06 Starting and driving
Fuel requirements
06
141
You can also keep the vehicle locked if you
remain inside it during refueling. The central
locking button does not lock the fuel filler door.
Be sure the fuel filler door is not obstructed and
is completely closed after refueling. Open the
fuel filler cap slowly during hot weather.
Refueling
The fuel tank is designed to accommodate
possible expansion of the fuel in hot weather,
see page 269 for fuel tank volume. Be aware
that the "usable" tank capacity will be some-
what less than the specified maximum. When
the fuel level is low, such factors as ambient
temperature, the fuel's "Reid vapor pressure"
characteristics, and terrain can affect the fuel
pump's ability to supply the engine with an
adequate supply of fuel. Therefore, it is advis-
able to refuel as soon as possible when the
needle nears the red zone, or when the fuel
warning light comes on.
CAUTION
•Do not refuel with the engine running1.
Turn the ignition off or to position I. If the
ignition is on, an incorrect reading could
occur in the fuel gauge
•After refueling, close the fuel filler cap
by turning it clockwise until it clicks into
place.
•Avoid overfilling the fuel tank. Do not
press the handle on the filler nozzle
more than one extra time. Too much fuel
in the tank in hot weather conditions can
cause the fuel to overflow. Overfilling
could also cause damage to the emis-
sion control systems.
•Avoid spilling gasoline during refueling.
In addition to causing damage to the
environment, gasolines containing
alcohol can cause damage to painted
surfaces, which may not be covered
under the New Vehicle Limited War-
ranty.
•Do not use gasolines containing meth-
anol (methyl alcohol, wood alcohol).
This practice can result in vehicle per-
formance deterioration and can dam-
age critical parts in the fuel system.
Such damage may not be covered
under the New Vehicle Limited War-
ranty.
1If the fuel filler cap is not closed tightly or if the engine is running when the vehicle is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle’s
performance will not be affected. Use only Volvo original or approved fuel filler caps.
12 Index
12
280
Electrical system...................................... 274
Electronic Brake Force Distribution
(EBD)........................................................ 151
Electronic Climate Control
air distribution table.............................. 88
Electronic Climate Control (ECC)............... 85
Emergency brake....................................... 70
Emergency locking retractor...................... 34
Emergency starting.................................. 157
Emergency towing................................... 154
Emission inspection readiness................ 210
Engine
specifications...................................... 272
starting................................................ 143
starting with keyless drive.................. 145
Engine compartment overview................213
Engine oil................................................. 214
changing............................................. 214
checking............................................. 214
specifications...................................... 271
volumes.............................................. 269
Equalizer, audio system........................... 241
Eyelets for anchoring loads..................... 114F
Federal Clean Air Act............................... 208
Flat tires
changing............................................. 188
repairing with tire sealing system....... 190
Fluids and oils.......................................... 269
FM1/FM2 menu....................................... 243
Fog lights
front...................................................... 59
rear........................................................ 60
Front airbags.............................................. 22
disconnecting passenger’s side airbag 26
Front fog lights........................................... 59
Front park assist...................................... 166
Front seats................................................. 92
accessing the rear seat........................ 92
adjusting the head restraints................ 98
manually operated................................ 92
power.................................................... 96
Fuel filler door
opening manually................................. 60
unlocking.............................................. 60
Fuel gauge................................................. 49
Fuel requirements.................................... 139Fuel tank volume.....................................269
Fuses, replacing......................................228
G
Gasoline requirements............................. 139
Geartronic................................................ 148
Glossary of tire terminology..................... 181
Glove compartment................................. 109
locking................................................ 129
Gross vehicle weight (GVW)............182, 267
H
Hand brake (parking brake)....................... 70
Hazard warning flashers............................ 69
HD digital radio........................................ 245
Headlights.................................................. 59
changing bulbs................................... 221
high and low beams............................. 61
high beam flash.................................... 61
Headlight washers..................................... 67
High beam flash......................................... 61
