2010 JEEP LIBERTY cruise control

NOTE:In order to ensure proper operation, the Elec-
tronic Speed Control System has been designed to shut
down if multiple Speed Control functions are operated
simultaneously. If this occurs, the Electronic Speed Con-
trol System can be reactivated by pushing the Electronic
Speed Control ON/OFF button and resetting the desired
vehicle set speed.
To Activate
Push and release the ON/OFF button located
on the end of the Electronic Speed Control
lever. The Cruise indicator lamp in the instru-
ment cluster will illuminate. To turn the system
off, push and release the ON/OFF button a second time.
The Cruise indicator lamp will turn off. Be sure to turn
the Electronic Speed Control system off when not in use.
NOTE: The Electronic Speed Control system will auto-
matically turn off when the engine is turned off.
WARNING!
Leaving the Electronic Speed Control system on
when not in use is dangerous. You could accidentally
set the system or cause it to go faster than you want.
You could lose control and have an accident. Always
leave the Electronic Speed Control system off when
you are not using it.
To Set a Desired Speed
When the vehicle reaches the speed desired, press down
on the SET DECEL lever and release. Release the accel-
erator and the vehicle will operate at the selected speed.
NOTE:
•The vehicle must be traveling at least 25 mph
(40 km/h) for the Electronic Speed Control to set.
•The vehicle should be traveling at a steady speed and
on level ground before pressing the SET DECEL lever.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161

CHAngE OIL Message (Base And Mid Line Clusters
Only)
Your vehicle is equipped with an engine oil change
indicator system. The “CHANgE OIL” message will flash
in the instrument cluster odometer for approximately
12 seconds after a single chime has sounded to indicate
the next scheduled oil change interval. The engine oil
change indicator system is duty cycle based, which
means the engine oil change interval may fluctuate
dependent upon your personal driving style.
Unless reset, this message will continue to display each
time you turn the ignition switch to the ON position. To
turn off the message temporarily, press and release the
Trip Odometer button on the instrument cluster. To reset
the oil change indicator system (after performing the
scheduled maintenance) perform the following proce-
dure:1. Turn the ignition switch to the ON position.
Do not
start the engine.
2. Fully depress the accelerator pedal slowly three
times within 10 seconds.
3. Turn the ignition switch to the LOCK position.
NOTE: If the indicator message illuminates when you
start the vehicle, the oil change indicator system did not
reset. If necessary, repeat this procedure.
28. Cruise Indicator — If Equipped This indicator lights when the electronic speed
control system is turned on.
29. Shift Lever Indicator
The Shift Lever Indicator is self-contained within the
instrument cluster. It displays the gear position of the
automatic transmission.
220 UNDERSTANDING YOUR INSTRUMENT PANEL

DisposalAntifreeze (Engine Coolant) ............... 439
Engine Oil ........................... 426
Door Locks ............................. 28
Door Locks, Automatic .................... 30
Door Opener, Garage ..................... 173
Driving ............................... 321
Off-Pavement ......................... 321
Off-Road ............................ 321
On Hills ............................ 321
Through Flowing, Rising, or Shallow Standing
Water .............................. 321
When to Use Low Range ................. 321
Electric Remote Mirrors .................... 96
Electrical Outlet, Auxiliary (Power Outlet) ...... 189
Electrical Power Outlets ................... 189
Electronic Brake Control System ............. 331
Anti-Lock Brake System ................. 332 Brake Assist System
.................... 333
Electronic Roll Mitigation ................ 334
Electronic Stability Program ............... 339
Traction Control System ................. 332
Electronic Roll Mitigation (ERM) ............. 334
Electronic Speed Control (Cruise Control) ...... 160
Electronic Stability Program (ESP) ............ 339
Electronic Vehicle Information Center (EVIC) .... 223
Emergency, In Case of Hazard Warning Flasher ................. 404
Jacking ............................. 405
Jump Starting ......................... 412
Overheating .......................... 404
Towing ............................. 414
Emission Control System Maintenance ......421,470
Engine ............................... 419
Air Cleaner .......................... 427
Block Heater ......................... 301
Break-In Recommendations ................ 85
504 INDEX

Sentry Key (Immobilizer)................... 14
Sentry Key Programming ................... 16
Sentry Key Replacement ................... 15
Service Assistance ....................... 491
Service Contract ......................... 493
Service Engine Soon Light
(Malfunction Indicator) .................... 210
Service Manuals ........................ 495
Setting the Clock ................ 237,251,254,263
Settings, Personal ........................ 231
Shift Lock Manual Override ................ 303
Shifting Automatic Transmission ................. 305
Transfer Case ................. 309,312,315,318
Shoulder Belts ........................... 42
Side View Mirror Adjustment ................ 95
Side Window Demisters (Defrosters) .......... 292
Signals, Turn ................. 88,152,211,462,464
Sky Slider Power Roof .................183,446Snow Chains (Tire Chains)
................. 360
Spare Tire .......................... 355,406
Spark Plugs ............................ 466
Specifications Fuel (Gasoline) ........................ 466
Oil .............................. 425,466
Speed Control (Cruise Control) .............. 160
Speedometer ........................... 211
Starting ............................. 26,299
Cold Weather ......................... 300
Emergency (Jump Starting) ............... 412
Engine Block Heater .................... 301
Engine Fails to Start .................... 300
Remote .............................. 26
Starting and Operating .................... 299
Starting Procedures ...................... 299
Steering Power ........................... 325,327
Tilt Column .......................... 159
516 INDEX
