2010 Lexus GX460 navigation

15
GX460_U.S.A. (OM60E69U)
Headlight cleaner switch 
P. 241
A
Fuel filler door opener P. 109
VSC OFF switch P. 330
Power outlet main switch P. 542
Heated steering wheel switch
P. 549
ODO/TRIP button P. 196
Instrument cluster li ght control switch P. 196
Outside rear view mirror
switches
P. 97
: If equipped
*: Refer to “Navigation System Owner’s Manual”.

17
GX460_U.S.A. (OM60E69U)
Accessory meterP. 212

: If equipped
*: Refer to “Navigation System Owner’s Manual”.
Vehicles without a navigation system
Vehicles with a navigation system
C
Security indicator P. 114, 116
Rear window defogger switch P. 404
Air conditioning system P. 384
Navigation system*Security indicator P. 114, 116
Air conditioning system*
Rear window defogger switch*
Windshield wiper de-icer P. 405

114
GX460_U.S.A. (OM60E69U)
1-6. Theft deterrent system
Engine immobilizer system
The vehicle’s keys have built-in transponder chips that prevent the engine
from starting if a key has not been previously registered in the vehicle’s on-
board computer.
Never leave the keys inside the vehicle when you leave the vehicle.
Vehicles without a navigation system
The indicator light flashes after
the “ENGINE START STOP”
switch has been turned off to
indicate that the system is oper-
ating.
Vehicles with a navigation system The indicator light flashes after
the “ENGINE START STOP”
switch has been turned off to
indicate that the system is oper-
ating.

116
1-6. Theft deterrent system
GX460_U.S.A. (OM60E69U)
Alarm
The system sounds the alarm and flashes the lights when forced entry is
detected.
■Triggering of the alarm
The alarm is triggered in the following situations:
●A locked door or glas s hatch is unlocked or opened in any way
other than using the entry function, wireless remote control or
mechanical key with the alarm being set. (The doors will lock
again automatically.)
● The hood is opened with the alarm being set.
■ Setting the alarm system
Vehicles without a navigation system Close the doors, glass hatch
and hood, and lock all the doors.
The system will be set automati-
cally after 30 seconds.
The indicator light changes from
being on to flashing when the
system is set.

117
1-6. Theft deterrent system
1
Before driving
GX460_U.S.A. (OM60E69U)
Vehicles with a navigation systemClose the doors, glass hatch
and hood, and lock all the doors.
The system will be set automati-
cally after 30 seconds.
The indicator light changes from
being on to flashing when the
system is set.
■Deactivating or stopping the alarm
Do one of the following to deactivate or stop the alarms:
●Unlock the doors.
● Start the engine. (The alarm will be deactivated or stopped after a
few seconds.)

198
2-2. Instrument cluster
GX460_U.S.A. (OM60E69U)
Indicators and warning lights
The indicators and warning lights on the instrument cluster and center
panel inform the driver of the status of the vehicle’s various systems.
Instrument cluster
Center panel (vehicles without a navigation system)

199
2-2. Instrument cluster
2
When driving
GX460_U.S.A. (OM60E69U)
Center panel (vehicles with a navigation system)

260
2-4. Using other driving systems
GX460_U.S.A. (OM60E69U)
Intuitive parking assist
: If equipped
The distance from your vehicle to nearby obstacles when parallel parking
or maneuvering into a garage is measured by the sensors and communi-
cated via the multi-information display and a buzzer. Always check the sur-
rounding area when using this system.
Vehicles with a navigation system
Refer to the “Navigation System Owner’s Manual”.
Vehicles without a navigation system
■Types of sensors
Front corner sensors
Front center sensors
Rear corner sensors
Rear center sensors
