2010 PONTIAC G6 mirror controls

In Brief........................................................... 1-1
Instrument Panel
........................................ 1-2
Initial Drive Information
............................... 1-4
Vehicle Features
......................................1-14
Performance and Maintenance
...................1-18
Seats and Restraint System............................. 2-1
Head Restraints
......................................... 2-2
Front Seats
............................................... 2-4
Rear Seats
..............................................2-13
Safety Belts
.............................................2-14
Child Restraints
.......................................2-36
Airbag System
.........................................2-59
Restraint System Check
............................2-74
Features and Controls..................................... 3-1
Keys
........................................................ 3-2
Doors and Locks
....................................... 3-8
Windows
.................................................3-13
Theft-Deterrent Systems
............................3-16
Starting and Operating Your Vehicle
...........3-20
Mirrors
....................................................3-34Storage Areas
.........................................3-37
Sunroof
..................................................3-37
Retractable Hardtop
..................................3-38
Instrument Panel............................................. 4-1
Instrument Panel Overview
.......................... 4-3
Climate Controls
......................................4-16
Warning Lights, Gages, and Indicators
........4-24
Driver Information Center (DIC)
..................4-39
Audio System(s)
.......................................4-53
Driving Your Vehicle....................................... 5-1
Your Driving, the Road, and the Vehicle
....... 5-2
Towing
...................................................5-23
Service and Appearance Care.......................... 6-1
Service
..................................................... 6-4
Fuel
......................................................... 6-6
Checking Things Under
the Hood
.............................................6-14
Headlamp Aiming
.....................................6-47
Bulb Replacement
....................................6-47
2010 Pontiac G6 Owner ManualM

Instrument Panel..............................................1-2
Initial Drive Information....................................1-4
Remote Keyless Entry (RKE) System................1-4
Remote Vehicle Start......................................1-4
Door Locks....................................................1-5
Trunk Release...............................................1-5
Windows.......................................................1-6
Seat Adjustment.............................................1-6
Safety Belt....................................................1-9
Sensing System for Passenger Airbag...............1-9
Mirror Adjustment.........................................1-10
Steering Wheel Adjustment............................1-11
Interior Lighting............................................1-11
Exterior Lighting...........................................1-12
Windshield Wiper/Washer...............................1-12
Climate Controls...........................................1-13Vehicle Features.............................................1-14
Radio(s)......................................................1-14
Satellite Radio..............................................1-15
Portable Audio Devices..................................1-15
Steering Wheel Controls................................1-16
Bluetooth
®...................................................1-16
Cruise Control..............................................1-17
Power Outlets..............................................1-17
Performance and Maintenance.........................1-18
Traction Control System (TCS).......................1-18
Electronic Stability Control (ESC)....................1-18
Tire Pressure Monitor....................................1-19
Tire Sealant and Compressor Kit....................1-19
Engine Oil Life System..................................1-20
Fuel E85 (85% Ethanol)................................1-20
Driving for Better Fuel Economy.....................1-21
Roadside Assistance Program........................1-21
OnStar
®......................................................1-22
Section 1 In Brief
1-1

Mirror Adjustment
Exterior Mirrors
Controls for the outside
power mirrors are located
on the driver door.
1. Move the selector switch located below the four-way
control pad to the left or right to choose either the
driver side or passenger side mirror.
2. Press one of the four arrows located on the control
pad to move the mirror to the desired direction.
Keep the selector switch in the center position when not
adjusting either outside mirror.Manually fold the mirrors inward to prevent damage
when going through an automatic car wash. To fold, push
the mirror toward the vehicle. Push the mirror outward, to
return to its original position.
SeeOutside Power Mirrors on page 3-36.
Interior Mirror
Adjust the mirror to see clearly behind your vehicle. Hold
the mirror in the center to move it up or down and side to
side. To reduce headlamp glare during nighttime use,
move the lever at the bottom of the mirror to the right.
Move it to the left for daytime use.
SeeManual Rearview Mirror on page 3-34.
Vehicles with an automatic dimming rearview mirror will
automatically reduce the glare from the headlamps of the
vehicle behind. The dimming feature comes on and the
indicator light illuminates each time the ignition is turned
to start.
SeeAutomatic Dimming Rearview Mirror on page 3-34.
1-10

Keys...............................................................3-2
Remote Keyless Entry (RKE) System................3-3
Remote Keyless Entry (RKE) System
Operation...................................................3-3
Remote Vehicle Start......................................3-5
Doors and Locks.............................................3-8
Door Locks....................................................3-8
Power Door Locks..........................................3-8
Door Ajar Reminder........................................3-9
Delayed Locking.............................................3-9
Automatic Door Lock.......................................3-9
Programmable Automatic Door Unlock.............3-10
Rear Door Security Locks..............................3-10
Lockout Protection........................................3-11
Trunk..........................................................3-11
Windows........................................................3-13
Power Windows............................................3-14
Sun Visors...................................................3-16
Theft-Deterrent Systems..................................3-16
Content Theft-Deterrent.................................3-16
PASS-Key
®III+ Electronic Immobilizer.............3-18
PASS-Key®III+ Electronic Immobilizer
Operation.................................................3-18
Starting and Operating Your Vehicle................3-20
New Vehicle Break-In....................................3-20
Ignition Positions..........................................3-20
Retained Accessory Power (RAP)...................3-21Starting the Engine.......................................3-21
Engine Coolant Heater..................................3-23
Automatic Transmission Operation...................3-24
Parking Brake..............................................3-29
Shifting Into Park (Automatic Transmission)......3-30
Shifting Out of Park......................................3-31
Parking Over Things That Burn.......................3-32
Engine Exhaust............................................3-32
Running the Vehicle While Parked..................3-33
Mirrors...........................................................3-34
Manual Rearview Mirror.................................3-34
Automatic Dimming Rearview Mirror................3-34
Compass.....................................................3-35
Outside Power Mirrors...................................3-36
Outside Convex Mirror...................................3-36
Storage Areas................................................3-37
Glove Box...................................................3-37
Cupholders..................................................3-37
Center Console Storage.................................3-37
Convenience Net..........................................3-37
Sunroof.........................................................3-37
Retractable Hardtop........................................3-38
Lowering the Retractable Hardtop...................3-38
Raising the Retractable Hardtop......................3-41
Section 3 Features and Controls
3-1

Mirrors
Manual Rearview Mirror
The vehicle may have a manual inside rearview mirror
with the OnStar®system.
Vehicles with OnStar have three additional control
buttons located at the bottom of the mirror. See your
dealer/retailer for more information on the OnStar
system and how to subscribe to OnStar. Also, see the
OnStar
®owners guide for more information about
the services OnStar provides.
Adjust the mirror to see clearly behind your vehicle. Hold
the mirror in the center to move it up or down and side to
side. Adjust the mirror to avoid glare from the headlamps
behind your vehicle. Move the lever to the right for
nighttime use and to the left for daytime use.
Automatic Dimming Rearview Mirror
The vehicle may have an automatic dimming rearview
mirror with a compass display and/or OnStar®controls.
For more information about OnStar, see the OnStar®
owners guide.
Vehicles with OnStar have three additional control
buttons located at the bottom of the mirror. See your
dealer/retailer for more information on the system
and how to subscribe to OnStar. See the OnStar
®
owners guide for more information about the service
OnStar provides.
For vehicles with OnStar:
O(On/Off):Press to turn the dimming feature on or off.
For vehicles without OnStar:
AUTO/OFF:Press AUTO/OFF to turn the dimming
feature on or off.
Automatic Dimming Mirror Operation
Automatic dimming reduces the glare of lights from
behind the vehicle. The dimming feature comes on and
the indicator light illuminates each time the vehicle is
started.
3-34

Outside Power Mirrors
Controls for the outside
power mirrors are located
on the driver door.
To adjust the mirrors:
1. Move the selector switch located below the four-way
control pad to the left or right to choose either the
driver side or passenger side mirror.
2. Press one of the four arrows located on the control
pad to move the mirror to the desired direction.
3. Adjust each outside mirror so that a little of the
vehicle and the area behind it can be seen.
Keep the selector switch in the center position when not
adjusting either outside mirror.Manually fold the mirrors inward to prevent damage
when going through an automatic car wash. To
fold, push the mirror toward the vehicle. Push the
mirror outward, to return to its original position.
Outside Convex Mirror
{WARNING:
A convex mirror can make things, like other
vehicles, look farther away than they really are.
If you cut too sharply into the right lane, you could
hit a vehicle on the right. Check the inside mirror
or glance over your shoulder before changing
lanes.
The passenger side mirror is convex shaped. A convex
mirror’s surface is curved so more can be seen from
the driver seat.
3-36

Audio System.........................................4-53, 4-72
Audio Steering
Wheel Controls........................................4-82
Radio Reception..........................................4-83
Setting the Clock.........................................4-53
Theft-Deterrent Feature................................4-81
XM™ Satellite Radio Antenna System............4-84
Audio System(s).............................................4-54
Automatic Climate Control System.....................4-20
Automatic Dimming Mirror Operation..................3-34
Automatic Door Lock......................................... 3-9
Automatic Headlamp System............................4-12
Automatic Transmission
Fluid..................................................6-27, 6-28
Operation...................................................3-24
Automatic Transmission Shift Lock Control
System Check.............................................. 7-8
B
Backglass Antenna..........................................4-84
Backing Up....................................................5-31
Battery..........................................................6-42
Electric Power Management..........................4-14
Run-Down Protection...................................4-15
Battery Replacement......................................... 3-5
Belt Routing, Engine.......................................7-12
Bench Seat, Split (60/40).................................2-13Blizzard Conditions..........................................5-16
Bluetooth Controls...........................................4-72
Bluetooth
®.....................................................4-71
Brake
Emergencies................................................ 5-5
Brake Adjustment............................................6-41
Brake Fluid....................................................6-39
Brake Pedal Travel.........................................6-41
Brake Wear...................................................6-41
Brakes..........................................................6-39
Antilock....................................................... 5-4
Parking......................................................3-29
System Warning Light..................................4-30
Braking........................................................... 5-3
Braking in Emergencies..................................... 5-5
Break-In, New Vehicle.....................................3-20
Bulb Replacement...........................................6-54
Center High-Mounted Stoplamp
(CHMSL) ........................................6-49, 6-50
Fog Lamps .................................................4-12
Halogen Bulbs............................................6-47
Headlamp Aiming........................................6-47
Headlamps.................................................6-47
Headlamps, Front Turn Signal, Sidemarker,
and Parking Lamps..................................6-48
License Plate Lamps....................................6-54
Taillamps, Turn Signal, Sidemarker, Stoplamps,
and Back-Up Lamps.................6-50, 6-51, 6-53
Buying New Tires...........................................6-75
2

Mirrors
Automatic Dimming Rearview........................3-34
Manual Rearview.........................................3-34
Outside Convex Mirror.................................3-36
Outside Power Mirrors..................................3-36
MP3 .............................................................4-63
Muting a Call.................................................4-79
My GM Canada (Canada) — www.gm.ca............. 8-5
N
Net, Convenience...........................................3-37
New Vehicle Break-In......................................3-20
O
Odometer......................................................4-26
Trip ...........................................................4-26
Off-Road
Recovery..................................................... 5-9
Oil
Engine.......................................................6-21
Engine Oil Life System.................................6-24
Pressure Light.............................................4-37
Older Children, Restraints................................2-36
Online Owner Center........................................ 8-5
Online Owner Center (U.S.) —
www.gmownercenter.com/pontiac..................... 8-5OnStar, Privacy..............................................8-18
OnStar Steering Wheel Controls........................1-24
Operation Tips................................................4-24
Other Information............................................4-81
Other Rainy Weather Tips................................5-13
Outlet Adjustment............................................4-24
Outlets
Accessory Power.........................................4-15
Outside
Convex Mirror.............................................3-36
Power Mirrors.............................................3-36
Overheated Engine Protection Operating Mode.....6-37
Overseas — Customer Assistance...................... 8-6
Owner Checks and Services.............................. 7-8
Owner Information...........................................8-15
Owners, Canadian.............................................. iiiP
Paint, Damage..............................................6-113
Pairing..........................................................4-72
Parade Dimming.............................................4-14
Park
Headlamps Off in Park.................................4-11
Shifting Into................................................3-30
Shifting Out of............................................3-31
Parking
Brake........................................................3-29
Over Things That Burn.................................3-32
11
