2010 Lexus GS450h Using The Audio System / LEXUS 2010 GS450H OWNERS MANUAL (OM30C81U)

257
3-1. Using the touch screen
3
Interior features
GS_HV_U (OM30C81U)
January 28, 2010 10:42 am
●Changing the passcode
Touch “Edit”.
Enter the desired passcode.
The passcode can be between 4 and 8 characters in length, and is set
to “0000” by default.
●Changing the device name
Touch “Edit”.
Enter the desired name.
●Restoring the default settings
Touch “Default”.
A confirmation screen will be displayed, touch “Yes” to restore
the default settings.
■When setting the connection method to “From Portable Player”
●Connection methods differ depending on the audio player. Consult your audio
player’s manual.
●Automatic connection cannot be set to “On”.
■When using Bluetooth® audio
A confirmation screen will be displayed if an attempt is made to remove a portable
player.
Touch “Yes” to disconnect and remove the player.
STEP1
STEP2
STEP1
STEP2
STEP1
STEP2

258
3-1. Using the touch screen
GS_HV_U (OM30C81U)
January 28, 2010 10:42 am
Vehicle settings
Touch “Vehicle” on the “Setup” screen.
Refer to “Navigation System
Owner’s Manual”.
Setting up intuitive parking
assist
●Setting up intuitive parking assist
Alert volume setting
Display setting
“Static”: Displays when the sen-
sors detect an obsta-
cle.
“Dynamic”: Displays if maneuvers
are required to avoid
an obstacle.
“Off”: Does not display the
intuitive parking assist
display.
■Intuitive parking assist display
When an obstacle is detected while the rear view monitor system is in use, the
warning indicator will appear in the top right of the screen even if the display setting
has been set to “Off”.

259
3
Interior features
GS_HV_U (OM30C81U)
October 13, 2015 12:41 pm
3-2. Using the air conditioning system and defogger
Automatic air conditioning system
Airflow and outlets are automatically adjusted according to the tempera-
ture setting.
Press
to display the air conditioning operation screen.
The illustrations below are for vehicles with navigation system.
The display and button positions will differ depending on the type of the sys-
tem.
Automatic mode Driver’s side 
temperature display
Fan speed display
OffAirflow display Air conditioning operation
screen display button
Passenger’s side 
temperature 
display
Micro dust and pollen filter Driver’s side 
temperature control Air conditioning 
ON/OFF switch
Outside air or recirculated mode
Windshield defoggerPassenger’s side 
temperature control Dual operation switch

260
3-2. Using the air conditioning system and defogger
GS_HV_U (OM30C81U)
October 13, 2015 12:41 pm
Using the voice command system (with navigation system)
Press the talk switch to operate the
voice command system. 
(“Navigation System Owner’s
Manual”)
Using the automatic mode
Press .
The air conditioning system will begin to operate. Air outlets
and fan speed are automatically adjusted according to the
temperature setting.
Press to switch to automatic mode.
Automatically switches between outside air and recirculated
air modes.
Press  to increase the temperature and  to decrease the tem-
perature on .
The temperature for the driver and passenger seats can be set sepa-
rately.
STEP1
STEP2
STEP3

261
3-2. Using the air conditioning system and defogger
3
Interior features
GS_HV_U (OM30C81U)
October 13, 2015 12:41 pm
Adjusting the settings
■Adjusting the temperature setting
Press  to increase the temperature and  to decrease the tempera-
ture on .
Press  (increase) or  (decrease) on to separately adjust the tem-
perature for the passenger and driver sides (dual mode). Touch “DUAL” to
return the driver and passenger side temperatures to the same setting
(simultaneous mode).
The air conditioning system switches between dual and simultaneous
modes each time “DUAL” is touched.
■Adjusting the fan speed
Touch any switch of “LO” to “HI” (decrease increase) on the oper-
ating screen.
Press to turn the fan off.

262
3-2. Using the air conditioning system and defogger
GS_HV_U (OM30C81U)
October 13, 2015 12:41 pm
■Changing the air outlets
Touch any mode on the operating
screen.
Upper body
*: Only in the automatic mode
Upper body and feet
Feet
Feet and the windshield defogger operates

263
3-2. Using the air conditioning system and defogger
3
Interior features
GS_HV_U (OM30C81U)
October 13, 2015 12:41 pm
■Switching between outside air and recirculated air modes
Press .
The mode switches between (recycles air inside the vehicle), “AUTO”
and (introduces air from outside the vehicle) modes each time the
button is pressed.
When the system is switched to automatic mode, the air conditioning sys-
tem operates automatically.
Defogging the windshield
Press
.
The air conditioning system control
operates automatically.

264
3-2. Using the air conditioning system and defogger
GS_HV_U (OM30C81U)
October 13, 2015 12:41 pm
Micro dust and pollen filter
Press .
Outside air mode switches to
(recirculated air) mode. Pol-
len is removed from the air and the
air flows to the upper part of the
body.
Usually the system will turn off
automatically approximately 3
minutes later.
To stop the operation, press
again.
Adjusting the sensitivity of the air intake control in automatic mode
Press until the smog sensor screen appears while the
vehicle is stopped.
Touch any switch of “LO” to “HI”
(lower sensitivity higher sensi-
tivity) on the operating screen.
STEP1
STEP2
