2010 TOYOTA YARIS Owners Manual

217
3-2. Using the audio system
3
Interior features
Using the AUX adapter
: If equipped
■Operating portable audio devices connected to the audio system
The volume can be adjusted using the vehicle’s audio controls. All other
adjustments must be made on the portable audio device itself.
■When using a portable audio device connected to the power outlet
Noise may occur during playback. Use the power source of the portable
audio device.
This adapter can be used to connect a portable audio device and lis-
ten to it through the vehicle’s speakers.
Connect the portable audio
device.
Press .

218
3-3. Using the interior lights
Interior lights list
■Illuminated entry system (if equipped)
When the interior light switch is in the DOOR position, the interior light auto-
matically turns on/off according to whether the doors are locked/unlocked
and whether the doors are open/closed and the engine switch position.
■To prevent the battery from being discharged
If the interior light remains on when the door is not fully closed and the inte-
rior light switch is in the DOOR position, the light will go off automatically
after 20 minutes.
■Customization that can be configured at Toyota dealer
Settings (e.g. The time elapsed before lights turn off) can be changed.
(Customizable features P. 377)
Interior light (P. 219)
Personal lights (P. 219)

219 3-3. Using the interior lights
3
Interior features
Interior light
ON
OFF
DOOR position
Personal lights
On/off
Interior light and personal lights

220
3-4. Using the storage features
List of storage features
CAUTION
■Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
●Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
●Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.
Cup holders
Auxiliary boxes
Glove boxes
Bottle holders

221 3-4. Using the storage features
3
Interior features
Glove boxes
Upper glove box
Pull up the lever.
Lower glove box
Pull up the lever.
CAUTION
■Caution while driving
Keep the glove boxes closed.
Injuries may result in the event of an accident or sudden braking.
Glove boxes

222 3-4. Using the storage features
Cup holders
Front
Pull the lid down.
Rear
Cup holders

223 3-4. Using the storage features
3
Interior features
Bottle holders
Front
Rear (3-door models)
CAUTION
■Items unsuitable for the cup holder
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury. If possible, cover hot drinks to prevent
burns.
■When not in use
Front cup holders: Keep the cup holders closed.
Injuries may result in the event of an accident or sudden braking.
Cup holders and bottle holders

224 3-4. Using the storage features
Rear (5-door models)
■Bottle holders
Depending on their size or shape, some bottles may not fit in the holders.
NOTICE
■Items that should not be stowed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glasses and paper cups containing liquid. The contents may
spill and glasses may break.
Bottle holders
