2010 PONTIAC G6 rear view mirror

In Brief........................................................... 1-1
Instrument Panel
........................................ 1-2
Initial Drive Information
............................... 1-4
Vehicle Features
......................................1-14
Performance and Maintenance
...................1-18
Seats and Restraint System............................. 2-1
Head Restraints
......................................... 2-2
Front Seats
............................................... 2-4
Rear Seats
..............................................2-13
Safety Belts
.............................................2-14
Child Restraints
.......................................2-36
Airbag System
.........................................2-59
Restraint System Check
............................2-74
Features and Controls..................................... 3-1
Keys
........................................................ 3-2
Doors and Locks
....................................... 3-8
Windows
.................................................3-13
Theft-Deterrent Systems
............................3-16
Starting and Operating Your Vehicle
...........3-20
Mirrors
....................................................3-34Storage Areas
.........................................3-37
Sunroof
..................................................3-37
Retractable Hardtop
..................................3-38
Instrument Panel............................................. 4-1
Instrument Panel Overview
.......................... 4-3
Climate Controls
......................................4-16
Warning Lights, Gages, and Indicators
........4-24
Driver Information Center (DIC)
..................4-39
Audio System(s)
.......................................4-53
Driving Your Vehicle....................................... 5-1
Your Driving, the Road, and the Vehicle
....... 5-2
Towing
...................................................5-23
Service and Appearance Care.......................... 6-1
Service
..................................................... 6-4
Fuel
......................................................... 6-6
Checking Things Under
the Hood
.............................................6-14
Headlamp Aiming
.....................................6-47
Bulb Replacement
....................................6-47
2010 Pontiac G6 Owner ManualM

Mirror Adjustment
Exterior Mirrors
Controls for the outside
power mirrors are located
on the driver door.
1. Move the selector switch located below the four-way
control pad to the left or right to choose either the
driver side or passenger side mirror.
2. Press one of the four arrows located on the control
pad to move the mirror to the desired direction.
Keep the selector switch in the center position when not
adjusting either outside mirror.Manually fold the mirrors inward to prevent damage
when going through an automatic car wash. To fold, push
the mirror toward the vehicle. Push the mirror outward, to
return to its original position.
SeeOutside Power Mirrors on page 3-36.
Interior Mirror
Adjust the mirror to see clearly behind your vehicle. Hold
the mirror in the center to move it up or down and side to
side. To reduce headlamp glare during nighttime use,
move the lever at the bottom of the mirror to the right.
Move it to the left for daytime use.
SeeManual Rearview Mirror on page 3-34.
Vehicles with an automatic dimming rearview mirror will
automatically reduce the glare from the headlamps of the
vehicle behind. The dimming feature comes on and the
indicator light illuminates each time the ignition is turned
to start.
SeeAutomatic Dimming Rearview Mirror on page 3-34.
1-10

Keys...............................................................3-2
Remote Keyless Entry (RKE) System................3-3
Remote Keyless Entry (RKE) System
Operation...................................................3-3
Remote Vehicle Start......................................3-5
Doors and Locks.............................................3-8
Door Locks....................................................3-8
Power Door Locks..........................................3-8
Door Ajar Reminder........................................3-9
Delayed Locking.............................................3-9
Automatic Door Lock.......................................3-9
Programmable Automatic Door Unlock.............3-10
Rear Door Security Locks..............................3-10
Lockout Protection........................................3-11
Trunk..........................................................3-11
Windows........................................................3-13
Power Windows............................................3-14
Sun Visors...................................................3-16
Theft-Deterrent Systems..................................3-16
Content Theft-Deterrent.................................3-16
PASS-Key
®III+ Electronic Immobilizer.............3-18
PASS-Key®III+ Electronic Immobilizer
Operation.................................................3-18
Starting and Operating Your Vehicle................3-20
New Vehicle Break-In....................................3-20
Ignition Positions..........................................3-20
Retained Accessory Power (RAP)...................3-21Starting the Engine.......................................3-21
Engine Coolant Heater..................................3-23
Automatic Transmission Operation...................3-24
Parking Brake..............................................3-29
Shifting Into Park (Automatic Transmission)......3-30
Shifting Out of Park......................................3-31
Parking Over Things That Burn.......................3-32
Engine Exhaust............................................3-32
Running the Vehicle While Parked..................3-33
Mirrors...........................................................3-34
Manual Rearview Mirror.................................3-34
Automatic Dimming Rearview Mirror................3-34
Compass.....................................................3-35
Outside Power Mirrors...................................3-36
Outside Convex Mirror...................................3-36
Storage Areas................................................3-37
Glove Box...................................................3-37
Cupholders..................................................3-37
Center Console Storage.................................3-37
Convenience Net..........................................3-37
Sunroof.........................................................3-37
Retractable Hardtop........................................3-38
Lowering the Retractable Hardtop...................3-38
Raising the Retractable Hardtop......................3-41
Section 3 Features and Controls
3-1

Mirrors
Manual Rearview Mirror
The vehicle may have a manual inside rearview mirror
with the OnStar®system.
Vehicles with OnStar have three additional control
buttons located at the bottom of the mirror. See your
dealer/retailer for more information on the OnStar
system and how to subscribe to OnStar. Also, see the
OnStar
®owners guide for more information about
the services OnStar provides.
Adjust the mirror to see clearly behind your vehicle. Hold
the mirror in the center to move it up or down and side to
side. Adjust the mirror to avoid glare from the headlamps
behind your vehicle. Move the lever to the right for
nighttime use and to the left for daytime use.
Automatic Dimming Rearview Mirror
The vehicle may have an automatic dimming rearview
mirror with a compass display and/or OnStar®controls.
For more information about OnStar, see the OnStar®
owners guide.
Vehicles with OnStar have three additional control
buttons located at the bottom of the mirror. See your
dealer/retailer for more information on the system
and how to subscribe to OnStar. See the OnStar
®
owners guide for more information about the service
OnStar provides.
For vehicles with OnStar:
O(On/Off):Press to turn the dimming feature on or off.
For vehicles without OnStar:
AUTO/OFF:Press AUTO/OFF to turn the dimming
feature on or off.
Automatic Dimming Mirror Operation
Automatic dimming reduces the glare of lights from
behind the vehicle. The dimming feature comes on and
the indicator light illuminates each time the vehicle is
started.
3-34

While driving on a surface with reduced traction,
try your best to avoid sudden steering, acceleration,
or braking, including reducing vehicle speed by shifting to
a lower gear. Any sudden changes could cause the tires
to slide. You may not realize the surface is slippery until
the vehicle is skidding. Learn to recognize warning
clues — such as enough water, ice, or packed snow on
the road to make a mirrored surface — and slow down
when you have any doubt.
If the vehicle has the Antilock Brake System (ABS),
remember: It helps avoid only the braking skid. If the
vehicle does not have ABS, then in a braking skid,
where the wheels are no longer rolling, release enough
pressure on the brakes to get the wheels rolling again.
This restores steering control. Push the brake pedal down
steadily when you have to stop suddenly. As long as the
wheels are rolling, you will have steering control.Driving at Night
Night driving is more dangerous than day driving
because some drivers are likely to be impaired — by
alcohol or drugs, with night vision problems, or by
fatigue.
Night driving tips include:
•Drive defensively.
•Do not drink and drive.
•Reduce headlamp glare by adjusting the inside
rearview mirror.
•Slow down and keep more space between you and
other vehicles because headlamps can only light up
so much road ahead.
•Watch for animals.
•When tired, pull off the road.
•Do not wear sunglasses.
•Avoid staring directly into approaching headlamps.
•Keep the windshield and all glass on your vehicle
clean — inside and out.
•Keep your eyes moving, especially during turns or
curves.
5-11

Other Rainy Weather Tips
Besides slowing down, other wet weather driving tips
include:
•Allow extra following distance.
•Pass with caution.
•Keep windshield wiping equipment in good shape.
•Keep the windshield washer fluid reservoir filled.
•Have good tires with proper tread depth.
SeeTires on page 6-56.
•Turn off cruise control.
Before Leaving on a Long Trip
To prepare your vehicle for a long trip, consider having
it serviced by your dealer/retailer before departing.
Things to check on your own include:
•Windshield Washer Fluid:Reservoir full? Windows
clean — inside and outside?
•Wiper Blades:In good shape?
•Fuel, Engine Oil, Other Fluids:All levels checked?
•Lamps:Do they all work and are lenses clean?
•Tires:Are treads good? Are tires inflated to
recommended pressure?
•Weather and Maps:Safe to travel?
Have up-to-date maps?
Highway Hypnosis
Always be alert and pay attention to your surroundings
while driving. If you become tired or sleepy, find a
safe place to park your vehicle and rest.
Other driving tips include:
•Keep the vehicle well ventilated.
•Keep interior temperature cool.
•Keep your eyes moving — scan the road ahead
and to the sides.
•Check the rearview mirror and vehicle instruments
often.
5-13

Fuses Usage
EPS Electronic Power Steering
FUSE PULLER Fuse Puller
HVAC
BLOWERHeating Ventilation Air Conditioning
Blower Switch
HVAC
BLOWER HIGHHeating Ventilation Air Conditioning
Blower - High Speed Relay
HVAC CTRL
(BATT)Heating Ventilation Air Conditioning
Control Diagnostic Link Connector
(Battery)
HVAC CTRL
(IGN)Heating Ventilation Air Conditioning
Control (Ignition)
IGN SENSOR Ignition Switch
INTERIOR
LIGHTSInterior Lamps
NOT
INSTALLEDNot Used
NOT
INSTALLEDNot UsedFuses Usage
NOT
INSTALLEDNot Used
NOT
INSTALLEDNot Used
ONSTAR OnStar
®
PEDAL Not Used
POWER
MIRRORSPower Mirrors
POWER
WINDOWSPower Windows (Sedan)
RADIO Audio System
ROOF/HEAT
SEATSunroof, Heated Seat, Power
Windows (Coupe, Retractable
Hardtop), Automatic Dimming
Rearview Mirror, Compass
RUN/CRANKCruise Control Switch, Passenger
Airbag Status Indicator, DSC Switch
6-118

Mirrors
Automatic Dimming Rearview........................3-34
Manual Rearview.........................................3-34
Outside Convex Mirror.................................3-36
Outside Power Mirrors..................................3-36
MP3 .............................................................4-63
Muting a Call.................................................4-79
My GM Canada (Canada) — www.gm.ca............. 8-5
N
Net, Convenience...........................................3-37
New Vehicle Break-In......................................3-20
O
Odometer......................................................4-26
Trip ...........................................................4-26
Off-Road
Recovery..................................................... 5-9
Oil
Engine.......................................................6-21
Engine Oil Life System.................................6-24
Pressure Light.............................................4-37
Older Children, Restraints................................2-36
Online Owner Center........................................ 8-5
Online Owner Center (U.S.) —
www.gmownercenter.com/pontiac..................... 8-5OnStar, Privacy..............................................8-18
OnStar Steering Wheel Controls........................1-24
Operation Tips................................................4-24
Other Information............................................4-81
Other Rainy Weather Tips................................5-13
Outlet Adjustment............................................4-24
Outlets
Accessory Power.........................................4-15
Outside
Convex Mirror.............................................3-36
Power Mirrors.............................................3-36
Overheated Engine Protection Operating Mode.....6-37
Overseas — Customer Assistance...................... 8-6
Owner Checks and Services.............................. 7-8
Owner Information...........................................8-15
Owners, Canadian.............................................. iiiP
Paint, Damage..............................................6-113
Pairing..........................................................4-72
Parade Dimming.............................................4-14
Park
Headlamps Off in Park.................................4-11
Shifting Into................................................3-30
Shifting Out of............................................3-31
Parking
Brake........................................................3-29
Over Things That Burn.................................3-32
11
