55 1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CAUTION
■Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
●Use the head restraints designed for each respective seat.
●Adjust the head restraints to the correct position at all times.
●After adjusting the head restraints, push down on them and make sure
they are locked in position.
●Do not drive with the head restraints removed.

64 1-3. Adjustable components (seats, mirrors, steering wheel)
CAUTION
■Seat belt damage and wear
●Do not damage the seat belts by allowing the belt, plate, or buckle to be
jammed in the door.
●Inspect the seat belt system periodically. Check for cuts, fraying, and loose
parts. Do not use a damaged seat belt until it is replaced. Damaged seat
belt cannot protect an occupant from death or serious injury.
●Ensure that the belt and tab are locked and the belt is not twisted.
If the seat belt does not function correctly, immediately contact your Toyota
dealer.
●Replace the seat assembly, including the belts, if your vehicle has been
involved in a serious accident, even if there is no obvious damage.
●Do not attempt to install, remove, modify, disassemble or dispose of the
seat belts. Have any necessary repairs carried out by your Toyota dealer.
Inappropriate handling of the pretensioner may prevent it from operating
properly resulting in death or serious injury.
■Child restraint lock function belt precaution
Do not allow children to play with the child restraint lock function belt. If the
belt becomes twisted around a child’s neck, it will not be possible to pull the
belt out leading to choking or other serious injuries that could result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used
to cut the belt.
■When using the rear center seat belt
Do not use the rear center seat belt with
either buckle released. Fastening only
one of the buckles may result in death or
serious injury in case of sudden braking
or a collision.

65 1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CAUTION
■Using a seat belt comfort guide
●Make sure the belt is not twisted and that it lies flat. The elastic cord must
be behind the belt and the guide must be on the front.
●To reduce the chance of injury in case of emergency braking, sudden
swerving or an accident while driving, remove and store the comfort guide
in its pocket when it is not in use.
●Always make sure the shoulder belt is positioned across the center of the
shoulder. The belt should be kept away from the neck, and should not fall
off the shoulder.
Failure to observe these precautions could reduce the effectiveness of the
seat belt in an accident, causing death or serious injury.
■Using a seat belt extender
●Do not wear the seat belt extender, if you can fasten the seat belt without
the extender.
●Do not use the seat belt extender when installing a child restraint system,
because the belt will not securely hold the child restraint system, increas-
ing the risk of death or serious injury in the event of an accident.
●The personalized extender may not be safe on another vehicle, when
used by another person, or at a different seating position other than the
one originally intended.
NOTICE
■When using a seat belt extender
When releasing the seat belt, press on the buckle release button on the
extender, not on the seat belt.
This helps prevent damage to the vehicle interior and the extender itself.

101 1-7. Safety information
1
Before driving
CAUTION
■Front passenger occupant classification system precautions
●If an adult sits in the front passenger seat, the AIR BAG ON indicator light
is illuminated. If the AIR BAG OFF indicator is illuminated, ask the passen-
ger to sit up straight, well back in the seat, feet on the floor, and with the
seat belt worn correctly. If the AIR BAG OFF indicator still remain illumi-
nated, either ask the passenger to move to the rear seat, or if that is not
possible, move the front passenger seat fully rearward.
●When it is unavoidable to install the forward-facing child restraint system
on the front passenger seat, install the child restraint system on the front
passenger seat in the proper order. (
P. 106)
●Do not modify or remove the front seats.
●Do not kick the front passenger seat or subject it to severe impact. Other-
wise, the SRS warning light may come on to indicate a malfunction of the
detection system. In this case, contact your Toyota dealer immediately.
●Child restraint systems installed on the rear seat should not contact the
front seatbacks.

113 1-7. Safety information
1
Before driving
Child restraint systems with a top tether strap
Remove the luggage cover. (P. 234)
Remove the deck board and auxiliary boxes. (P. 233)
Remove the head restraint.
Split rear seats (type A), Non-split rear seat
Latch the hook onto the anchor
bracket and tighten the top tether
strap.
Make sure the top tether strap is
securely latched.

116 1-7. Safety information
CAUTION
■When installing a child restraint system
●Split rear seats: When installing a child restraint system in the rear center
seat, adjust both seat cushions to the same position and align seatbacks
at the same angle. The seatbacks must be adjusted to the same angle.
Otherwise, the child restraint system cannot be securely restrained and
this may cause death or serious injuries in the event of emergency brak-
ing, sudden swerving or an accident.
●Split rear seats: When using the LATCH anchors for a child restraint sys-
tem, move the seat as far back as possible and adjust the seatback as
upright as possible.
●When a booster seat is installed, always ensure that the shoulder belt is
positioned across the center of the child's shoulder. The belt should be
kept away from the child's neck, but not so that it could fall off the child's
shoulder. Failing to do so may result in death or serious injury in the event
of emergency braking, sudden swerving or an accident.
●Ensure that the belt and tab are securely locked and the seat belt is not
twisted.
●Push and pull the child restraint system from side to side and forward to be
sure it is secure.
●After securing a child restraint system, never adjust the seat.
●Follow all installation instructions provided by the child restraint system
manufacturer.
●Split rear seats: When a child restraint system with a top tether strap is
installed, do not install the head restraint. The head restraint may interfere
with the top tether strap preventing secure installation of the child restraint
system.
●Split rear seats: Make sure to properly store the removed head restraint in
a secure place when you use the child restraint system on the rear seats.

390 Alphabetical index
Child restraint system
Booster seats, definition ........ 102
Booster seats, installation ..... 106
Convertible seats, definition .. 102
Convertible seats,
installation ........................... 106
Front passenger occupant
classification system .............97
Infant seat, definition ............. 102
Infant seats, installation......... 106
Installing CRS with LATCH
system ................................ 108
Installing CRS with seat
belts .................................... 109
Installing CRS with top
tether straps ........................ 113
Child safety
Airbag precautions ..................92
Battery precautions ....... 262, 344
Child restraint system............ 102
Child-protectors .......................34
How your child should wear
the seat belt ..........................62
Installing child restraints ........ 106
Power window lock switch.......72
Power window precautions .....73
Removed key battery
precautions ......................... 282
Seat belt extender
precautions ...........................65
Seat belt precautions ..............63
Child-protectors .........................34
Cleaning
Exterior .................................. 236
Interior ................................... 238
Seat belts .............................. 239
Clock ......................... 139, 141, 229
Clutch
Fluid ...................................... 358
Pedal ..............................120,134
Comfort guide ............................59
Condenser ................................ 259
CRS ........................................... 102Cruise control
Cruise control ........................ 156
Indicator ................................ 156
Cup holders .............................. 222
Curtain shield airbags ............... 85
Customizable features ............ 377
Daytime running light
system .................................... 150
Defogger
Rear window ......................... 193
Side mirrors........................... 193
Dimension ................................ 352
Do-it-yourself maintenance .... 247
Doors
Back door ................................ 36
Door glasses ........................... 71
Door lock ................................. 31
Side doors ............................... 31
Side mirrors............................. 68
Warning light ......................... 318
Driver's seat belt reminder
light ......................................... 318
Driving
Break-in tips .......................... 122
Correct posture ....................... 83
Procedures............................ 120
Winter driving tips ................. 169
Electric power steering
Electric power steering.......... 160
Warning light ......................... 316
Emergency flashers
Switch ................................... 304
Emergency, in case of
If the engine will not start ...... 337
If the shift lever cannot be
shifted from P ..................... 339
If the vehicle battery is
discharged .......................... 341
If the warning buzzer
sounds ................................ 315
