Page 25 of 37
•Comes on for any period of time while driving.
Event Data Recorder (EDR)
In the event of an accident, your vehicle is designed to
record up to five seconds of specific vehicle data param-
eters (see list below) in an event data recorder prior to the
moment of airbag deployment, or near deployment (if
applicable), and up to a quarter second of either high-
speed deceleration data or change in velocity during
and/or after airbag deployment or near-deployment.
EDR data is ONLY recorded if an airbag deploys, or
nearly deploys, and is otherwise unavailable.
NOTE:
1. A near-deployment event occurs when the airbag
sensor detects severe vehicle deceleration usually indica-
tive of a crash, but not severe enough to warrant airbag
deployment.
2. Under certain circumstances, EDR data may not be
recorded (e.g., loss of battery power).In conjunction with other data gathered during a com-
plete accident investigation, the electronic data may be
used by Chrysler Group LLC and others to learn more
about the possible causes of crashes and associated
injuries in order to assess and improve vehicle perfor-
mance. In addition to crash investigations initiated by
Chrysler Group LLC, such investigations may be re-
quested by customers, insurance carriers, government
officials, and professional crash researchers, such as those
associated with universities, and with hospital and insur-
ance organizations.
In the event that an investigation is undertaken by
Chrysler Group LLC (regardless of initiative), the com-
pany or its designated representative will first obtain
permission of the appropriate custodial entity for the
vehicle (usually the vehicle owner or lessee) before
accessing the electronic data stored, unless ordered to
download data by a court with legal jurisdiction (i.e.,
pursuant to a warrant). A copy of the data will be
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25
Page 26 of 37
provided to the custodial entity upon request. General
data that does not identify particular vehicles or crashes
may be released for incorporation in aggregate crash
databases, such as those maintained by the U.S. govern-
ment and various states. Data of a potentially sensitive
nature, such as would identify a particular driver, ve-
hicle, or crash, will be treated confidentially. Confidential
data will not be disclosed by Chrysler Group LLC to any
third party except when:
1. Used for research purposes, such as to match data
with a particular crash record in an aggregate database,
provided confidentiality of personal data is thereafter
preserved.
2. Used in defense of litigation involving a Chrysler
Group LLC product.
3. Requested by police under a legal warrant.4. Otherwise required by law.
Data parameters that are recorded:
•Diagnostic trouble code(s) and warning light status for
electronically-controlled safety systems, including the
airbag system
•Vehicle speed
•Engine RPM
•Brake switch status
•Pedal position
•And other parameters depending on vehicle
configuration
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 27 of 37
UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
Instrument Panel Features ................ 28
3
Page 28 of 37
INSTRUMENT PANEL FEATURES
1 — Air Outlet6 — Climate Controls
2 — Instrument Cluster 7 — Power Outlet
3 — Horn 8 — Lower Switch Bank
4 — Radio 9 — Auxiliary Power Outlet
5 — Glove Compartment
28 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 29 of 37
STARTING AND OPERATING
CONTENTS
Engine Block Heater — If Equipped ......... 30
4
Page 30 of 37
ENGINE BLOCK HEATER — IF EQUIPPED
The engine block heater warms engine, and permits
quicker starts in cold weather. Connect the cord to a
standard 110-115 Volt AC electrical outlet with a
grounded, three wire extension cord. The engine block
heater cord is found under the hood near the brake fluid
reservoir.
WARNING!
Remember to disconnect the cord before driving.
Damage to the 110-115 Volt AC electrical cord could
cause electrocution.Use the heater when temperatures below 0°F (-18°C) are
expected to last for several days.
30 STARTING AND OPERATING
Page 31 of 37
MAINTAINING YOUR VEHICLE
CONTENTS
Engine Compartment — 3.8L .............. 32Maintenance Procedures .................. 33
5
Page 32 of 37
ENGINE COMPARTMENT — 3.8L
1 — Brake Fluid Reservoir7 — Washer Fluid Reservoir
2 — Engine Oil Fill 8 — Engine Coolant Reservoir
3 — Automatic Transmission Dipstick 9 — Air Cleaner Filter
4 — Engine Oil Dipstick 10 — Coolant Pressure Cap
5 — Battery 11 — Power Steering Fluid Reservoir
6 — Integrated Power Module
32 MAINTAINING YOUR VEHICLE
