493
4-3. Do-it-yourself maintenance
4
Maintenance and care
■
Lights other than the above
If any of the lights listed below has burnt out, have it replaced by
your Toyota dealer.
● Headlight low beams (discharge bulbs)
● High mounted stoplight
● Front fog lights (if equipped)
● Outer foot lights (if equipped)
■Condensation build-up on th e inside of the lens
Contact your Toyota dealer for more information in the following situations.
Temporary condensation build-up on the inside of the headlight lens does
not indicate a malfunction.
● Large drops of water are built up on the inside of the lens.
● Water has built up inside the headlight.
■ Discharge headlights
If voltage to the discharge bulbs is insufficient, the bulbs may not come on,
or may go out temporarily. The discharge bulbs will come on when normal
power is restored.
■ LED high mounted stoplight
The high mounted stoplight consists of a number of LEDs. If any of the LEDs
burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 549 of 592
549
6-1. Specifications
6
Vehicle specifications
Light bulbs
A: D2R discharge bulbs
B: HB4 halogen bulbs
C: HB3 halogen bulbs D: Wedge base bulbs (clear)
E: Wedge base bulbs (amber) F: Double end bulbs
Light BulbsBulb No.WTy p e
Exterior Headlights (low beam)
With discharge headlights
Without discharge headlights
9006 35
51A
B
Headlights (high beam) 9005 60 C
Front fog lights 9006 51 B
Front turn signal and parking
lights 3457A 27/7 E
Front side marker lights 5E
Rear turn signal lights 7440 21 D
Stop/tail and rear side marker
lights 7443 21/5 D
Tail lights 194 3.8 D
Back-up lights 921 16 D
License plate lights 5D
Outer foot lights 6D
InteriorFront personal/interior lights
4.9 D
Rear personal/interior lights 5.0 D
Luggage compartment light 5F
Vanity lights 3F
Front door courtesy lights 6F
Sliding door courtesy lights 3.8 D
Page 581 of 592
581
Alphabetical index
Emergency, in case of
If the back door opener is
inoperative ........................... 49
If the engine will not start...... 529
If the shift lever cannot be shifted ................................ 530
If the vehicle has discharged battery ................................ 532
If the warning buzzer sounds... ........................... 504
If the warning light turns
on ....................................... 504
If you have a flat tire .... 515, 516
If you lose your keys/ wireless remote control
transmitter .......................... 531
If you think something is
wrong ................................. 500
If your vehicle becomes stuck................................... 539
If your vehicle needs to be towed ................................. 496
If your vehicle overheats ...... 536
Engine Compartment........................ 438
Engine switch ....................... 167
Hood ..................................... 434
How to start the engine ................................ 167
Identification number ............ 543
If the engine will not start...... 529
Ignition switch ....................... 167
Overheating .......................... 536 Engine coolant
Capacity ................................546
Checking ...............................444
Preparing and checking before winter ..................................226
Engine coolan t temperature
gauge ......................................174
Engine immobilizer system.....111
Engine oil
Capacity ................................545
Checking ...............................439
Preparing and checking before winter ..................................226
Engine oil maintenance
data .........................................442
Event data recorder .................502
Floor mat...................................401
Fluid Brake .....................................446
Power steering ......................448
Washer ..................................453
Fog lights Replacing light bulbs .............486
Switch....................................190
Wattage .................................549
Front automatic air conditioning system..............246E
F
Page 582 of 592
582 Alphabetical index
Front fog lightsReplacing light bulbs ............. 486
Switch.................................... 190
Wattage ................................. 549
Front manual air conditioning
system .................................... 240
Front passenger occupant classification system ............ 130
Front passenger's seat belt reminder light......................... 507
Front seats
Adjustment ..............................56
Front side marker lights Replacing light bulbs ............. 486
Switch.................................... 185
Wattage ................................. 549
Front turn signal lights
Replacing light bulbs ............. 486
Wattage ................................. 549
Fuel
Capacity ................................ 544
Fuel gauge ............................ 174
Fuel pump shut off system .... 501
Gas station information ......... 592
Information ............................ 550
Refueling ............................... 107
Type ...................................... 544
Fuel door................................... 107
Fuel filler door .......................... 107
Fuel pump shut off system ..... 501
Fuses......................................... 474 Garage door opener ................ 405
Garage door opener box ......... 410
Gas station information .......... 592
Gauges...................................... 174
Glove box ................................. 365
Grocery bag hooks .................. 394
Hands-free system
(for cellular phone) ................ 327
Head restraints
Adjusting ................................ 82
Headlights Manual headlight leveling
dial ...................................... 187
Replacing light bulbs ............. 486
Switch ................................... 185
Wattage................................. 549
Heaters Seat heaters.......................... 390
Side mirror ............................ 260
Hood.......................................... 434
Hooks Cargo hooks.......................... 402
Grocery bag hooks................ 394G
H
Page 583 of 592
583
Alphabetical index
I/M test ...................................... 429
Identification
Engine .................................. 543
Vehicle.................................. 543
Ignition switch ......................... 167
Illuminated entry system ........ 361
Indicator lights ........................ 177
Initialization
Items to initialize ................... 568
Inside rear view mirror.............. 95
Interior lights Interior lights ......................... 361
Switch ................................... 362
Wattage ................................ 549
Intuitive parking assist ........... 209
Jack Positioning a floor jack ......... 436
Replacing the wheel ............. 516
Jack handle.............................. 516
Keyless entry ............................. 27
Keys Engine switch ....................... 167
If you lose your keys/
wireless remote control
transmitter .......................... 531
Ignition switch ....................... 167
Keyless entry .......................... 27
Key number ............................ 26
Keys ....................................... 26
Wireless remote control.......... 27 License plate lights
Replacing light bulbs .............486
Wattage .................................549
Light bulbs Replacing ..............................486
Wattage .................................549
Lights Door courtesy lights ..............361
Engine switch light ................361
Fog light switch .....................190
Headlight switch ....................185
Interior light switch ................362
Luggage compartment light .....................................363
Outer foot lights .....................361
Personal light switch .............362
Replacing light bulbs .............486
Turn signal lever....................172
Vanity lights ...........................384
Wattage .................................549
Load capacity ...........................225
Lock steering column ..............167
Luggage compartment light Switch....................................363
Wattage .................................549I
J
K
L
Page 585 of 592
585
Alphabetical index
Rear turn signal lights
Replacing light bulbs ............ 486
Wattage ................................ 549
Rear window defogger............ 260
Rear window wiper.................. 193
Replacing Fuses.................................... 474
Light bulbs ............................ 486
Tires ..................................... 516
Wireless remote control battery ................................ 472
Reporting safety defects for U.S. owners ........................... 570
Roof luggage carrier ............... 219
Seat belts
Adjusting the seat belt ............ 85
Automatic Locking Retractor .............................. 88
Child restraint system installation .......................... 140
Cleaning and maintaining
the seat belts...................... 422
Emergency Locking Retractor .............................. 88
How to wear your seat belt ..... 85
How your child should wear the seat belt ......................... 90
Pregnant women, proper seat belt use ................................ 89
Reminder light ...................... 507
Seat belt extenders ................ 90
Seat belt pretensioners .......... 88
Seat heaters ............................. 390
Seating capacity ...................... 225 Seats
Adjustment ..................56, 59, 61
Adjustment
precaution .................58, 60, 62
Child seats/child restraint
system installation ..............140
Cleaning ................................421
Driver's seat position memory .................................80
Head restraint..........................82
Properly sitting in the seat .....116
Seat heaters ..........................390
Second seats ..............................59
Service reminder indicators ..............................177
Shift lever Automatic transmission .........170
If the shift lever cannot
be shifted from P................. 530
Shift lock system .....................530
Side airbags..............................118
Side marker lights Replacing ..............................486
Switch....................................185
Wattage .................................549
Side mirrors
Adjusting and folding ...............97
Mirror position memory ...........80
Sliding doors
Sliding doors ...........................37
Wireless remote control ..........27
S
Page 586 of 592
586 Alphabetical index
Spare tireInflation pressure................... 548
Spare tire............................... 516
Spark plug ................................ 546
Specifications........................... 542
Speech command switch ........ 332
Speedometer ............................ 174
Steering Column lock release.............. 167
Steering wheel Adjustment ..............................94
Audio switches ...................... 292
Stop lights Replacing light bulbs ............. 486
Wattage ................................. 549
Storage feature......................... 364
Storage precautions ................223
Stuck If your vehicle becomes stuck ................................... 539
Sunshades Rear door .............................. 393
Roof....................................... 105
Sun visors................................. 383
Switch Engine switch ........................ 167
Fog light switch ..................... 190
Ignition switch........................ 167
Light switches........................ 185
Power door lock switch ...........33
Power window switch .... 100, 102
Window lock switch ............... 100
Wiper and washer
switch .......................... 191, 193 Tables
Front seat side table ............. 399
Seatback tables .................... 397
Tachometer .............................. 174
Tail lights Replacing light bulbs ............. 486
Switch ................................... 185
Wattage................................. 549
Talk switch ............................... 332
Telephone switch..................... 332
Theft deterrent system Alarm..................................... 113
Engine immobilizer system ... 111
Theft prevention labels ........... 115
Third seats.................................. 61
Tire inflation pressure ............. 463
Tire information
Glossary ................................ 559
Size ....................................... 548
Tire identification number...... 555
Uniform tire quality grading................................ 557
Tires
Chains ................................... 226
Checking ............................... 454
If you have a flat tire...... 515, 516
Inflation pressure .................. 463
Information ............................ 553
Replacing .............................. 516
Rotating tires ......................... 454
Size ....................................... 548
Snow tires ............................. 226
Tire pressure warning system ........................ 454, 507
Tools ......................................... 516
Total load capacity .................. 225T
