TM-120
< ECU DIAGNOSIS >
TCM
*1: These numbers are prescribed by SAE J2012.
*2: These malfunctions cannot be displayed MIL if another malfunction is assigned to MIL.
DTC Alphabetical IndexINFOID:0000000005148693
NOTE:
If DTC U1000 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000. Refer to
TM-40, "
Diagnosis Procedure".
*1: These numbers are prescribed by SAE J2012.
*2: These malfunctions cannot be displayed MIL if another malfunction is assigned to MIL. P1772
P1772L C BRAKE SOLENOID TM-90
P1774 (2*) P1774 L C BRAKE SOLENOID TM-93
U1000U1000CAN COMM CIRCUIT TM-40
DTC
Items
(CONSULT- III screen terms) Reference
OBD- II
Except OBD- II
CONSULT- III GST (*1) CONSULT- III only
“TRANSMISSION”
Items
(CONSULT- III screen terms) DTC
Reference
OBD- II
Except OBD- II
CONSULT- III GST (*1) CONSULT- III only “TRANS-
MISSION”
1ST E/BRAKING —P1731TM-80
1GR INCORRECT RATIO P0731P0731TM-56
2GR INCORRECT RATIO P0732P0732TM-58
3GR INCORRECT RATIO P0733P0733TM-60
4GR INCORRECT RATIO P0734P0734TM-62
5GR INCORRECT RATIO P0735P0735TM-64
INTERLOCK P1730P1730TM-78
TORQUE CONVERTER P0744 P0744 TM-68
FLUID TEMP SENSOR P0710P1710TM-73
CAN COMM CIRCUIT U1000U1000TM-40
DRCT CLUTCH SOLENOID P1762P1762 TM-86
ENGINE SPEED —P0725TM-53
FR BRAKE SOLENOID P1757P1757TM-84
HLR CLUTCH SOLENOID P1767P1767TM-88
INPUT CLUTCH SOLENOID P1752P1752TM-82
PC SOLENOID A P0745P0745TM-69
L C BRAKE SOLENOID P1772P1772TM-90
L C BRAKE SOLENOID P1774 P1774 TM-93
T/M RANGE SWITCH A P0705P0705TM-45
STARTER RELAY —P0615TM-41
TORQUE CONVERTER P0740P0740TM-65
TRANSMISSION CONTROL P0700P0700TM-44
TP SENSOR —P1705TM-71
INPUT SPEED SENSOR A P0717P0717TM-48
VEHICLE SPEED SIGNAL —P1721TM-76
OUTPUT SPEED SENSOR P0720P0720TM-51
Revision: April 20092010 QX56

SYSTEM SYMPTOMTM-121
< SYMPTOM DIAGNOSIS >
CEF
G H
I
J
K L
M A
B
TM
N
O P
SYMPTOM DIAGNOSIS
SYSTEM SYMPTOM
Symptom TableINFOID:0000000005148715
• The diagnostics item numbers s how the sequence for inspection. Inspect in order from item 1.
• Overhaul and inspect inside the A/T only if A/T fluid condition is NG. Refer to TM-148, "
Checking the
A/T Fluid (ATF)".
No. ItemsSymptom Condition Diagnostic ItemReference
page
1
Shift
Shock Large shock. (“N”
→“
D” position) ON vehicle1. Engine idle speed
EC-17
2. Engine speed signalTM-53
3. Accelerator pedal position sensorTM-71
4. Control cable adjustmentTM-164
5. ATF temperature sensor TM-73
6. Front brake solenoid valveTM-84
7. CAN communication line LAN-4
8. Fluid level and stateTM-148
9. Line pressure testTM-157
10. Control valve with TCMTM-172
OFF vehicle11. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to
TM-8, TM-9 . TM-204
2 Shock is too large
when changing D1→
D
2. ON vehicle1. Accelerator pedal position sensor
TM-71
2. Control cable adjustmentTM-164
3. Direct clutch solenoid valve TM-86
4. CAN communication line LAN-4
5. Engine speed signalTM-53
6. Input speed sensorTM-48
7. Output speed sensor and vehicle speed signalTM-50,
TM-76
8. Fluid level and state TM-148
9. Control valve with TCMTM-172
OFF vehicle 10. Direct clutch TM-239
3Shock is too large
when changing D2→
D
3. ON vehicle1. Accelerator pedal position sensor
TM-71
2. Control cable adjustmentTM-164
3. High and low reverse clutch solenoid valve TM-88
4. CAN communication line LAN-4
5. Engine speed signalTM-53
6. Input speed sensorTM-48
7. Output speed sensor and vehicle speed signalTM-50,
TM-76
8. Fluid level and state TM-148
9. Control valve with TCMTM-172
OFF vehicle 10. High and low reverse clutch TM-237
Revision: April 20092010 QX56

TM-122
< SYMPTOM DIAGNOSIS >
SYSTEM SYMPTOM
4Shift
Shock Shock is too large
when changing D3→
D
4. ON vehicle1. Accelerator pedal position sensor
TM-71
2. Control cable adjustmentTM-164
3. Input clutch solenoid valve TM-82
4. CAN communication line LAN-4
5. Engine speed signalTM-53
6. Input speed sensorTM-48
7. Output speed sensor and vehicle speed signalTM-50,
TM-76
8. Fluid level and state TM-148
9. Control valve with TCMTM-172
OFF vehicle 10. Input clutch TM-227
5Shock is too large
when changing D4→
D
5. ON vehicle1. Accelerator pedal position sensor
TM-71
2. Control cable adjustmentTM-164
3. Front brake solenoid valve TM-84
4. CAN communication line LAN-4
5. Engine speed signalTM-53
6. Input speed sensorTM-48
7. Output speed sensor and vehicle speed signalTM-50,
TM-76
8. Fluid level and state TM-148
9. Control valve with TCMTM-172
OFF vehicle10. Front brake (brake band)
TM-19211. Input clutchTM-227
6Shock is too large for
downshift when accel-
erator pedal is
pressed. ON vehicle1. Accelerator pedal position sensor
TM-71
2. Control cable adjustmentTM-164
3. CAN communication line LAN-4
4. Engine speed signalTM-53
5. Input speed sensorTM-48
6. Output speed sensor and vehicle speed signalTM-50,
TM-76
7. Fluid level and state TM-148
8. Control valve with TCMTM-172
OFF vehicle9. Front brake (brake band)
TM-19210. Input clutchTM-227
11. High and low reverse clutchTM-237
12. Direct clutchTM-239
No. ItemsSymptom Condition Diagnostic ItemReference
page
Revision: April 20092010 QX56

SYSTEM SYMPTOMTM-123
< SYMPTOM DIAGNOSIS >
CEF
G H
I
J
K L
M A
B
TM
N
O P
7
Shift
Shock Shock is too large for
upshift when accelera-
tor pedal is released.
ON vehicle1. Accelerator pedal position sensor
TM-71
2. Control cable adjustmentTM-164
3. Engine speed signal TM-53
4. CAN communication line LAN-4
5. Input speed sensorInput speed sensorTM-48
6. Output speed sensor and vehicle speed signalTM-50,
TM-76
7. Fluid level and state TM-148
8. Control valve with TCMTM-172
OFF vehicle9. Front brake (brake band)
TM-19210. Input clutchTM-227
11. High and low reverse clutchTM-237
12. Direct clutchTM-239
8Shock is too large for
lock-up. ON vehicle1. Accelerator pedal position sensor
TM-71
2. Control cable adjustmentTM-164
3. Engine speed signal TM-53
4. CAN communication line LAN-4
5. Input speed sensorTM-48
6. Output speed sensor and vehicle speed signalTM-50,
TM-76
7. Torque converter clutch solenoid valve TM-65
8. Fluid level and stateTM-148
9. Control valve with TCMTM-172
OFF vehicle 10. Torque converter TM-172
9Shock is too large dur-
ing engine brake. ON vehicle
1. Accelerator pedal position sensor
TM-71
2. Control cable adjustmentTM-164
3. CAN communication line LAN-4
4. Fluid level and stateTM-148
5. Control valve with TCMTM-172
OFF vehicle6. Front brake (brake band)
TM-1727. Input clutchTM-172
8. High and low reverse clutchTM-172
9. Direct clutchTM-172
No. ItemsSymptom Condition Diagnostic ItemReference
page
Revision: April 20092010 QX56

TM-124
< SYMPTOM DIAGNOSIS >
SYSTEM SYMPTOM
10No Up
Shift Gear does not change
from D →
D2. ON vehicle 1. Fluid level and state
TM-148
2. Output speed sensor and vehicle speed signal TM-50,
TM-76
3. Direct clutch solenoid valve TM-86
4. Line pressure testTM-157
5. CAN communication line LAN-4
6. Control valve with TCMTM-172
OFF vehicle 7. Direct clutch TM-172
11Gear does not change
from D → D
3. ON vehicle 1. Fluid level and state
TM-148
2. Output speed sensor and vehicle speed signal TM-50,
TM-76
3. High and low reverse clutch solenoid valve TM-88
4. Line pressure testTM-157
5. CAN communication line LAN-4
6. Control valve with TCMTM-172
OFF vehicle 7. High and low reverse clutch TM-172
12Gear does not change
from D →
D4. ON vehicle 1. Fluid level and state
TM-148
2. Output speed sensor and vehicle speed signal TM-50,
TM-76
3. Input clutch solenoid valve TM-82
4. Front brake solenoid valveTM-84
5. Line pressure testTM-157
6. CAN communication line LAN-4
7. Control valve with TCMTM-172
OFF vehicle 8. Input clutch TM-172
13Gear does not change
from D →
D5. ON vehicle 1. Fluid level and state
TM-148
2. Output speed sensor and vehicle speed signal TM-50,
TM-76
3. Front brake solenoid valve TM-84
4. Direct clutch solenoid valveTM-86
5. Input speed sensorTM-48
6. Line pressure testTM-157
7. CAN communication line LAN-4
8. Control valve with TCMTM-172
OFF vehicle9. Front brake (brake band)
TM-17210. Input clutchTM-172
No. ItemsSymptom Condition Diagnostic ItemReference
page
Revision: April 20092010 QX56

SYSTEM SYMPTOMTM-125
< SYMPTOM DIAGNOSIS >
CEF
G H
I
J
K L
M A
B
TM
N
O P
14
No Down
Shift In “D” or "4" range,
does not downshift to
4GR.
ON vehicle1. Fluid level and state
TM-148
2. Output speed sensor and vehicle speed signal TM-50,
TM-76
3. Front brake solenoid valve TM-84
4. Direct clutch solenoid valveTM-86
5. CAN communication line LAN-4
6. Line pressure testTM-157
7. Control valve with TCMTM-172
OFF vehicle8. Front brake (brake band)
TM-1729. Input clutchTM-172
15In “D” or "3" range,
does not downshift to
3GR. ON vehicle1. Fluid level and state
TM-148
2. Output speed sensor and vehicle speed signal TM-50,
TM-76
3. Input clutch solenoid valve TM-82
4. Front brake solenoid valveTM-84
5. CAN communication line LAN-4
6. Line pressure testTM-157
7. Control valve with TCMTM-172
OFF vehicle 8. Input clutch TM-172
16In “D” or "2" range,
does not downshift to
2GR.
. ON vehicle1. Fluid level and state
TM-148
2. Output speed sensor and vehicle speed signal TM-50,
TM-76
3. High and low reverse clutch solenoid valve TM-88
4. CAN communication line LAN-4
5. Line pressure testTM-157
6. Control valve with TCMTM-172
OFF vehicle 7. High and low reverse clutch TM-172
17In “D” or "1" range,
does not downshift to
1GR. ON vehicle1. Fluid level and state
TM-148
2. Output speed sensor and vehicle speed signal TM-50,
TM-76
3. Direct clutch solenoid valve TM-86
4. CAN communication line LAN-4
5. Line pressure testTM-157
6. Control valve with TCMTM-172
OFF vehicle 7. Direct clutch TM-172
No. ItemsSymptom Condition Diagnostic ItemReference
page
Revision: April 20092010 QX56

TM-126
< SYMPTOM DIAGNOSIS >
SYSTEM SYMPTOM
18Slips/Will
Not en-
gage When “D” position, re-
mains in 1GR.
ON vehicle
1. Fluid level and state
TM-148
2. Output speed sensor and vehicle speed signal TM-50,
TM-76
3. Direct clutch solenoid valve TM-86
4. Line pressure testTM-157
5. CAN communication line LAN-4
6. Control valve with TCMTM-172
OFF vehicle7. 3rd one-way clutch
TM-225
8. 1st one-way clutchTM-232
9. Gear systemTM-172
10. Reverse brakeTM-172
11. Forward one-way clutch (Parts behind drum support is im-
possible to perform inspection by disassembly. Refer to TM-
8, TM-9. TM-172
12. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to
TM-8
, TM-9. TM-172
19 When “D” position, re-
mains in 2GR. ON vehicle1. Fluid level and state
TM-148
2. Output speed sensor and vehicle speed signal TM-50,
TM-76
3. Low coast brake solenoid valve TM-90
4. Line pressure testTM-157
5. CAN communication line LAN-4
6. Control valve with TCMTM-172
OFF vehicle7. 3rd one-way clutch
TM-172
8. Gear systemTM-172
9. Direct clutchTM-172
10. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to TM-8
, TM-9. TM-172
No. Items
Symptom Condition Diagnostic ItemReference
page
Revision: April 20092010 QX56

SYSTEM SYMPTOMTM-127
< SYMPTOM DIAGNOSIS >
CEF
G H
I
J
K L
M A
B
TM
N
O P
20
Slips/Will
Not en-
gage When “D” position, re-
mains in 3GR.
ON vehicle
1. Fluid level and state
TM-148
2. Output speed sensor and vehicle speed signal TM-50,
TM-76
3. Line pressure test TM-157
4. CAN communication line LAN-4
5. Control valve with TCMTM-172
OFF vehicle6. 3rd one-way clutch
TM-172
7. Gear systemTM-172
8. High and low reverse clutchTM-172
9. Forward one-way clutch (Parts behind drum support is im-
possible to perform inspection by disassembly. Refer to TM-
8, TM-9. TM-172
10. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to
TM-8
, TM-9. TM-172
21 When “D” position, re-
mains in 4GR. ON vehicle1. Fluid level and state
TM-148
2. Output speed sensor and vehicle speed signal TM-50,
TM-76
3. Input clutch solenoid valve TM-82
4. Direct clutch solenoid valveTM-86
5. High and low reverse clutch solenoid valveTM-88
6. Low coast brake solenoid valveTM-90
7. Front brake solenoid valveTM-84
8. Line pressure testTM-157
9. CAN communication line LAN-4
10. Control valve with TCMTM-172
OFF vehicle11. Input clutch
TM-17212. Gear systemTM-172
13. High and low reverse clutchTM-172
14. Direct clutchTM-172
No. ItemsSymptom Condition Diagnostic ItemReference
page
Revision: April 20092010 QX56
