2010 Lexus HS250h battery capacity

550
6-1. Specifications
Fuel
Electric motor (Traction motor)
Hybrid battery (Traction battery)
Lubrication system
Fuel typeUnleaded gasoline only
Octane rating87 (Research octane number 91) or higher
Fuel tank capacity14.5 gal. (55 L, 12.5 Imp. gal.)
Ty p ePermanent magnet synchronous motor
Maximum output105 kW
Maximum torque199 ft•lbf (270 N•m, 27.5 kgf•m)
Ty p eNickel-metal hydride battery
Vo l t a g e7.2 V/module
Capacity6.5 Ah (3HR)
Quantity34 modules
Overall voltage244.8 V
Oil capacity 
Drain and refill 
(Reference)
With filter
Without filter

4.5 qt. (4.3 L, 3.8 lmp.qt.)
4.3 qt. (4.1 L, 3.6 lmp.qt.)

553
6-1. Specifications
6
Vehicle specifications
Electrical system
Hybrid transaxle
*: The fluid capacity is a reference quantity. If replacement is necessary, contact your Lexus dealer.
12-volt battery
Open voltage* at
68 F (20 C):12.6 12.8 V Fully charged 
12.2 
12.4 V Half charged 
11.8 
12.0 V Discharged 
(*: Voltage checked 20 minutes after the hybrid sys-
tem and all the lights are turned off)
Charging rates5 A max.
Fluid capacity *4.4 qt. (4.2 L, 3.7 Imp. qt.)
Fluid typeToyota Genuine ATF WS
NOTICE
■Hybrid transaxle fluid type
Using hybrid transaxle fluid other than “Toyota Genuine ATF WS” may cause dete-
rioration in shift quality, locking up of the transaxle accompanied by vibration, and
ultimately damage the hybrid transaxle of your vehicle.

567
6-1. Specifications
6
Vehicle specifications
Occupant distributionDistribution of occupants in a vehicle as specified in
the third column of Table 1
* below
Production options
weight
The combined weight of installed regular production
options weighing over 5 lb. (2.3 kg) in excess of the
standard items which they replace, not previously
considered in curb weight or accessory weight,
including heavy duty brakes, ride levelers, roof rack,
heavy duty battery, and special trim
RimA metal support for a tire or a tire and tube assembly
upon which the tire beads are seated
Rim diameter 
(Wheel diameter)Nominal diameter of the bead seat
Rim size designationRim diameter and width
Rim type designationThe industry manufacturer’s designation for a rim by
style or code
Rim widthNominal distance between rim flanges
Vehicle capacity weight
(Total load capacity)The rated cargo and luggage load plus 150 lb. (68
kg) times the vehicle’s designated seating capacity
Vehicle maximum load on
the tireThe load on an individual tire that is determined by
distributing to each axle its share of the maximum
loaded vehicle weight, and dividing by two
Vehicle normal load on
the tire
The load on an individual tire that is determined by
distributing to each axle its share of curb weight,
accessory weight, and normal occupant weight (dis-
tributed in accordance with Table 1
* below), and
dividing it by two
We a t h e r s i d eThe surface area of the rim not covered by the
inflated tire
Tire related termMeaning

593
Alphabetical index
Back-up lightsReplacing light bulbs ....................... 470
Wattage ................................................. 556
Battery Checking ............................................... 433
If the vehicle has a discharged 
12-volt battery .................................. 536
Preparing and checking 
before winter .....................................244
Bluetooth
®................................................ 311
Bottle holders ........................................ 369
Brake Fluid .......................................................... 554
Parking brake ........................................ 163
Brake assist ..............................................225
Break-in tips ............................................. 137
Brightness control Instrument panel light 
control ................................................... 163
Care Exterior ................................................... 402
Interior..................................................... 406
Seat belts ............................................... 407
Cargo capacity ......................................243
CD changer ............................................ 273
CD player................................................. 273
Chains ........................................................245 Child restraint system
Booster seats, definition .................. 120
Booster seats, installation ............... 130
Convertible seats, definition .......... 120
Convertible seats, installation ....... 128
Front passenger occupant 
classification system ......................... 115
Infant seats, definition ........................ 120
Infant seats, installation ...................... 127
Installing CRS with LATCH 
anchors ................................................. 125
Installing CRS with seat belts ......... 127
Installing CRS with top tether 
straps ....................................................... 131
Child safety Airbag precautions .............................. 110
Child restraint system ....................... 120
Child-protectors .................................. 58
How your child should wear 
the seat belt .......................................... 75
Installing child restraints....................124
Moon roof precautions........................91
Power window lock switch ..............86
Power window precautions ........... 88
Removed electronic key battery 
precautions........................................454
Seat belt extender precautions...... 78
Seat belt precautions .......................... 76
Seat heater precautions.................. 376
Trunk precautions................................. 62
12-volt battery precautions ...........435
B
C

595
Alphabetical index
Electric power steering ......................225
Electronic keyIf the electronic key does not 
operate properly ............................ 533
Emergency, in case of If the electronic key does not 
operate properly ............................ 533
If the engine will not start ...............530
If the hybrid system will not 
start........................................................530
If the 12-volt battery is 
discharged ........................................ 536
If the warning buzzer sounds...... 492
If the warning light turns on .......... 492
If the warning message is 
displayed ............................................. 501
If you have a flat tire .......................... 521
If you lose your keys ........................ 532
If you think something is 
wrong................................................... 489
If your electronic key does 
not operate properly.................... 533
If your vehicle becomes stuck .... 545
If your vehicle needs to be  towed ................................................... 483
If your vehicle overheats.................. 541
Emergency flasher Switch ...................................................... 482 Engine
Accessory mode................................. 148
Compartment...................................... 422
Engine switch .........................................147
Hood ......................................................... 419
How to start the engine ....................147
How to start the hybrid 
system ....................................................147
Identification number ...................... 548
If the engine will not start............... 530
If the hybrid system will not 
start ....................................................... 530
Ignition switch ........................................147
Overheating .......................................... 541
Power switch..........................................147
Engine compartment cover ............. 423
Engine coolant Capacity .................................................552
Checking ...............................................428
Preparing and checking before winter .................................... 244
Engine/power control unit coolant Capacity .................................................552
Checking ...............................................428
Preparing and checking before winter .................................... 244
Engine immobilizer system.................. 96E

603
Alphabetical index
Warning messagesCruise control ..................................... 502
Dynamic radar cruise 
control .................................... 502, 505
Electric power steering  system.................................................. 502
Engine oil maintenance..................505
Engine oil pressure............................ 501
EV drive mode ...................................505
Headlight ............................................... 502
Hood .......................................................505
Hybrid system ...................................... 501
Intuitive parking assist ........ 502, 505
Key .............................................................. 513
Lane-Keeping Assist .......................505
Moon roof .............................................505
Open door ...........................................505
Parking brake ......................................505
Pre-collision system ............ 502, 505
Smart access system with 
push start.............................................. 513
Tire pressure warning 
system..................................................505
Trunk ........................................................505
Washer fluid.........................................505 Washer
Checking ............................................... 432
Preparing and checking before winter .................................... 244
Switch........................................................ 195
Washing and waxing ...........................402
Weight Cargo capacity ................................... 243
Load limits ............................................. 243
Weight.................................................... 548
Wheels ......................................................448
Window glasses .......................................86
Window lock switch ...............................86
Windows Power windows .....................................86
Rear window defogger.................. 260
Washer .................................................... 195
Windshield wiper de-icer................... 261
Windshield wipers................................. 195
Wireless remote control key Locking/Unlocking ............................. 54
Replacing the battery.......................453
Wireless remote control key .......... 54
WMA disc ................................................ 281
