2010 JEEP LIBERTY rear view mirror

MIRRORS
Inside Day/Night Mirror
A two-point pivot system allows for horizontal and
vertical mirror adjustment. Adjust the mirror to center on
the view through the rear window.
Headlight glare can be reduced by moving the small
control under the mirror to the night position (toward the
rear of vehicle). The mirror should be adjusted while set
in the day position (toward the windshield).
Automatic Dimming Mirror — If Equipped
This mirror automatically adjusts for headlight glare
from vehicles behind you. You can turn the feature on or
off by pressing the button at the base of the mirror. A light
next to the button will illuminate to indicate when the
dimming feature is activated.
Adjusting Rearview Mirror
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
To avoid damage to the mirror during cleaning, never
spray any cleaning solution directly onto the mirror.
Apply the solution onto a clean cloth and wipe the
mirror clean.
Outside Mirrors
To receive maximum benefit, adjust the outside mirror(s)
to center on the adjacent lane of traffic and a slight
overlap of the view obtained from the inside mirror.
NOTE:The passenger side convex outside mirror will
give a much wider view to the rear, and especially of the
lane next to your vehicle.
WARNING!
Vehicles and other objects seen in the passenger side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger side convex mirror could cause you to
collide with another vehicle or other object. Use your
inside mirror when judging the size or distance of a
vehicle seen in the passenger side convex mirror.
Automatic Dimming Mirror
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95

2. Unclip the visor from the center clip.
3. Pull the sun visor toward the inside rearview mirror to
extend it.
uconnect™ phone — IF EQUIPPED
uconnect™ phone is a voice-activated, hands-free, in-
vehicle communications system. uconnect™ phone al-
lows you to dial a phone number with your cellular
phone using simple voice commands (e.g.,Call”
“Mike” ”Work orDial” “248-555-1212). Your cellular
phone’s audio is transmitted through your vehicle’s
audio system; the system will automatically mute your
radio when using the uconnect™ phone.
NOTE: The uconnect™ phone requires a cellular phone
equipped with the Bluetooth Hands-Free Profile,Ve r -
sion 0.96 or higher. See the uconnect™ website for
supported phones. For uconnect™ customer support, visit the following
websites:
•www.chrysler.com/uconnect
•www.dodge.com/uconnect
•www.jeep.com/uconnect
•or call 1–877–855–8400
uconnect™ phone allows you to transfer calls between
the system and your cellular phone as you enter or exit
your vehicle and enables you to mute the system’s
microphone for private conversation.
The uconnect™ phone is driven through your Bluetooth
“Hands-Free Profile” cellular phone. uconnect™ features
Bluetooth technology - the global standard that enables
different electronic devices to connect to each other
without wires or a docking station, so uconnect™ phone
works no matter where you stow your cellular phone (be
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Things You Should Know About Your uconnect™
phone
uconnect™ phone Tutorial
To hear a brief tutorial of the system features, press the
button and say “uconnect™ Tutorial.”
Voice Training
For users experiencing difficulty with the system recog-
nizing their voice commands or numbers, the uconnect™
phone Voice Training feature may be used. To enter this
training mode, follow one of the two following proce-
dures:
From outside the uconnect™ phone mode (e.g., from
radio mode):
•Press and hold thebutton for five seconds until
the session begins, or,
•Press thebutton and say the Setup, Voice Train-
ing command. Repeat the words and phrases when prompted by the
uconnect™ phone. For best results, the Voice Training
session should be completed when the vehicle is parked
with the engine running, all windows closed, and the
blower fan switched off.
This procedure may be repeated with a new user. The
system will adapt to the last trained voice only.
To restore the Voice Recognition system to factory default
settings, enter the Voice Training session via the above
procedure and follow the prompts.
Voice Recognition (VR)
•
For best performance, adjust the rearview mirror to
provide at least12in (1 cm) gap between the overhead
console (if equipped) and the mirror.
•Always wait for the beep before speaking.
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with MOPARGlass Cleaner or any commercial
household-type glass cleaner. Never use an abrasive type
cleaner. Use caution when cleaning the inside rear win-
dow equipped with electric defrosters or the right rear
quarter window equipped with the radio antenna. Do
not use scrapers or other sharp instruments, which may
scratch the elements.
When cleaning the rear view mirror, spray cleaner on the
towel or rag that you are using. Do not spray cleaner
directly on the mirror.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic. 1. Clean with a wet soft rag. A mild soap solution may be
used, but do not use high alcohol content or abrasive
cleaners. If soap is used, wipe clean with a clean damp
rag.
2. Dry with a soft cloth.
Seat Belt Maintenance
Do not bleach, dye, or clean the seat belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage can also weaken the fabric.
If the seat belts need cleaning, use a mild soap solution or
lukewarm water. Dry with a soft cloth. Do not remove the
seat belts from the car to wash them.
Replace the seat belts if they appear frayed or worn or if
the buckles do not work properly.
7
MAINTAINING YOUR VEHICLE 453

Cavity CartridgeFuseMini-
Fuse Description
M15 — 20 Amp YellowMultifunction Control
Switch/Cabin Com-
partment Node
(CCN)/Steering Col-
umn Control Module
(SCM)/Rear View
Mirror/Tire Pressure
Monitor (TPM) - if
equipped/IR Sensor -
if equipped/Transfer
Case Module - if
equipped
M16 — 10 Amp RedOccupant Restraint
Controller (ORC)Cavity Cartridge
FuseMini-
Fuse Description
M17 — 15 Amp BlueExterior Lighting —
Left Front Park and
Side Marker, Left Tail
and Running, License
Lights
M18 — 15 Amp BlueExterior Lighting —
Right Front Park and
Side Marker, Right
Tail and Running
Lights
M19 — 25 Amp NaturalAuto Shut Down
(ASD) #1 and #2
458 MAINTAINING YOUR VEHICLE

Passing............................. 153
Replacing ........................... 461
Switch ........................... 148,149
Time Delay .......................... 150
Heated Mirrors .......................... 97
Heated Seats ........................... 138
Heater ............................... 281
Heater, Engine Block ..................... 301
High Beam Indicator ..................... 211
High Beam/Low Beam Select (Dimmer)
Switch ............................... 153
Hill Descent Control ..................... 337
Hill Descent Control Indicator ............214,337
Hill Start Assist ......................... 334
Hitches Trailer Towing ........................ 387
Holder, Coin ........................... 192
Holder, Cup ........................... 191
HomeLink (Garage Door Opener) Transmitter . . . 173 Hood Release
.......................... 146
Ignition ............................... 12
Key ................................ 12
Ignition Key Removal ..................... 12
Illuminated Entry ........................ 19
Immobilizer (Sentry Key) ................... 14
Infant Restraint ........................ 75,76
Inflation Pressure Tires .................... 353
Information Center, Vehicle ................. 223
Inside Rearview Mirror .................... 94
Instrument Cluster .................... 207,208
Instrument Panel and Controls .............. 206
Instrument Panel Cover ................... 451
Instrument Panel Lens Cleaning ............. 453
Integrated Power Module (Fuses) ............ 454
Interior Appearance Care .................. 451
Interior Lighting ........................ 148
Intermittent Wipers (Delay Wipers) ........... 156
508 INDEX

Rearview............................. 94
Vanity ............................... 97
Modifications/Alterations, Vehicle ............. 8
Monitor, Tire Pressure System ............... 363
Mopar Parts ......................... 422,494
MTBE/ETBE ........................... 374
Multi-Function Control Lever ............... 148
New Vehicle Break-In Period ................ 85
Occupant Restraints ....................... 40
Occupant Restraints (Sedan) ................. 60
Octane Rating, Gasoline (Fuel) ............373,466
Odometer Trip ................................ 217
Off-Pavement Driving (Off-Road) ............ 321
Off-Road Driving (Off-Pavement) ............ 321
Oil Change Indicator .................. 220,226
Oil Change Indicator, Reset ..............220,226Oil, Engine
......................... 424,466
Capacity ............................ 465
Change Interval .................. 220,226,425
Checking ............................ 424
Dipstick ............................. 424
Disposal ............................ 426
Filter ............................ 427,466
Filter Disposal ........................ 426
Identification Logo ..................... 425
Materials Added to ..................... 426
Recommendation ................... 425,465
Synthetic ............................ 426
Viscosity ......................... 426,465
Oil Filter, Change ........................ 427
Onboard Diagnostic System ..............420,421
Opener, Garage Door (HomeLink) ........... 173
Operating Precautions .................... 420
Operator Manual (Owner’s Manual) ............ 5
Outside Rearview Mirrors .................. 95
512 INDEX
