuel consumption since the
last time the trip computer was reset (by press-
ing RESET, button C). When the engine is
switched off, information on fuel consumption
is stored and remains in system memory until
the RESET (button C) is pressed again.
4. Current fuel consumptionThis value indicates the current fuel consump-
tion, based on readings taken once per sec-
ond. When the vehicle is not moving, "----" will
be displayed.
5. Average speedThis value indicates average speed since the
last time the trip computer was reset (by press-
ing RESET, button C). When the engine is
switched off, information on average speed is
stored and remains in system memory until the
RESET (button C) is pressed again.

02 Instruments and controls
Cruise control
02

73 Engaging the cruise control function
G027098
The cruise control panel is located on the left
side of the steering wheel hub.
NOTE
This does not set the vehicle's speed.
1.
Press the CRUISE button.
>
CRUISE will be displayed in the infor-
mation window in the instrument panel.
2.
Press + or – to set the current speed.
>
CRUISE-ON will be displayed in the
information window in the instrument
panel.
Increasing or decreasing speed
G027139
Use + or – in the following ways to increase or
decrease the vehicle's speed:
1.
Press and hold down + or – until the vehicle
reaches the desired speed.
2.
Press + or – for approximately a half sec-
ond and release the button to increase or
decrease vehicle speed by approximately
1 mph (1.6 km/h).
NOTE
Cruise control will not function at speeds
below 20 mph. (30 km/h).
Braking
•Cruise control is automatically disengaged
when the brake pedal is depressed. The
currently set speed is stored in memory.
•Pressing resume will return the vehicle
to the previously set speed.
AccelerationMomentary acceleration, such as when pass-
ing another vehicle, does not affect cruise con-
trol operation. The vehicle will automatically
return to the previously set speed when you
release the accelerator pedal.
Disengaging cruise controlTo disengage cruise control, press the
CRUISE button. CRUISE or CRUISE-ON will
no longer be displayed in the information win-
dow in the instrument panel.
NOTE
Cruise control is automatically disengaged
if:
•the engine is switched off
•the gear selector is placed in (N) Neutral
•the wheels start to spin or lock
•if an increase in speed is maintained for
more than one minute
•if the vehicle's speed falls below
approximately 20 mph (30 km/h).

02 Instruments and controls
Cruise control
02
74
Temporarily disengaging the cruise
control
1.
Press 0 to temporarily disengage cruise
control.
>
CRUISE will be displayed in the infor-
mation window in the instrument panel.
2. Depress the brake pedal.
Pressing "resume"
causes the vehicle to
return to the previously set speed.
WARNING
Cruise control should not be used in heavy
traffic or when driving on wet or slippery
roads, or when driving on unpaved or
uneven road surfaces. Cruise control may
not maintain set speed on steep down-
grades.

02 Instruments and controls
12-volt sockets
02
* Option/accessory, for more information, see Introduction.75
These 12 volt sockets can be used to plug in
certain accessories such as cellular tele-
phones, etc.
The ignition key must be in at least position I
for the sockets in the front seat and the optional
socket at the rear of the center console to func-
tion.
12-volt socket in the cargo compartment
Fold down the lid to use the socket. This socket
can be used even if the ignition is switched off.
NOTE
•If the 12-volt sockets are used while the
engine is not running, there is a risk that
the vehicle's battery will be discharged.
•If the ignition is switched off and a
device drawing more than 0.1 A is con-
nected to a socket, a battery warning
will be displayed in the text window.
•The covers should be kept on when the
auxiliary sockets are not in use.
•Maximum current from the sockets is
15 A.
G028425
12-volt socket at the rear of the center console*
Ashtrays/cigarette lighterThe auxiliary sockets can also be used for cig-
arette lighters.
Ashtrays and lighters are available as acces-
sories. Please contact your Volvo retailer.
G027099
12-volt socket in the cargo compartment

02 Instruments and controls
Mirrors
02
80* Option/accessory, for more information, see Introduction.
Rearview mirror
G026660
To reduce glare from the headlights of follow-
ing vehicles, use the control to switch between
the normal and night-driving positions.
Normal position
Night position, reduces glare from follow-
ing headlights
Autodim function*The autodim function reacts to headlights from
following traffic and automatically reduces
glare.
NOTE
This function is automatically switched off
when the gear selector is placed in the
Reverse position.
Rearview mirror with compass*
G026965
The upper left-hand corner of the rearview mir-
ror has an integrated display that shows the
compass direction toward which the car is
pointing. Eight different directions can be dis-
played:
N, NE, E, SE, S, SW, W and NW. The
display shows your car's orientation with
respect to true north.
If the compass is activated, it will be displayed
automatically when the ignition is in postilion IIor when the engine is running. The compass
can be switched off or on by pressing the inset
button on the rear side of the mirror (see the
inset illustration). This can be done with
straightened paperclip or similar object. The
button is recessed approximately 1 in. (2.5 cm)
in the mirror.
G026409
Magnetic zonesThe earth is divided into 15 magnetic zones.
The compass is initially set for the zone to
which the car was delivered, and should
always be adjusted if the car is driven to a new
magnetic zone. To do so:
1.
Switch the ignition to position II.

02 Instruments and controls
Mirrors
02

81
2. Press the button on the rear side of the
mirror with straightened paperclip or simi-
lar object for approximately 3 seconds until
ZONE is displayed. The number of the cur-
rent magnetic zone will also be displayed.
3. Press the button repeatedly until the num-
ber for the desired zone (1 – 15) is dis-
played.
C
A
LZ
O
N
E
C
A
LZ
O
N
E
G026950
Calibrating the compass
After several seconds, the compass heading
will again be displayed, and the change of
magnetic zones is complete.
Calibrating the compass1. Stop the car in a large, open area, away
from traffic.
2. Turn off as many electrical devices in the
car as possible to avoid interference with
the compass (e.g. audio system, etc).
3. Using a pen or similar object, hold the but-
ton (on the rear side of the mirror)
depressed for at least 6 sec-
onds. "
CAL" will be displayed.
4. Drive slowly in a circle at a maximum speed
of 5 m.p.h. (8 km/h) until
CAL is no longer
displayed.
NOTE
This step can also be done by driving nor-
mally until CAL is no longer displayed.
Calibration is complete.
Power door mirrors
G029575
The mirror control switches are located on the
driver's door armrest.
Driver's side: Press the L button (a light in the
switch will light up) to activate the adjustment
control and then use this control to adjust the
driver's door mirror.
Passenger's door: Press the R button (a light
in the switch will light up) and then use the
adjustment control to adjust the passenger's
door mirror.
After you have adjusted the mirror(s), press the
L or R switch again (the light will go out) to
deactivate the adjustment control.
