2010 PEUGEOT 807 window

4
2 4
4
7
6
4
3
3
415
1
FAMILIARISATION
Interior
Battery 116
Child monitoring mirror
102
Disarming the passenger's front air bag
96
Opening control Sliding side doors from the
inside. 24
Handbrake
86
Bonnet opening controls The bonnet opening control
is a red handle under a
cover. Release the bonnet
from inside the vehicle then
go to the front and insert
your hand under the badge
to open and raise the bonnet,
place the strut in its location
securely. 111
Safety auto-reverse. 97
102
84
83
Electric windows/Safety auto-reverse
CHILD SAFETY
Monitoring mirror.
Child seats.
On a steep gradient,
guide the side door
manually to assist
closing.
closing

Accesses
READY TO SET OFF
2
19 Pressing one of the buttons
opens or closes the
corresponding rear door
(right or left). Locating your vehicle
Key in ignition
A buzzer sounds on opening the
driver’s door, if the key has been left in
the ignition.
Folding/opening out the key
Unlocking Press the open padlock to
unlock the vehicle. This is confi rmed by rapid
fl ashing of the direction
indicators.
If the vehicle is locked and unlocking
is activated inadvertently, unless the
doors are opened within 30 seconds,
the vehicle will lock automatically. This press unlocks the entire vehicle
before opening the sliding door.
Opening/Closing the electric
sliding side doors
To tuck away the key blade,
press the button, then fold it
down into the remote control
module.
To open out the key, press the button.
To locate your vehicle, if you
have locked it, in a car park.
Press the closed padlock, the
courtesy lights come on and
the direction indicators fl ash
for a few seconds.

Pressing the closed
padlock for more than
2 seconds , in addition to
locking or deadlocking,
permits automatic closing of
the windows and places the sunroofs
in the partially open position, if they
were open. To close them completely,
you must press their switch before
leaving the vehicle.

Accesses
READY TO SET OFF
2
19 Pressing one of the buttons
opens or closes the
corresponding rear door
(right or left). Locating your vehicle
Key in ignition
A buzzer sounds on opening the
driver’s door, if the key has been left in
the ignition.
Folding/opening out the key
Unlocking Press the open padlock to
unlock the vehicle. This is confi rmed by rapid
fl ashing of the direction
indicators.
If the vehicle is locked and unlocking
is activated inadvertently, unless the
doors are opened within 30 seconds,
the vehicle will lock automatically. This press unlocks the entire vehicle
before opening the sliding door.
Opening/Closing the electric
sliding side doors
To tuck away the key blade,
press the button, then fold it
down into the remote control
module.
To open out the key, press the button.
To locate your vehicle, if you
have locked it, in a car park.
Press the closed padlock, the
courtesy lights come on and
the direction indicators fl ash
for a few seconds.

Pressing the closed
padlock for more than
2 seconds , in addition to
locking or deadlocking,
permits automatic closing of
the windows and places the sunroofs
in the partially open position, if they
were open. To close them completely,
you must press their switch before
leaving the vehicle.

Accesses
22
ALARM
If fi tted on your vehicle, this provides
two types of protection:
- exterior protection: it sounds if a door, the tailgate or the bonnet is
opened.
- interior protection: it sounds if the volume inside the passenger
compartment changes (breaking of
a window or a movement inside the
vehicle).
A red indicator light, located in the
centre of the fascia, indicates the
information detailed below. To lock your vehicle without setting
the alarm, insert the key in the
lock then lock the vehicle (e.g. for
washing).
When the alarm is triggered, the siren
sounds and the direction indicator
lights fl ash for thirty seconds.
Warning - alarm triggered: the red indicator
light fl ashes rapidly, insert the key and
switch on the ignition to switch it off.
When the alarm has been triggered ten
times in succession (on the eleventh time)
the alarm is deactivated. Repeat the rules
for setting the alarm. - Close the sunroofs,
- Switch off the ignition,
- In the next ten seconds, press
button A , located on the left-hand
side of the fascia, until the red
indicator light is on continuously,
- Get out of the vehicle,
- Within the next fi ve minutes, set the alarm by locking or deadlocking using
the remote control (the red indicator
light fl ashes once a second).
Do not make any modifi cations
to the alarm system as this could
cause faults.
Setting the alarm
- Switch off the ignition and get out of
the vehicle.
- Set the alarm within fi ve minutes of getting out of the vehicle, by locking
or deadlocking using the remote
control (the red indicator light
fl ashes once per second). Disarming
Unlock the vehicle with the remote
control (the red indicator light goes out).
To set the alarm with exterior
protection only
If, while you are away from the vehicle,
you wish to leave a window partially
open or a pet inside the vehicle, you
should choose exterior protection only. Incorrect operation
When the ignition is switched on, if the red
indicator light remains on for ten seconds,
there is a fault in the siren connection.
Consult a PEUGEOT dealer to have the
system checked.
Automatic setting of the alarm
If fi tted on your vehicle, the alarm is set
automatically 2 minutes after the last
door or the tailgate is closed.
To prevent triggering of the alarm when
a door or the tailgate is opened, it is
imperative to press the remote control
unlocking button again. When the alarm is set but the
remote control does not operate:
- Unlock the doors with the key and open the door. The alarm is
triggered.
- Switch on the ignition in the next ten seconds. The alarm is
disarmed.

Accesses
24
Opening/Closing using
the remote control
Press one of the buttons to
open or close the corresponding
rear door (right or left).
Opening/Closing from
the front
Press the corresponding
control.
An audible signal accompanies the
opening and closing of the door.
ELECTRIC SLIDING SIDE DOORS
Remember to close the sliding
doors when your vehicle is parked
for long periods, the electric open
door monitoring system consumes
power.
On a steep gradient, guide the side
door manually to assist closing.
Opening/Closing from
row 2
Press the corresponding
control. General recommendations
It is imperative that the doors are
only operated when the vehicle is
stationary.
Always ensure that the door is
operated safely. Check that no person,
animal or object is preventing the
required operation, either inside or
outside the vehicle.
Do not lean through an open window,
do not leave any object protruding
through the door during opening or
closing.
Do not leave children or pets near the
opening and closing controls without
supervision.
Obstacle detection
The detection system is triggered
when an obstacle which has a certain
physical resistance hinders the
movement of the door.
If an obstacle is detected during:
- closing of the door, the door opens
fully,
- opening of the door, the door stops.
When the obstacle has been removed,
complete or restart the action using the
remote control or the interior controls.
Failure to observe these
recommendations may result in injury
or damage if part of the body or an
object becomes jammed or caught.

Accesses
READY TO SET OFF
2
25
ELECTRIC CHILD SAFETY
Simultaneous locking or
unlocking of the tailgate and the
doors
The tailgate is locked or unlocked by
the remote control or the driver’s door
or passenger door lock.
To open, operate the handle C and lift
the tailgate. Tailgate release
The tailgate locks automatically
when the vehicle is being driven
at more than 6 mph (10 km/h) and
unlocks when one of the front doors is
opened.
TAILGATE
"Tailgate open" warning
When the engine is running or the
vehicle is being driven, you are warned
if the tailgate is not closed correctly by
a diagram on the display, accompanied
by an audible signal. This enables the tailgate to be
unlocked in the event of a central
locking fault.
- Fold back a row 2 rear seat,
- Fold back a row 3 rear seat or the
bench seat to gain access to the
lock from inside the boot,
- Insert a small screwdriver into hole D in the lock and push it
towards the left to unlock the
tailgate.
B - Electric
This disarms all the electrical controls
in the rear:
- electric windows,
- sliding side doors,
- sunroofs in rows 2 and 3.
With the ignition on, press button
B .
A message appears on the display,
accompanied by an audible signal,
indicating the status of the function:
activated or not activated.
Always check the status before setting off.
This safety system is independent of
the central locking.
In the event of a serious impact, the
doors are unlocked automatically
to permit access by the emergency
services.
Always remove the ignition key
when leaving the vehicle, even for
a short time.

82
Mirrors and windows Manual interior mirror
The interior mirror has two positions:
- day (normal),
- night (anti-dazzle).
To change from one to the other, push
or pull the lever on the lower edge of
the mirror.
Automatic day/night interior
mirror
This automatically and gradually
changes between the day and night
positions. To prevent dazzling,
the glass of the mirror darkens
automatically depending on the
intensity of the light from behind.
It clears as the light (headlamps of
following vehicles, sunlight) decreases,
ensuring maximum visibility.
Special feature
To ensure maximum visibility during
manoeuvres, the mirror clears
automatically when reverse gear is
engaged.
MIRRORS
MIRRORS AND WINDOWS
Electric exterior mirrors
- Move switch
A to the right or to
the left to select the corresponding
mirror.
- Move knob B in all four directions
to adjust.
- Return switch A to the centre
position
When parked, the mirrors can be
folded back manually, or electrically by
pulling switch A rearwards.
Electric unfolding of the mirrors is
possible with the key on unlocking the
vehicle.

ERGONOMICS and COMFORT
3
83
Mirrors and windows
ELECTRIC WINDOWS

4. Rear left electric window switch.

5. Rear electric windows disarming
switch (child safety).
- red strip visible: the rear switches are activated.
- red strip covered: the rear switches are disarmed. You have two options:
The electrical functions of the
electric windows are disarmed
one minute after switching off the
ignition.
Disarming the rear controls
For the safety of your children, press
switch 5 to disarm all of the electrical
controls in the rear:
- electric windows,
- sliding side doors,
- sunroofs.

1. Driver's electric window switch.

2. Passenger electric window
switch.

3. Rear right electric window
switch. Manual operation:
- press or pull switch
1 , without going
beyond the point of resistance. The
window stops when the switch is
released.
Automatic operation:
- press or pull switch 1 , beyond the
point of resistance: the window
opens or closes completely when
the switch is released. Pressing the
switch again stops the movement
of the window.
