2010 VOLVO C70 CONVERTIBLE engine

04 Interior
Power retractable hard top
04
100
Before operating the power retractable
hard top
A
BG020800
Please observe the following information
before operating the power retractable hard
top:
•There should be no objects on the power
retractable hard top's cover.
•Remove all snow, ice or loose objects from
the power retractable hard top and trunk
lid.
•The top should be dry before it is lowered.
CAUTION
If the power retractable hard top is lowered
while it is wet, water may drip into the pas-
senger compartment or trunk
•There should be at least 6.5 feet (2 meters)
of free space from the ground (distance A
in the illustration).
•There should be at least 8 inches (20 cm)
of free space behind the vehicle (distance
B in the illustration in the center column).
•The ambient temperature should be above
14°F (-10°C).
•The trunk divider (see page 101) must be
closed.
•The trunk must be closed.
•The vehicle must be at a standstill and the
brake pedal must be pressed.
Volvo also recommends the following:
•The vehicle should be parked outdoors, on
level ground.
•Raising or lowering the power retractable
hard top should preferably be done in one,
continuous operation.
•If the vehicle is parked outdoors, the
engine should be idling to help avoid bat-
tery drain.
CAUTION
If the instructions on these pages are not
followed, damage to the power retractable
hard top's mechanism may occur.
WARNING
•The power retractable hard top must
not be obstructed in any way when it is
being operated. Always have an unob-
structed view of the power retractable
hard top when it is in motion. See also
the decal on the trunk divider.
•Anyone near the vehicle should be well
clear of the power retractable hard top's
moving parts before it is operated.
•Children must never be allowed to play
with the power retractable hard top
control button.
•Do not leave the power retractable hard
top motionless longer than necessary
while it is being operated.
•Do not leave the key in the ignition if
there are children in the vehicle.

04 Interior
Power retractable hard top
04
102
Operating the power retractable hard
top
G032112
Power retractable hard top button
1.
Turn the ignition key to position II or start
the engine if the vehicle is parked out-
doors.
2. Press the brake pedal.
3.
Opening the hard top: Press and hold
down the button. Release the button when
an audible signal sounds and the message
TOP FULLY DOWN is displayed.
Closing the hard top: Pull up and hold the
button to raise the hard top. Release the
button when an audible signal sounds and
the message
TOP FULLY UP is displayed.
CAUTION
•Please heed any messages that may
appear in the information display while
the top is in operation.
•Any windows that are closed will be
opened approximately 4 inches (10 cm)
while the power retractable hard top is
in operation. The windows will be auto-
matically re-closed when the top is
completely raised or lowered.
WARNING
•See the section “Before operating the
power retractable hard top” on page
100 before operating the power retract-
able hard top.
Never pull the release wire for the power
retractable hard top’s hydraulic system that
is located under the rear seat cushion. This
wire is only intended for use by qualified
service personnel. Pulling this wire could
lead to:
•A high risk of being injured by the power
retractable hard top mechanism.
•Unexpected movement of the hard top,
or the hard top or the trunk could inad-
vertently open.
•The retractable hard top can be dam-
aged.
Power retractable hard top-related text
messages
•PRESS BRAKE TO OPERATE TOPPress the brake pedal to operate the
retractable hard top.
•CLOSE TRUNK TO OPERATE TOP The
trunk is open and must be closed before
operating the power retractable hard top.
•TRUNK DIVIDER IS NOT CLOSED The
trunk divider (see page 101 for more infor-
mation) must be closed before operating
the power retractable hard top.
•TOP INOPERATIVE LOW BATTERY The
battery's charge is too low to operate the
power retractable hard top. In this case,
the top can only be raised. Start the engine,
or if necessary, have the battery charged
before operating the top.
•TOP IS UNLOCKED The power retracta-
ble hard top is not fully up or down. Press/
pull and hold the button again to complete
the operation.
•TOO HOT OR COLD TO OPERATE
TOP The power retractable hard top
mechanism has overheated, or the ambi-
ent temperature is below 14° F (-10° C). If
the mechanism has overheated, wait for
approximately 5 minutes (the message in
the information display will disappear) and
try to lower or raise the top again.

04 Interior
Interior lighting
04
106
Interior lighting
G020805
Front courtesy lights and reading lights
Front driver's side reading light, on/off
Courtesy lighting
Front passenger's side reading light, on/off
The front seat reading lights can be switched
on and off by pressing buttons (1) or (3) when
the ignition key is position I or II, or when the
engine is running.
The courtesy lighting (2) can be set to three
positions:

Press the left side of the button: the interior
courtesy lighting turns on.
Neutral position: the interior courtesy light-
ing comes on when a door is opened, and
is switched off 10 seconds after the door is
closed.

Press the right side of the button: the inte-
rior courtesy lighting stays off.
Courtesy lighting – automatic function
The interior lighting has a built-in automatic
function that switches on the courtesy lighting
for 30 seconds when:
•the car is unlocked from the outside using
the key blade or remote key
•the engine is switched off and the ignition
key is turned to the 0 position.
The courtesy lighting lights up or remains on
for 5 minutes when:
•one of the doors is opened and left open.
•the courtesy lighting has not been
switched off (the right side of button 2
depressed).
The automatic lighting goes out when:
•the engine is started
•the car is locked from the outside using the
key blade or remote key.
If the courtesy lighting is not switched off man-
ually, it will be turned off automatically5 minutes after the engine has been switched
off.
Footwell lightingThe footwell (and courtesy lighting) comes on
or goes off when one of the side doors is
opened or closed.
Rear reading lights
G020806
Rear reading lights
The rear reading lights can be switched on or
off by pressing the respective buttons, and
function if the ignition key is in positions I, II, or
if the engine is running.
The courtesy lighting can be switched on or off
within 30 minutes after the engine has been

04 Interior
Interior lighting
04
107
switched off, or after a door has been opened
or closed.
These lights switch off automatically 5 minutes
after the engine has been switched off.
Vanity mirror
G020210
Raise the cover to switch on the light.

04 Interior
Trunk
04
114* Option/accessory, for more information, see Introduction.
NOTE
The trunk cannot be closed while the folded
power retractable hard top is in the upper
position.
Raising and lowering the folded top in
the event of a fault
If the message ROOF FAILURE SEE
MANUAL is displayed, the folded power
retractable hard top can only be lowered in the
trunk.
CAUTION
Damage may be unavoidable if the power
retractable hard top must be operated when
this message is displayed.
Press the button again and hold it down. After
approximately 2 seconds, the power retracta-
ble hard top will begin to move. Keep the but-
ton depressed until the folded top is lowered.
An audible signal will sound during this entire
operation.
Load anchoring eyelets
G020850
The eyelets in the trunk can be used to fasten
accessory load and lashing straps, load nets,
and other load anchors.
12-volt socket in trunk*
G020856
Fold down the lid to use the socket.
•Using the 12-volt socket while the engine
is not running drains the vehicle's battery.
•If the ignition is switched off and a device
drawing more that 0.1A is connected to a
socket, a battery alert will be shown in the
driver information display.
•The cover should be kept on when the aux-
iliary socket is not in use.

05 Locks and alarm
Keyless drive*
05
126* Option/accessory, for more information, see Introduction.
CAUTION
•Keyless drive remote keys should never
be left in the vehicle. In the event of a
break-in, a remote found in the vehicle
could make it possible to start the
engine.
•Electromagnetic fields or metal
obstructions can interfere with the key-
less drive system. Avoid placing the
remote key near cellular phones, metal-
lic objects or e.g., in a metal briefcase.
Canada – IC:267T- 5WK48952,
267T- 5WK48964, 267T-5WK48891
NOTE
This device complies with RSS -210 of Industry
Canada. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept interference received, including inter-
ference that may cause undesired operation.
CAUTION
Changes or modifications not expressly
approved by the manufacturer could void the
user's authority to operate the equipment.
USA – FCC ID:KR55WK48952,KR55WK48964
NOTE
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept interference received, including inter-
ference that may cause undesired operation.
CAUTION
Changes or modifications not expressly
approved by the manufacturer could void the
user's authority to operate the equipment.
Siemens VDO
5WK48891
Tested To Comply With FCC Standards
For Automobile Use
Location of the keyless drive antennas
The keyless drive system has a number of
antennas located at various points in the vehi-
cle.
G020077
On the inside center of the rear bumper
Under the floor of the trunk, near the rear
seat
Left door handle
Under the rear section of the center con-
sole
Right door handle
Under the front section of the center con-
sole

05 Locks and alarm
Alarm*
05

* Option/accessory, for more information, see Introduction.131 Turning off (stopping) the alarm
If the alarm is sounding, it can be stopped by
pressing the UNLOCK button on the remote
key or by inserting the key in the ignition switch.
The driver's door must first be unlocked with
the key blade.
NOTE
On vehicles equipped with the optional key-
less drive, the start control must be
removed from the ignition switch before the
key can be inserted, see page 145 for
instructions.
Audible/visual alarm signal
An audible alarm signal is given by a battery
powered siren. The alarm cycle lasts for
30 seconds.
NOTE
The visual alarm signal is given by flashing
all turn signals and turning on the interior
lighting for approximately 5 minutes.
Temporarily turning off the accessory
alarm sensor(s)
G026313
Display
MENU
EXIT
ENTER
Menu navigation controlsIn certain situations it may be desirable to turn
off the accessory inclination and movement
alarm sensors, and the double locking function
if, for example, you drive your vehicle onto a
ferry where the rocking of the boat could trigger
the alarm or if a pet is left in the vehicle with the
doors locked.
To do so:
1.
Press MENU to enter the menu system and
scroll to
Car settings (for a more detailed
description of the menus, see page 75.
2.
Select
Reduced guard.
3.
Select
Activate once and the messageReduced guard – See manual will
appear in the information display. The
alarm sensors and/or double locking func-
tion will be turned off when the vehicle is
locked.
or
Select
Ask on exit. Each time the ignition
key is turned to position 0, the message
Press ENTER to reduce guard until
engine is started. Press EXIT to
cancel
will be displayed. Select one of the
alternatives:

06 Starting and driving
General information
06
136
Economical driving conserves natural
resources
Better driving economy may be obtained by
thinking ahead, avoiding rapid starts and stops
and adjusting the speed of your vehicle to
immediate traffic conditions.
Observe the following rules:
•Bring the engine to normal operating tem-
perature as soon as possible by driving
with a light foot on the accelerator pedal for
the first few minutes of operation. A cold
engine uses more fuel and is subject to
increased wear.
•Whenever possible, avoid using the vehicle
for driving short distances. This does not
allow the engine to reach normal operating
temperature.
•Drive carefully and avoid rapid acceleration
and hard braking.
•Use the transmission's Drive (D) position
as often as possible and avoid using kick-
down.
•Do not exceed posted speed limits.
•Avoid carrying unnecessary items (extra
load) in the vehicle.
•Maintain correct tire pressure. Check tire
pressure regularly (when tires are cold).
•Remove snow tires when threat of snow or
ice has ended.
•At highway driving speeds, fuel consump-
tion will be lower with the air conditioning
on and the windows closed than with the
air conditioning off and the windows open.
•Using the onboard trip computer's fuel
consumption modes can help you learn
how to drive more economically.
Other factors that decrease gas mileage
are:
•Dirty air cleaner
•Dirty engine oil and clogged oil filter
•Dragging brakes
•Incorrect front end alignment
Some of the above mentioned items and others
are checked at the standard maintenance
intervals.
WARNING
Driving with the trunk open: Driving with
the trunk open could lead to poisonous
exhaust gases entering the passenger com-
partment. If the trunk must be kept open for
any reason, proceed as follows:
1. Close the windows.
2. Set the ventilation system control to air
flow to floor, windshield and side win-
dows and the blower control to its high-
est setting.
Weight distribution affects handling
At the specified curb weight your vehicle has a
tendency to understeer, which means that the
steering wheel has to be turned more than
might seem appropriate for the curvature of a
bend. This ensures good stability and reduces
the risk of rear wheel skid. Remember that
these properties can alter with the vehicle load.
The heavier the load in the cargo area, the less
the tendency to understeer.
Handling, roadholding
Vehicle load, tire design and inflation pressure
all affect vehicle handling. Therefore, check
that the tires are inflated to the recommended
pressure according to the vehicle load. See the
"Tire pressure" section. Loads should be dis-
tributed so that capacity weight or maximum
permissible axle loads are not exceeded.
Driving through water
The vehicle can be driven through water up to
a depth of approximately 9 in. (25 cm), at a
maximum speed of 6 mph (10 km/h).
•Take particular care when driving through
flowing water.
•Clean the electrical connections for trailer
wiring after driving in mud or water
•When driving through water, maintain low
speed and do not stop in the water.
