Page 121 of 185
114
Changing a bulb
For further information concerning the
b u l b s , r e f e r t o t h e " T y p e s o f b u l b " .
1. Brake lights/side lights
Type B , P 2 1 / 5 W - 2 1 / 5 W
2. Direction indicators
Type B , P Y 2 1 W - 2 1 W ( a m b e r )
3. Reversing lights
Type B , P 2 1 W - 2 1 W
4. Fog lamps
Type B , P 2 1 W - 2 1 W - I d e n t i f y t h e f a u l t y b u l b t h e n o p e n
the rear doors to 180°.
Refer to the "Accesses" section of c h a p t e r 2 .
- R e m o v e t h e t w o fi x i n g b o l t s u s i n g the screwdriver stored in the tool kit
under the right-hand seat.
- P u l l t h e l i g h t u n i t f r o m t h e o u t s i d e .
- Holding the light, disconnect the electrical connector. - M o v e a s i d e t h e 4 t a b s t h e n e x t r a c t
the bulb holder.
- Remove the faulty bulb by p r e s s i n g i t l i g h t l y w h i l e t u r n i n g i t
anticlockwise.
- Change the bulb.
When removing the light unit:
- w i t h t a i l g a t e , p u l l t h e l i g h t u n i t
towards the centre of the vehicle,
- w i t h h i n g e d d o o r s , p u l l t h e l i g h t u n i t towards you.
W h e n r e fi t t i n g , t a k e c a r e t o
r e p o s i t i o n t h e t a b s a n d t h e s u p p l y
w i r e c o r r e c t l y t o a v o i d t r a p p i n g t h e
wire.
After changing the rear direction
indicator bulb, the reinitialisation time is
m o r e t h a n a p p r o x i m a t e l y 2 m i n u t e s .
REAR LIGHTS
High pressure washing
W h e n u s i n g t h i s t y p e o f w a s h i n g
o n s t u b b o r n d i r t , d o n o t p e r s i s t
o n t h e h e a d l a m p s , t h e l i g h t s a n d
their surround to avoid damaging their
coating and their seal.
Page 122 of 185
115
TROUBLESHOOTING
7
Changing a bulb
NUMBER PLATE LIGHTS
- U n s c r e w t h e t w o n u t s .
- P u s h t h e p i n s .
- If necessary, disconnect the connector to remove the light.
- Change the bulb.
With tailgate
- M o v e a s i d e t h e p l a s t i c l e n s u s i n g
a screwdriver.
- Change the bulb.
- R e p l a c e t h e p l a s t i c l e n s a n d p r e s s o n i t .
THIRD BRAKE LIGHT
Type A , W 16 W - 16 W
With hinged doors
- U n c l i p t h e i n t e r i o r t r i m .
- Disconnect the connector by moving aside its tab.
- T u r n t h e b u l b h o l d e r a q u a r t e r t u r n anticlockwise.
- Change the bulb.
- P u t t h e b u l b h o l d e r b a c k i n p l a c e and reconnect the connector.
- P u t t h e t r i m b a c k i n p l a c e .
Type A , W 5 W - 5 W
Page 124 of 185
117
TROUBLESHOOTING
7
Changing a fuse
FASCIA FUSES
T i l t t h e c o v e r t o g a i n a c c e s s t o t h e
fuses. Fuses
F A m p e r e s
A Allocation
1 15 R e a r w i p e r
2 - S p a r e
3 5 Air bag
4 10 Air conditioning, diagnostic socket, mirror control,
h e a d l a m p b e a m
5 3 0 E l e c t r i c w i n d o w s
6 3 0 Locks
7 5 R e a r c o u r t e s y l i g h t , f r o n t m a p r e a d i n g l i g h t , r o o f
console
8 20 A u d i o e q u i p m e n t , d i s p l a y , t y r e u n d e r - i n fl a t i o n
detection, alarm and siren
9 3 0 Front and rear 12 V socket
10 15 Central column 11 15 Low current ignition switch
12 15 Rain and brightness sensor, air bag
1 3 5 I n s t r u m e n t p a n e l
14 15 P a r k i n g a s s i s t a n c e , a u t o m a t i c a i r c o n d i t i o n i n g
controls, hands-free kit
15 3 0 Locks
16 - S p a r e
17 40 R e a r s c r e e n / m i r r o r s d e - i c i n g
Page 128 of 185
121
TROUBLESHOOTING
7
Having your vehicle towed
Without lifting (4 wheels on
the road)
Y o u s h o u l d a l w a y s u s e a t o w b a r .
BEING TOWED From the front
- U n c l i p t h e c o v e r b y p r e s s i n g t h e b o t t o m p a r t .
- Screw in the removable towing eye until it locks.
From the rear
- U n c l i p t h e c o v e r u s i n g a c o i n o r t h e fl a t p a r t o f t h e t o w i n g e y e ,
- Screw in the removable towing eye until it locks. When towing with the engine
switched off, there is no braking or
steering assistance.
Lifting (2 wheels on the road only)
I t i s p r e f e r a b l e t o r a i s e t h e v e h i c l e
u s i n g p r o f e s s i o n a l l i f t i n g e q u i p m e n t .
T h e t o w i n g e y e i s s t o r e d i n t h e t o o l k i t ,
located under the right-hand seat.
Vehicles fitted with a manual
gearbox (diesel version)
I n t h e c a s e o f v e h i c l e s fi t t e d w i t h a
m a n u a l g e a r b o x , t h e g e a r l e v e r m u s t
b e i n t h e n e u t r a l p o s i t i o n , f a i l u r e t o
o b s e r v e t h i s s p e c i a l c o n d i t i o n m a y
result in damage to certain braking
c o m p o n e n t s a n d t h e a b s e n c e o f
braking assistance when the engine is
started again.
