2010 TOYOTA 4RUNNER sensor

455
3-7. Other interior features
3
Interior features
4RUNNER_U
CAUTION
■
While driving the vehicle
Do not adjust the display. Adjust the display only when the vehicle is
stopped.
■ When doing the circling calibration
Secure a wide space, and watch out for people and vehicles in the vicinity.
Do not violate any local traffic rules while performing circling calibration.
NOTICE
■To avoid compass malfunctions
Do not place magnets or any metal objects near the accessory meter dis-
play.
Doing this may cause the compass sensor to malfunction.
■ To ensure normal operation of the compass
● Do not perform a circling calibration of the compass in a place where the
earth's magnetic field is subject to interference by artificial magnetic fields.
● During calibration, do not operate electric systems (moon roof, power win-
dows, etc.) as they may interfere with the calibration.

535
4-3. Do-it-yourself maintenance
4
Maintenance and care
4RUNNER_U
Fuse layout and amperage ratings
■ Engine compartment
FuseAmpereCircuit
1PTC HTR NO.330 A
PTC heater
2DEF30 ARear window defogger
3DEICER 20 A
Windshield wiper de-icer
4PTC HTR NO.230 APTC heater
5SUB BATT30 ATrailer sub battery
6PTC HTR NO.150 A
PTC heater
7MIR HTR10 AOutside rear view mirror defog-
gers
8TOWING TAIL30 A
Trailer tail light
9A/C COMP10 AAir conditioning system
10STOP10 A
Stop/tail lights
11IG220 AINJ, IGN, GAUGE fuses
12HORN10 AHorn(s)
13EFI 25 AMultiport fuel injection system/
sequential multiport fuel injec-
tion system
14A/F20 A
A/F sensor
CTH43AS079

538 4-3. Do-it-yourself maintenance
4RUNNER_U■
Driver’s side instrument panel
FuseAmpereCircuit
1TA I L10 A Stop/tail lights
2PA N E L7.5 A Instrument panel lights
3GAUGE7.5 A Meter and gauge
4IGN10 A Multiport fuel injection system/
sequential multiport fuel injec-
tion system, air bag system,
smart key system
5WASHER20 A Wiper and washer
6WIP30 A Wiper and washer
7S/ROOF 25 A Electric moon roof
8DOOR RR25 A Power windows
9DOOR D25 A Power windows
10DOOR BACK30 A
Multiplex communication sys-
tem
11DOOR P30 A Power windows
12P/SEAT FR 30 A Front passenger's power seat
13S/HTR FR 20 A Seat heater system
14ECU-IG NO.210 AAir conditioning system, multi-
port fuel injection system/
sequential multiport fuel injec-
tion system
15IG17.5 A
Turn signal lights, emergency
flashers
16ECU-IG NO.110 AVehicle stability control sys-
tem, tire pressure warning sys-
tem, steering sensor
17DOOR7.5 A Power windows

5
When trouble arises
563
5-1. Essential information
4RUNNER_U
Event data recorder
In a crash or near crash eventThe SRS airbag sensor assembly co ntains the EDR. In a crash or
near crash event, this device may record some or all of the following
information:
● Gasoline engine speed
● Whether the brake pedal was depressed or not
● Vehicle speed
● To what extent the accelerator pedal was depressed
● Position of the transmission shift lever
● Whether the driver and front passenger wore seat belts or not
● Driver’s seat position
● SRS airbag deployment data
● SRS airbag system diagnostic data
● Front passenger’s occupant classification
The information above is intended to be used for the purpose of
improving vehicle safety performance. Unlike general data recorders,
the EDR does not record sound data such as conversation between
passengers.
Your vehicle has computers that monitor and control certain aspects
of your vehicle. These computers assi st in driving and maintaining
optimal vehicle performance.
Besides storing data useful for tr oubleshooting, there is an event
data recorder (EDR) that records data in a crash or near crash
event.

572 5-2. Steps to take in an emergency
4RUNNER_U
■SRS warning light
This warning light system monitors the airbag sensor assembly, front airbag
sensors, side and curtain shield airbag sensors, curtain shield airbag sen-
sors, floor sensor, driver's seat belt buckle switch, front passenger occupant
classification system, SRS airbag on-off indicator, roll sensing of curtain
shield airbags off indicator, front passenger's seat belt buckle switch, seat
belt pretensioner assemblies, inflators, interconnecting wiring and power
sources. ( P. 114)
■ Key reminder buzzer (vehicl es without a smart key system)
The buzzer indicates that the key has not been removed with the engine off
and the driver’s door opened.
■ Open moon roof reminder buzzer (if equipped)
The buzzer indicates that the moon roof is not fully closed with the engine off
and the driver’s door opened.
■ Front passenger detection sensor, passenger seat belt reminder and
warning buzzer
● If luggage is placed on the front passenger seat, the front passenger
detection sensor may cause the warning light to flash and the warning
buzzer to sound even if a passenger is not sitting in the seat.
● If a cushion is placed on the seat, the sensor may not detect a passen-
ger, and the warning light may not operate properly.
■ If the malfunction indicator lamp comes on while driving
First check the following:
● Is the fuel tank empty?
If it is, fill the fuel tank immediately.
● Is the fuel tank cap loose?
If it is, tighten it securely.
The light will go off after several driving trips.
If the light does not go off even after several trips, contact your Toyota dealer
as soon as possible.

639
6-2. Customization
6
Vehicle specifications
4RUNNER_U
Door lock
(
P. 51,
596) Speed-detecting auto-
matic door lock function
Off On
Shifting the shift lever to
position other than P
locks all doors On Off
Shifting the shift lever to
P unlocks all doors On Off
Opening driver’s door
unlocks all doors Off On
Power win-
dows
( P. 91) Mechanical key linked
operation (close)
Off On
Mechanical key linked
operation (open) Off On
Wireless remote control
linked operation (open) Off On
Wireless remote control
linked operation signal
(Buzzer) On Off
Automatic
light control
system
( P. 198) Light sensor sensitivity Level 3 Levels 1 to 5
Time elapsed before
headlights automati-
cally turn off after doors
are closed
30 secondsOff
60 seconds
90 seconds
Ambient light level at
which instrument illumi-
nation begins to dim
(meter lights etc.) Standard
-2 (darker) to
2 (brighter)
Ambient light level at
which instrument illumi-
nation begins to
brighten (meter lights
etc.) Standard
-2 (darker) to
2 (brighter)
ItemFunctionDefault settingCustomized setting

659
Alphabetical index
4RUNNER_U
Specifications .......................... 610
Speech command switch ....... 385
Speedometer ........................... 182
Steering
Column lock release ..... 165, 170
Fluid...................................... 507
Steering wheel Adjustment ............................. 86
Audio switches ..................... 361
Stop lights Replacing light bulbs ............ 541
Wattage ................................ 622
Storage compartment ............. 458
Storage feature ........................ 416
Storage precautions ............... 270
Stuck If your vehicle becomes stuck................................... 606
Sun visors ................................ 429
Sunshade Roof ........................................ 98
Switch
Emergency flasher switch .... 554
Engine switch ............... 164, 167
Fog light switch..................... 204
Hazard light switch ............... 554
Ignition switch ............... 164, 167
Light switches ....................... 198
Power back window switch..... 94
Power door lock switch........... 52
Power window switch ............. 91
Rear window wiper and washer switch .................... 207
Window lock switch ................ 91
Wiper and washer switch ..... 205 Tachometer
Tachometer ...........................182
Tail lights
Replacing light bulbs .............541
Switch....................................198
Wattage .................................622
Talk switch................................385
Telephone switch .....................385
Theft deterrent system Alarm .....................................109
Engine immobilizer system ...106
Theft prevention labels............111
Tire inflation pressure .............520
Tire information Glossary ................................631
Size .......................................628
Tire identification number ......627
Uniform tire quality grading ...629
Tires Chains ...................................275
Checking ...............................514
If you have a flat tire ..............578
Inflation pressure...................520
Inflation pressure sensor .......514
Information ............................626
Replacing ..............................578
Rotating tires .........................514
Size .......................................621
Snow tires .............................275
Spare tire...............................578
Tissue pocket ...........................420
Tools .........................................578
Total load capacity...................273
Towing
Dinghy towing........................293
Emergency towing.................555
Trailer towing.........................280
TRAC (TRC) ..............................253
Traction control........................253
Trip information .......................194
Trip meter .................................182T
