PETROL INJECTION
Fault finding - Conformity check
17B
17B-140
PETROL INJECTION
Fault finding - Conformity check
17B
17B-140V9 MR-372-J84-17B050$470.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
CRUISE CONTROL/SPEED LIMITER SUB-FUNCTION:
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine off, ignition on.
Order FunctionParameter or Status
Checked or ActionDisplay and notes Fault finding
1
Cruise control/
Speed limiterET042:Cruise control/
Speed limiterNOT DETECTED
INACTIVE
CRUISE CONTROL
SPEED LIMITERIn the event of a fault,
apply the
interpretation of
ET042 Cruise
control/speed
limiter.
2ET415:Deactivation of
cruise control/
speed limiterWITHOUT
STATUS 1: Traction
control request
STATUS 2: Brake pedal
depressed
STATUS 3: Clutch pedal
depressed
STATUS 4: Suspend
button pressed
STATUS 5: Cruise control
or speed limiter monitoring
STATUS 6: Gear lever in
neutral (manual gearbox)
or neutral position
(automatic transmission)
STATUS 7: Inconsistency
between the request and
the vehicle speed
STATUS 8: Automatic
transmission in defect
mode
STATUS 9: Vehicle speed
monitoring
STATUS 10: Monitoring
by injection computerIn the event of a fault,
apply the
interpretation of
ET415 Cruise
control/Speed
limiter deactivation.
3ET703:Cruise control/
speed limiter
buttonsINACTIVE
DECREASE
INCREASE
SUSPEND
RESUMEIn the event of a fault,
apply the
interpretation of status
ET703 Cruise
control/speed limiter
buttons.

PETROL INJECTION
Fault finding - Conformity check
17B
17B-164
PETROL INJECTION
Fault finding - Conformity check
17B
17B-164V9 MR-372-J84-17B050$517.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
CRUISE CONTROL/SPEED LIMITER SUB-FUNCTION:
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine warm, idling.
Order FunctionParameter or Status
Checked or ActionDisplay and notes Fault finding
1
Cruise control/
Speed limiterET042:Cruise control/
Speed limiterNOT DETECTED
INACTIVE
CRUISE CONTROL
SPEED LIMITERIn the event of a fault,
apply the
interpretation of
ET042 Cruise
control/speed
limiter.
2ET415:Deactivation of
cruise control/
speed limiterWITHOUT
STATUS 1: Traction
control request
STATUS 2: Brake pedal
depressed
STATUS 3: Clutch pedal
depressed
STATUS 4: Suspend
button pressed
STATUS 5: Cruise control
or speed limiter monitoring
STATUS 6: Gear lever in
neutral (manual gearbox)
or neutral position
(automatic transmission)
STATUS 7: Inconsistency
between the request and
the vehicle speed
STATUS 8: Automatic
transmission in defect
mode
STATUS 9: Vehicle speed
monitoring
STATUS 10: Monitoring
by injection computerIn the event of a fault,
apply the
interpretation of
ET415 Cruise
control/Speed
limiter deactivation.
3ET703:Cruise control/
speed limiter
buttonsINACTIVE
DECREASE
INCREASE
SUSPEND
RESUMEIn the event of a fault,
apply the
interpretation of status
ET703 Cruise
control/speed limiter
buttons.

PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 186
PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 186V9 MR-372-J84-17B050$611.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
ET415
CRUISE CONTROL/SPEED LIMITER DEACTIVATION
NOTESSpecial notes:
Only perform the tests if the statuses do not correspond with the system programming
functions.
Note:
Cruise control can be activated when the vehicle speed exceeds 18 mph (30 km/h).
Status ET415 displays the various reasons for deactivation of the cruise control/speed limiter function, which are
due to driver demand or the exterior environment.
IMPORTANT
Clear the fault memory by running command RZ001 "Fault memory", to reset this status to "NONE".
NONEThis status is present on the diagnostic tool when:
The computer has been reinitialised.
The computer has been reprogrammed
STATUS 1Traction control request
If the vehicle is fitted with a traction control system, the cruise control function is
deactivated every time the ABS computer calls for traction control.
Status ET415 becomes STATUS 1 when driving with the cruise control active (ET042
Cruise control/Speed limiter: CRUISE CONTROL) and traction control is requested.
This deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command RZ001
"Fault memory".
If status ET415 becomes STATUS 1 with no traction control request (see 38C, Anti-lock
Braking System).
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool
S3000_V4C_ET415/S3000_V54_ET415
