2010 TOYOTA YARIS Engine size

133 2-1. Driving procedures
2
When driving
■Downshifting restrictions
The shift lever cannot be downshifted if the following speeds are exceeded.
mph (km/h)
■If the shift lever cannot be shifted from P (P. 339)
■Shift position uses
*: Shifting to the D position allows the system to select a gear suitable
for the driving conditions. Setting the shift lever to the D position is
recommended for normal driving.
Shift positionFunction
PParking the vehicle or starting the engine
RReversing
NNeutral
DNormal driving*
3Position for engine braking
2Position for more powerful engine braking
LPosition for maximum engine braking
DownshiftingTire sizeMaximum speed
32175/65R14 53 (86)
180/60R15 54 (88)
2L175/65R14 26 (43)
180/60R15 27 (44)

169
2-5. Driving information
2
When driving
Winter driving tips
Carry out the necessary preparations and inspections before driving
the vehicle in winter. Always drive the vehicle in a manner appropri-
ate to the prevailing weather conditions.
■Pre-winter preparations
●Use fluids that are appropriate to the prevailing outside tem-
peratures.
• Engine oil
• Engine coolant
• Washer fluid
●Have a service technician inspect the level and specific grav-
ity of battery electrolyte.
●Have the vehicle fitted with four snow tires or purchase a set
of tire chains for the front tires.
Ensure that all tires are the same size and brand, and that chains
match the size of the tires.
■Before driving the vehicle
Perform the following according to the driving conditions.
●Do not try to forcibly open a window, scrape an outside rear
view mirror surface or move a wiper or outside rear view mir-
ror that is frozen. Pour warm water over the frozen area to
melt the ice. Wipe away the water immediately to prevent it
from freezing.
●To ensure proper operation of the climate control system fan,
remove any snow that has accumulated on the air inlet vents
in front of the windshield.
●Remove any ice that has accumulated on the vehicle chassis.
●Periodically check for and remove any excess ice or snow
that may have accumulated in the wheel well or on the
brakes.

394 Alphabetical index
Seat belts
Adjustment ..............................57
ALR .........................................61
Automatic Locking Retractor ...61
Child restraint system
installation ................... 102, 106
Cleaning and maintaining...... 240
Comfort guide..........................59
ELR .........................................61
Emergency Locking
Retractor .............................. 61
How to wear your seat belt......56
How your child should wear
the seat belt ..........................62
Pregnant women, proper seat
belt use .................................62
Reminder light ....................... 318
Seat belt extenders .................62
Seat belt pretensioners ...........61
Seats
Adjustment ..............................40
Adjustment precautions........... 42
Child seats/child restraint
system installation ...... 102, 106
Cleaning ................................ 238
Folding down the rear seat......45
Folding down the rear seat
precautions ...........................49
Front seat adjustment .............40
Front seat adjustment
precautions ...........................42
Head restraint..........................50
Properly sitting in the seat .......83
Service reminder
indicators .............................. 145
Shift lever
Automatic transmission ......... 132
If the shift lever cannot be
shifted from P...................... 339
Manual transmission ............. 134
Shift lock system..................... 339
Side airbags................................85Side marker lights
Replacing light bulbs ............. 294
Switch ................................... 149
Wattage................................. 360
Side mirror
Adjusting ................................. 68
Defogger ............................... 193
Folding .................................... 69
Spare tire
Identification number............. 364
Inflation pressure .......... 272, 359
Information ............................ 364
Replacing .............................. 325
Size ....................................... 359
Storage location .................... 325
Spark plug ................................ 356
Specifications .......................... 352
Speedometer ............................ 139
Steering wheel
Adjustment .............................. 66
Column lock release ............. 130
Electric power steering.......... 160
EPS ....................................... 160
Specification.......................... 359
Warning light ......................... 316
Stop lights
Replacing light bulbs ............. 294
Wattage................................. 360
Storage features
Auxiliary boxes .............. 220, 225
Bottle holders ................ 220, 223
Cup holders................... 220, 222
Glove boxes .................. 220, 221
Storage precautions ................ 167
Stuck
If the vehicle becomes
stuck ................................... 348
Sun visors ................................ 227
Switch
Cruise control ........................ 156
Emergency flashers
switch.................................. 304
Engine switch ........................ 129S

395 Alphabetical index
Fog lights switch ................... 151
Hazard lights switch ............. 304
Ignition switch ....................... 129
Headlights switch ................. 149
Light switch........................... 149
Power door lock switch........... 32
Power window switch ............. 71
Turn signal lights .................. 135
VSC OFF switch ................... 162
Window lock switch ................ 72
Wiper and washer ........ 152, 155
Tachometer .............................. 139
Tail lights
Indicator................................ 149
Replacing light bulbs ............ 294
Switch ................................... 149
Wattage ................................ 360
Theft deterrent system
Alarm ...................................... 80
Engine immobilizer system..... 78
Theft prevention labels ........... 82
Theft prevention labels ............. 82
Tire inflation pressure ............ 272
Tire information
Glossary ............................... 371
Size ...................................... 368
Tire identification number ..... 367
Uniform tire quality
grading ............................... 369
Tires
Chains .................................. 169
Checking .............................. 266
If you have a flat tire ............. 325
Identification number ............ 364
Inflation pressure .......... 272, 359
Inflation pressure sensor ...... 267
Information ........................... 364
Replacing ..................... 266, 325
Rotating tires ........................ 266
Size ...................................... 359
Snow tires............................. 169
Spare tire .............................. 325Tire pressure warning
system ........................266, 318
Warning light .........................318
Tools .........................................325
Total load capacity...................168
Towing
Dinghy towing................181, 182
Emergency towing.................305
Trailer towing.................172, 173
Trip meter .................................142
Turn signal lights
Indicator ................................135
Lever .....................................135
Replacing light bulbs .............294
Switch....................................135
Wattage .................................360
Vanity mirrors...........................228
Vehicle identification
number ...................................353
Vehicle stability control...........160
VSC............................................160
Warning buzzers
Brake system ........................315
Seat belt reminder .................318
Warning lights
ABS .......................................316
Airbag system .......................316
Anti-lock brake system ..........316
Brake system ........................316
Charging system ...................316
Driver’s seat belt ...................318
Electric power steering
system ................................316
Electronic engine control
system ................................316
Engine oil replacement..........318
EPS system...........................316
Front passenger occupant
classification system ........... 316
Front passenger’s seat belt ...318
T
V
W
