2010 VOLVO XC90 display

10 Audio
Sirius satellite radio
10
252
Unlock all channelsThis permanently removes all channels from
the locked list and makes them available for
selection.
Temp. unlock all ch.This function will temporarily unlock all chan-
nels and make them available for selection. The
channels remain on the locked list and will
again be locked the next time the ignition is
switched on.
CHANGE CODE
This function makes it possible to change the
channel access code. The default code is
0000.
To change the code:
1.
Select
CHANGE CODE and press
ENTER.
2.
Enter the current code and press ENTER.
3.
Enter the new code and press ENTER.
4.
Confirm the new code and press ENTER.
If an incorrect code is entered, the
text "
Incorrect code!" is displayed.
If you have forgotten the access code1.
Select "SIRIUS ID" in the Sirius settings
menu and press ENTER.2.
Press and hold the ENTER button for
2 seconds.
The current code will be displayed.
Your Volvo retailer can also provide you with
assistance.

10 Audio
Auxiliary equipment
10

* Option/accessory, for more information, see Introduction.253
G027029
Auxiliary connector
AUX*The AUX (auxiliary) port can be used to con-
nect a device such as an MP3 player.
Turn the SELECTOR control (see the illustra-
tion on page 238) to choose
AUX.
If the player is being charged through a 12-volt
socket while it is connect to the AUX port,
sound quality may be impaired.
The volume of the external sound source AUX
may be different from the volume of the internal
sound sources such as the CD player or the
radio.
USB
USB connector in glove compartment
If you connect an iPodŸ, MP3 player or a USB
flash drive to the optional USB connector, this
device can be controlled using the vehicle's
audio controls.
NOTE
Be sure that the device and/or cable are in
the glove compartment before closing the
glove compartment door.
1.
Select USB with the SELECTOR button.
>
Connect device will be displayed.2.
Connect the iPodŸ, MP3 player or USB
flash drive to the USB connector (see the
illustration).
>
The text
Loading will be displayed while
the system loads the files (folder struc-
ture) on the device. This may take a
short time.
When the information has been loaded, infor-
mation about the tracks on the device will be
displayed.
The
/ buttons can be used to fast
forward/reverse or change tracks:
•Press briefly to change tracks.
•Press slightly longer to fast forward/
reverse.
The arrow keys on the steering wheel keypad
can also be used in the same way.
NOTE
The system supports playback of files in the
most common versions of formats such as
mp3, wma, and wav. However, there may be
versions of these formats that the system
does not support.
The system also supports a number of
iPodŸ models produced in 2005 or later.
iPodŸ Shuffle is not supported.

10 Audio
CD player/changer
10

* Option/accessory, for more information, see Introduction.255
G027151
Playing a CD
CD player
If a CD is in the slot and the audio system is in
CD mode when it is switched on, the CD will be
played automatically. Otherwise, to play a CD:
1.
Insert a CD into the slot
.
2. Select the CD mode using the
SELECTOR control
or the CD button
.
CD changer*The CD changer can hold up to six discs.
If a CD position in the changer containing a disc
is selected, and the audio system is in CDmode when it is switched on, the CD will play
automatically. Otherwise, to play a CD:
1. Select an empty position using the station
setting buttons 1 – 6.
INSERT DISC will be
displayed. Be sure this text is displayed
before inserting a disc. The numbers of
positions already containing discs are
shown in the display.
2.
Insert a CD into the slot
.
3. Select the CD mode using the
SELECTOR control
or the CD button
.
Ejecting CDs
CD player
Press the EJECT button to eject the CD.
CD changer
Ejecting one disc
A short press on the EJECT button (3) will
eject the CD that is currently playing.
NOTE
For reasons of traffic safety, the ejected CD
must be removed within 12 seconds or it will
be automatically drawn back into the slot
and the CD player will enter pause mode.
Press the CD button to restart the disc.
Ejecting all discs
A long press on the EJECT button starts
the EJECT ALL function.
The text
EJECTING ALL will be displayed and
the entire magazine will be emptied disc by
disc.
PauseTo pause CD playback, turn the volume all the
way down. "CD paused" will be displayed.
This will not occur if someone in the rear seat
is listening to the CD through the optional
headphones.
Play will resume when the volume is turned up
again.
Audio filesIn addition to playing normal music CDs, the
CD player/changer can also play discs con-
taining files in mp3 or wma format.
NOTE
Certain discs that are copy protected can-
not be read by the player.
When a disc with audio files is inserted in the
player, the player scans the disc's folders
before it begins playing the files. The length of
time that this takes depends on the quality of
the disc.

10 Audio
CD player/changer
10
256
Navigating the disc and playing tracksIf a disc with audio files is in the CD player,
press ENTER to display a list of folders on the
disc.
Use the up and down arrows to move among
the folders on the disc. Audio files have the
symbol and folders containing these
files have the
symbol.
Press ENTER to play a selected folder or a file.
When the music file has been played, the
player will continue to play the rest of the files
in the current folder. When all of the files in the
folder have been played, the player will auto-
matically go to the next folder and play the files
in it.
NOTE
Press or if the entire name of
the current track does not fit in the display.
Changing tracks
CD player/CD changer
1.
Briefly press or to go to the
next/previous track or file. The steering
wheel keypad can be used in the same
way.2.
Press and hold down
or to
search within a track/file. The search con-
tinues as long as the buttons are
depressed. The steering wheel keypad can
be used in the same way.
SCANThis function plays the first ten seconds of
each track or file1.
1.
Press SCAN to begin scanning the tracks
or files on the currently selected CD.
2.
Press EXIT/CLEAR or SCAN to interrupt
the scan function and listen to an entire
track or file.
Random play
CD player
This function plays the tracks or files on a CD
in random order (shuffle).
If a normal music CD is being playedSelect RANDOM in the menu and press
ENTER.
If a CD with mp3 or wma files is being
played
Select DISC or FOLDER in the menu and
press ENTER.
CD changerThis function offers two alternatives for playing
the tracks on the disc(s) in the CD changer in
random order (shuffle).
•SINGLE DISC (random order on the cur-
rently selected disc)
•ALL DISCS (random order on all of the
CDs in the changer)
If a normal music CD is being played
•Select RANDOM in the menu and press
ENTER.
•Select SINGLE DISC or ALL DISCS and
press ENTER.
NOTE
Press to play the next randomly selected
track. This can only be done on the currently
selected disc.
If a CD with mp3 or wma files is being
played
Select SINGLE DISC or FOLDER in the menu
and press ENTER.
This function is deactivated when a new disc is
selected.
1CD changer: SCAN only functions on the currently selected disc.

10 Audio
CD player/changer
10
257
DisctextCertain CDs contain information about the
disc, such as the titles of the tracks, etc. This
information can be shown in the display by
activating the
DISCTEXT function.
1.
Press the MENU button.
2.
Select
DISCTEXT in the menu and press
ENTER.
3. Any information that may be stored on the
disc will be displayed.
To deactivate this function, select
DISCTEXTand press ENTER.
Compact disc care
•Do not put tape or labels on the disc itself.
They could become stuck in the player.
•Use CD standard EN 60908 discs only.
Discs not meeting this standard may cause
problems with system (poor sound). CDR
discs can cause listening problems due to
the quality of the disc or recording equip-
ment used.
•DualDisc: The audio side of a DualDisc
(combined CD/DVD) does not meet CD
specifications and may not play in your
audio system.
•Keep the discs clean. Wipe them with a
soft, clean, lint-free cloth, working from the
center outwards. If necessary, dampen thecloth with a neutral soap solution. Dry thor-
oughly before using.
•Never use cleaning spray or antistatic liq-
uid. Use only cleaners specifically made for
CD's.
•Use discs of the correct size only (3.5"
discs should never be used).
•Volvo does not recommend the use of
plastic outer rings on the disc.
•Condensation may occur on discs/optical
components of the changer in cold winter
weather. The disc can be dried with a
clean, lint-free cloth. Optical components
in the CD changer may, however, take up
to one hour to dry off.
•Never attempt to play a disc which is dam-
aged in any way.
•When not in use, the discs should be
stored in their covers. Avoid storing discs
in excessive heat, direct sunlight or dusty
locations.

10 Audio
Rear Seat Entertainment – Dual Screen (RSE)*
10

* Option/accessory, for more information, see Introduction.259 Introduction
The RSE system can be used at the same time
as the vehicle’s audio system.
When the rear seat passengers play a DVD,
connect an external device to the RSE AUX
connectors, etc., and listen to the audio
through the cordless headphones, the driver
and front seat passenger can still use the vehi-
cle's audio system to listen to the radio, a CD,
music stored on an MP3 player, etc.
Please also refer to the Quick Guide provided
with the RSE system for additional information.
Electrical current - ignition keyThe RSE system can be activated with the igni-
tion in position I or II (see page 137 for infor-
mation on the ignition positions), or when the
engine is running. While the engine is being
started, a film or music that is currently being
played will pause momentarily and resume
playing when the engine has started.
When the RSE system has been used once
when the ignition is switched off, it will be then
be blocked for further use. RSE can be restar-
ted by turning the ignition key to position I.
NOTE
Using RSE for more than approximately
10 minutes with the engine switched off may
drain the vehicle’s battery and make it diffi-
cult or impossible to start the engine.
If this occurs, a message will be displayed
on the RSE system’s screens.
Music
Listening to a music CD1. Insert a CD into the RSE player’s slot with
the disc’s label facing upward.
> The CD will begin to play automatically.
2. Switch on the cordless headphones and
select CH A for the left screen or CH B for
the right screen.
> This will direct the sound to the head-
phones.
3. Adjust the headphone volume by using the
thumb wheel on the headphones.
To listen through the vehicle’s audio sys-
tem speakers, press MODE on the audio
system control panel and select
AUX.
Press
on the RSE remote to route the
sound through the speakers.
Selecting a folder on the CD1. Insert the CD in the player.2.
Press
.
3. Use the navigation buttons (the arrow keys
surrounding the OK button on the RSE
remote control) to highlight a folder and/or
a specific track.
4.
Press
to select a sub-folder.
Playback alternativesThe CD can be played in several different ways.
Use the navigation buttons to select one of the
alternatives.
With the dialogue box displayed:
1. Press the right navigation button to access
the menu to the right..
2. Use the navigation keys to select one of the
alternatives.
3.
Confirm your choice by pressing
.
Changing tracks on the CD
Change tracks on the CD by pressing
or . Hold the respective buttons
down for fast forward or reverse.
Pause1. Pause and restart the CD by pressing
.
2.
Stop the CD by pressing
.
3.
Press
again to eject the CD.

12 Index
12
281
Child restraint anchors......................... 43, 45
Child restraints
recalls and registration......................... 46
Child safety................................................ 33
Child safety locks....................................126
Climate system.......................................... 90
refrigerant............................................. 90
Clock reset button..................................... 54
Coat hanger............................................. 112
Cold weather precautions........................ 158
Compact disc care
CD care............................................... 257
Convertible seats....................................... 39
Coolant.................................................... 211
changing............................................. 206
Courtesy light........................................... 107
Cup holder
rear seat.............................................. 111
Curb weight............................................. 176
Current fuel consumption.......................... 71D
Defroster
rear window and door mirrors.............. 70
rear window and mirrors....................... 96
windshield............................................. 95
Detachable trailer hitch............................ 156
Dimensions.............................................. 266
Disabling the passenger's side front air-
bag............................................................. 25
Display, instrument panel.......................... 54
Dolby Pro Logic II (DPL II)........................ 241
Door mirrors............................................... 81
defroster............................................... 70
Door mirrors, folding.................................. 60
Driving conditions, difficult......................139
Driving economically................................ 138
Driving through water..............................139
E
Economical driving.................................. 138
Electrically operated moonroof.................. 83
Electrical system...................................... 275Emission inspection readiness................ 203
Engine
specifications...................................... 274
starting................................................ 135
Engine oil................................................. 208
specifications...................................... 273
F
Federal Clean Air Act............................... 202
Flat tires
changing............................................. 180
repairing with tire sealing system....... 184
Fog light..................................................... 56
Fog lights
front*..................................................... 64
Folding door mirrors.................................. 60
Front airbags.................................. 21, 22, 25
Front seat
folding backrest.................................. 100
manually adjusted............................... 100
Front seats
power.................................................. 100
ventilated.............................................. 93
XC90 Executive.................................. 102

12 Index
12
282
Front suspension..................................... 272
Fuel.......................................................... 130
Fuel filler cap........................................... 133
Fuel filler door
opening manually...............................133
unlocking.............................................. 64
Fuel system.............................................. 274
Fuses.......................................................224
G
Gasoline................................................... 130
Geartronic – manual shifting.................... 141
Generator................................................. 275
Generator warning light............................. 56
Glove compartment................................. 111
Grocery bag holder.................................. 117
Gross vehicle weight (GVW).................... 176
H
Hand brake................................................ 76
Hazard warning flashers............................ 70HD digital radio........................................ 246
Headlights.................................................. 63
Active Bending Lights............. 60, 64, 217
Dual Xenon........................................... 60
Headlights, high and low beams............... 66
Heated front seats..................................... 95
High/low beams – replacing....................217
High beam bulb, replacing...................... 222
High beam flash......................................... 66
High beam indicator.................................. 54
Hoisting the vehicle.................................205
Home safe lighting..................................... 66
Hood, opening/closing.............................. 77
I
Ignition switch.......................................... 137
Immobilizer (start inhibitor)...................... 120
Important information................................ 10
Indicator and warning symbols.................. 54
indicator light............................................. 56
Infant seats................................................ 37
Inflatable Curtain........................................ 29Inflation pressure, checking..................... 169
Inflation pressure table
Canadian models................................ 172
Information display.................................... 54
Inspection readiness................................ 203
Instrument overview.................................. 52
Instrument panel........................................ 54
Instrument panel lighting........................... 64
Interior lighting......................................... 107
ISOFIX/LATCH anchors............................. 43
J
Jack.........................................................180
K
Key (ignition switch) positions................. 137
Keys......................................................... 120
