2010 JEEP LIBERTY torque

Draining Fluid
First remove the fill plug (1), then the drain plug (2).
Recommended tightening torque for the drain and fill
plugs is 15–25 ft lbs (20–34 N·m).
CAUTION!
Do not over-tighten the plugs. You could damage
them and cause a leak.
Lubricant Selection
Use only manufacturer’s recommended fluid. Refer to
“Fluids, Lubricants, and Genuine Parts” in this section
for the correct fluid type.
Frequency of Fluid Change
Under normal operating conditions, the fluid installed at
the factory will give satisfactory lubrication for the life ofthe vehicle. Fluid changes are not necessary unless the
fluid becomes contaminated with water. Change the fluid
immediately if contaminated with water.
Front/Rear Axle Fluid
Fluid Level Check
The lubricant level should be at bottom edge of the oil fill
hole.
Adding Fluid
Add lubricant only at the fill hole and only to the level
specified above.
Lubricant Selection
Use only manufacturer’s recommended lubricant. Refer
to “Fluids, Lubricants, and Genuine Parts” in this section
for the correct fluid type.7
MAINTAINING YOUR VEHICLE 445

Automatic Door Locks................... 30,31
Automatic Headlights .................... 149
Automatic Oil Change Indicator ..........220,226
Automatic Temperature Control (ATC) ......... 285
Automatic Transaxle ...................... 302
Special Additives ...................... 444
Automatic Transmission ................305,443
Adding Fluid ...................... 443,467
Fluid and Filter Changes ................. 443
Fluid Change ......................... 443
Fluid Level Check ..................... 443
Fluid Type ........................... 467
Gear Ranges ......................... 305
Special Additives ...................... 444
Torque Converter ...................... 309
Auxiliary Electrical Outlet (Power Outlet) ...... 189
Auxiliary Power Outlet ................... 189
Axle Fluid ............................. 467
Axle Lubrication (Axle Fluid) ............... 467Battery
............................... 428
Emergency Starting ..................... 412
Gas Caution .......................... 428
Jump Starting ......................... 412
Keyless Transmitter Replacement (RKE) ....... 25
Belts, Seat ............................ 42,87
Body Mechanism Lubrication ............... 431
B-Pillar Location ........................ 348
Brake Assist System ...................... 333
Brake Control System, Electronic ............. 331
Brake Fluid ............................ 467
Brake, Parking .......................... 327
Brake System ........................... 441
Anti-Lock (ABS) .................... 329,332
Fluid Check ....................... 441,467
Master Cylinder ....................... 441
Parking ............................. 327
Warning Light ........................ 221
Brakes ............................... 441
10
INDEX 501

Load Capacity........................ 348
Pressure Monitor System (TPMS) ........... 363
Pressure Warning Light .................. 208
Quality Grading ....................... 497
Radial .............................. 355
Replacement ......................... 359
Rotation ............................ 361
Safety .............................. 343
Sizes ............................... 345
Spare Tire ........................... 406
Spinning ............................ 356
Tread Wear Indicators ................... 357
To Open Hood .......................... 146
Tongue Weight/Trailer Weight .............. 390
Torque Converter Clutch .................. 309
Tow/Haul Indicator Light ................. 214
Towing ............................... 382
24-Hour Towing Assistance ............... 112
Behind a Motor Home .................. 397 Disabled Vehicle
....................... 414
Guide .............................. 388
Recreational .......................... 397
Weight .............................. 388
Towing Assistance ....................... 112
Towing Vehicle Behind a Motor Home ......... 397
Traction Control ......................... 332
Trailer Towing .......................... 382
Cooling System Tips .................... 397
Hitches ............................. 387
Minimum Requirements ................. 391
Trailer and Tongue Weight ............... 390
Wiring .............................. 394
Trailer Towing Guide ..................... 388
Trailer Weight .......................... 388
Transaxle ............................. 302
Automatic ........................... 302
Operation ........................... 302
Transfer Case ........................... 444
518 INDEX
