Instruments and controls Trip recorder zero
reset button
After this operation, if you wish
to disconnect the battery, lock
the vehicle and wait for at least
fi v e m i n u t e s , o t h e r w i s e t h e z e r o r e - s e t
will not be registered.
Zero re-set
Your PEUGEOT dealer carries out this
operation after each service.
However, if you carry out the service
yourself, the re-set procedure is as
follows:
- switch off the ignition,
- press and hold the trip recorder
reset button,
- switch on the ignition.
The display begins a countdown.
When the display shows "=0" , release
the button; the spanner disappears.
Engine oil level indicator
When the ignition is switched on,
the engine oil level is indicated for
a few seconds, after the service
information. Oil level correct
Lack of oil
Flashing of
"OIL" ,
linked with the
service warning light,
accompanied by an
audible signal and a message on the
display, indicates a lack of oil which
could damage the engine.
I f t h e l a c k o f o i l i s c o n fi r m e d b y a c h e c k
using the dipstick, it is essential that
the level is topped up.
Oil level gauge fault
Flashing of "OIL --"
indicates a malfunc-
tion of the engine oil
level gauge. Consult a
PEUGEOT dealer.
The level read will only be correct
if the vehicle is on level ground
and the engine has been off for
more than 15 minutes. Dipstick
A = m a x i m u m , n e v e r e x c e e d
this level as a surplus of oil
may damage the engine.
Contact a PEUGEOT dealer
without delay.
B = minimum, top up the level
v i a t h e o i l fi l l e r c a p , u s i n g
the type of oil suited to your
engine.
With the lights on, press
the button to vary the
intensity of the lighting
of the instruments and
controls. When the lighting
reaches the minimum
( o r m a x i m u m ) s e t t i n g ,
release the button then press it again
to increase (or reduce) the brightness.
As soon as the lighting is of the
required brightness, release the button. With the ignition on, press
the button until the zeros
appear.
Lighting rheostat
99
6
Levels
LEVELS
Oil change
It is imperative that this is carried
o u t a t t h e i n t e r v a l s s p e c i fi e d a n d t h e
viscosity grade of the oil selected must
f u l fi l t h e r e q u i r e m e n t s i n a c c o r d a n c e
with the manufacturer's servicing
schedule. Consult the instructions at a
PEUGEOT dealer.
R e m o v e t h e d i p s t i c k b e f o r e fi l l i n g .
C h e c k t h e l e v e l a f t e r fi l l i n g ( n e v e r
e x c e e d t h e m a x m a r k ) .
S c r e w t h e c a p b a c k o n t o t h e s u m p
before closing the bonnet. Changing the brake fluid
T h e b r a k e fl u i d m u s t b e c h a n g e d a t
the intervals stated, according to the
manufacturer's servicing schedule.
U s e fl u i d s r e c o m m e n d e d b y t h e
m a n u f a c t u r e r , w h i c h f u l fi l D O T 4
standards.
T h e l e v e l m u s t b e b e t w e e n t h e M I N
a n d M A X m a r k s o n t h e r e s e r v o i r .
I f fl u i d h a s t o b e a d d e d f r e q u e n t l y ,
this indicates a failure which must be
c h e c k e d b y a P E U G E O T d e a l e r a s
soon as possible.
Warning lights
I f y o u h a v e t o r e m o v e / r e fi t t h e
engine style cover, handle it with
c a r e t o a v o i d d a m a g i n g t h e fi x i n g
clips.
Oil level
C h e c k t h e l e v e l r e g u l a r l y a n d t o p u p
between changes.
C h e c k t h e l e v e l w i t h t h e v e h i c l e l e v e l ,
e n g i n e c o l d , u s i n g t h e d i p s t i c k .
Dipstick
T h e r e a r e t w o m a r k s o n
t h e d i p s t i c k :
A = m a x i m u m
I f y o u fi l l p a s t t h i s m a r k ,
consult a PEUGEOT
dealer.
B = minimum
N e v e r a l l o w t h e l e v e l t o
f a l l b e l o w t h i s m a r k .
To maintain the reliability
of engines and emission
control systems, the use
of additives in engine oil
is prohibited. Viscosity selection
In all cases, the oil selected must meet
the manufacturer's requirements.
These regular maintenance
o p e r a t i o n s w i l l k e e p y o u r v e h i c l e
in good running order. Consult the
instructions at a PEUGEOT dealer or
i n t h e s e r v i c i n g b o o k l e t e n c l o s e d i n t h e
h a n d b o o k p a c k .
C h e c k i n g b y m e a n s o f t h e w a r n i n g
lights on the instrument panel is
described in chapter 2, refer to the
"Instruments and controls" section.
