2010 VOLVO C70 CONVERTIBLE Owner´s Manual

04 Interior
Trunk
04

113 Loading the trunk
G020848
Button for changing level of folded power retract-
able hard top
Loading the trunk with the power
retractable hard top down
When the power retractable hard top is down,
it is folded in the trunk. Using the button shown
in the illustration above, the folded power
retractable hard top can be moved up or down
slightly to facilitate loading or unloading small
objects.
NOTE
This movement is part of the normal power
retractable hard top operation, which
means that messages pertaining to the
power retractable hard top’s operation (see
page 102) also apply to the this function.
WARNING
Anyone near the vehicle should be well clear
of the power retractable hard top's moving
parts before it is operated.
CAUTION
•Any objects that impede the movement
of the power retractable hard top may
damage the top or its mechanism.
•When the power retractable hard top
has been raised for loading the trunk, or
if its movement has been interrupted by
pressing the button twice, the trunk
should not be closed. Doing so can
damage the system or cause paint
damage.
To raise the level of the folded power
retractable hard top:
1. Open the trunk.2. Press the button on the right side of the
trunk opening.
NOTE
There may be a delay of several seconds
before the folded power retractable hard
top begins to move.
Movement of the top can be stopped by
pressing the button again.
3. The folded power retractable hard top will
raise slightly. If an audible signal sounds
during this operation, check the informa-
tion display in the center instrument panel
for messages.
4. Lift the trunk divider (see page 101) to pro-
vide an opening into the trunk.
5. When the objects to be loaded have been
placed in the trunk, press down the trunk
divider.
6. Press the button to move the power
retractable hard top downward. Movement
of the top can be stopped by pressing the
button again.
7. Close the trunk.

04 Interior
Trunk
04
114* Option/accessory, for more information, see Introduction.
NOTE
The trunk cannot be closed while the folded
power retractable hard top is in the upper
position.
Raising and lowering the folded top in
the event of a fault
If the message ROOF FAILURE SEE
MANUAL is displayed, the folded power
retractable hard top can only be lowered in the
trunk.
CAUTION
Damage may be unavoidable if the power
retractable hard top must be operated when
this message is displayed.
Press the button again and hold it down. After
approximately 2 seconds, the power retracta-
ble hard top will begin to move. Keep the but-
ton depressed until the folded top is lowered.
An audible signal will sound during this entire
operation.
Load anchoring eyelets
G020850
The eyelets in the trunk can be used to fasten
accessory load and lashing straps, load nets,
and other load anchors.
12-volt socket in trunk*
G020856
Fold down the lid to use the socket.
•Using the 12-volt socket while the engine
is not running drains the vehicle's battery.
•If the ignition is switched off and a device
drawing more that 0.1A is connected to a
socket, a battery alert will be shown in the
driver information display.
•The cover should be kept on when the aux-
iliary socket is not in use.

04 Interior
Trunk
04
115 Carrying long loads (ski hatch)
G021037
Ski hatch
The center section of the rear seat backrest
can be opened to create space for carrying
long, light objects (max. length 6.5 ft/2 meters,
max. weight 55 lbs/25 kg). To do so, the center
section (cushion) of the rear seat backrest must
be removed, the tire repair kit (if the vehicle is
so equipped) must be removed and stowed in
the trunk, and the plastic hatch in the trunk
must be opened.
Removing the center backrest cushionPull the strap at the upper edge of the cushion,
pull it forward, and lift it out.
Opening the plastic hatchFrom the trunk, press the catches in the two
holes in the hatch toward each other to release
the hatch, and fold it down.
NOTE
If the vehicle is equipped with the optional
ski bag, the bag’s zipper must be opened
from the passenger’s compartment in order
to insert objects through the ski hatch.
Replacing the backrest cushionBegin by guiding the lower section of the cush-
ion into place. Then press the upper section of
the cushion into place.
NOTE
This cushion is locked in place when the
vehicle is locked with the remote control.
Securing long objectsLong objects should be secured with one of the
rear seat belts.
Wrap the belt once around the object and lock
the belt in the retractor as usual. If the vehicle
is equipped with the optional ski bag, pass the
seat belt through the bag’s handle before fas-
tening the seat belt.

116* Option/accessory, for more information, see Introduction.
Remote key and key blade................................................................... 118
Valet locking ......................................................................................... 122
Keyless drive*........................................................................................ 124
Locking and unlocking.......................................................................... 128
Alarm*.................................................................................................... 130

05
LOCKS AND ALARM

05 Locks and alarm
Remote key and key blade
05
118
Remote keys
Two remote keys that also function as ignition
keys are provided with your car. The remote
keys contain detachable metal key blades for
manually locking or unlocking the driver's door
and the glove compartment.
USA – FCC ID: LTQVO315TXThis device complies with part 15 of the FCC
rules. Operation is subject to the following con-
ditions: (1) This device may not cause harmful
interference, and (2) this device must accept
any interference received, including interfer-
ence that may cause undesired operation.
Canada – IC: 3659AVO315TXOperation is subject to the following condi-
tions: (1) this device may not cause interfer-
ence, and (2) this device must accept any inter-
ference, including interference that may cause
undesired operation of the device.
Loss of a remote key
If either of the remote keys is lost, the other
must be taken with the car to a Volvo retailer.
As an anti-theft measure, the code of the lost
remote key must be erased from the system.
Each key blade has a unique code, which is
used if new key blades are required. A maxi-
mum of six remote keys/key blades can be
programmed and used for one car.
Immobilizer (start inhibitor)
Each of the keys supplied with your car con-
tains a coded transponder. The code in the key
is transmitted to an antenna in the ignition
switch where it is compared to the code stored
in the start inhibitor module. The car will start
only with a properly coded key. If you misplace
a key, take the other keys to an authorized
Volvo retailer for reprogramming as an antitheft
measure.
CAUTION
Never use force on the narrow section of the
remote key – this is where the transponder
is located. The car cannot be started if the
transponder is damaged.
USA – FCC ID: LTQWFS 125VOThis device complies with part 15 of the FCC
rules. Operation is subject to the following con-
dition: (1) This device may not cause harmful
interference, and (2) this device must accept
any interference received, including interfer-
ence that may cause undesired operation.
Canada – IC: 3659A-WFS125VOOperation is subject to the following condi-
tions: (1) this device may not cause interfer-
ence, and (2) this device must accept any inter-
ference, including interference that may cause
undesired operation of the device.
Remote key functions
G019402
Lock – Press the Lock button on the
remote once to lock all doors and the trunk.
The turn signals will flash once to confirm
locking.
NOTE
The car can also be locked if a door is open
(does not apply to vehicles with the optional
keyless drive).

05 Locks and alarm
Remote key and key blade
05

119
Unlock – Press the Unlock button on the
remote once to unlock the driver's door.
After a short pause, press the Unlock but-
ton a second time within 10 seconds to
unlock the other doors and the trunk. A
long press (at least several seconds) opens
all side windows.
NOTE
•The turn signals flash to confirm that the
vehicle has been correctly locked/
unlocked with the remote key or the
optional keyless drive. When locking the
vehicle, the turn signals will flash a con-
firmation only if all the doors are
securely closed and locked. Flashing
confirmation for locking and unlocking
may be customized in the vehicle's Per-
sonal settings menu, see page 75 for
more information.
•The two-step unlocking function can be
changed so that one press of the
Unlock button unlocks all of the doors
and the trunk. See Personal settings
page 75 for more information.
•Automatic relocking: If the doors are
unlocked, the locks will automatically reen-
gage (re-lock) and the alarm will rearm after2 minutes unless a door or the trunk has
been opened.
•Automatic locking: When the car starts to
move, the doors and trunk can be locked
automatically. This feature can be turned
on or off, see Personal settings on page
75 for more information.
•Airbag deployment will automatically
attempt to unlock the doors.
Approach lighting – As you approach the
car: Press the button on the remote key to
illuminate the area around the car in dark
conditions. Pressing the button once lights
up the interior lighting, parking lights, and
license plate lighting. These lights will
switch off automatically after 30, 60 or
90 seconds. See the Personal settings pa
ge 75 for information about adjusting the
time setting.
Unlock trunk – Press the button once to
disarm the alarm system and unlock only
the trunk. After closing, the trunk will not
automatically relock. Press Lock to relock
it and rearm the alarm.
NOTE
This function will unlock, but not pop open,
the trunk.
Panic alarm – This button can be used to
attract attention during emergency situa-
tions. To activate the panic alarm, press
and hold the red button for at least 3 sec-
onds or press it twice within 3 seconds.
The turn signals and horn will be activated.
The panic alarm will stop automatically
after 30 seconds. To deactivate, wait
approximately 5 seconds and press the red
button again.
NOTE
This button will NOT unlock the car.
Weak battery in the remote key
G019406

05 Locks and alarm
Remote key and key blade
05
120
When the battery begins to lose its charge, the
Information symbol in the instrument panel
(see page 51) lights up and
KEY BATTERY
LOW VOLTAGE is shown in the information
display.
Replacing the battery in the remote key
If the range of the transmitter is noticeably
reduced, this indicates that the battery (type
CR 2450, 3V) is weak and should be replaced.
To replace the battery:
1. Place the remote key with the keypad
downward. Pry open the cover with a small
slotted screwdriver.
2. Remove the cover.
CAUTION
When replacing the battery, avoid touching
the electrical circuitry in the other half of the
remote key.
3. Note how the + and – sides of the battery
are positioned on the inside of the cover
(see the underside of the cover).
4. Pry out and replace the battery. Avoid
touching the battery and its contact surfa-
ces with your fingers.
5. Press the cover back into place.The old battery should be disposed of properly
at a recycling center or by a trained and quali-
fied Volvo service technician.
Key blade
G019403
Removing the key blade
The key blade can be removed from the remote
key. When removed, it can be used as follows:
•To lock/unlock the driver’s door
•To lock/unlock the glove compartment,
see page 129.
•To open the trunk mechanically, see
page 129.
•For valet locking (see page 122)
Removing the key bladeSlide the spring loaded catch to the side.
While holding the catch, pull the key blade
out of the remote key.
Reinserting the key blade in the remote
key
1. Hold the remote key with the pointed end
down.
2. Carefully slide the key blade into its groove.
3. Gently press the key blade in the groove
until it clicks into place.
Unlocking the doors with the detached
key blade
1. Insert the key blade as far as possible in the
driver's door lock.
2. Turn the key blade clockwise approxi-
mately one-quarter turn to unlock the driv-
er's door only.
NOTE
After unlocking the driver's door with the
key blade, opening the door will trigger the
alarm.
To disable the alarmPress the Unlock button on the remote key, or
insert the key in the ignition switch.
