2010 INFINITI QX56 sensor

P0717 INPUT SPEED SENSOR ATM-49
< COMPONENT DIAGNOSIS >
CEF
G H
I
J
K L
M A
B
TM
N
O P
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to TM-94, "
Diagnosis Procedure".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTIONING ITEM
Check the following items:
• The A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the control valve with TCM. Refer to TM-172, "Control Valve with TCM and A/T Fluid
Temperature Sensor 2 and Plug".
NG >> Repair or replace damaged parts.
4.CHECK DTC
Perform “DTC Confirmation Procedure”.
• Refer to TM-48, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> GO TO 2.
Item name Condition Display value (rpm)
INPUT SPEED During driving (lock-up ON) Approximately matche s the engine speed.
Revision: April 20092010 QX56

TM-50
< COMPONENT DIAGNOSIS >
P0720 OUTPUT SPEED SENSOR
P0720 OUTPUT SPEED SENSOR
DescriptionINFOID:0000000005148556
The output speed sensor detects the revolution of the idler gear parking pawl lock gear and emits a pulse sig-
nal. The pulse signal is sent to the TCM which converts it into vehicle speed.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000005148557
On Board Diagn osis LogicINFOID:0000000005148558
• This is an OBD-II self-diagnostic item.
• Diagnostic trouble code “P0720 OUTPUT SPEED SENSOR” with CONSULT-III is detected under the follow-
ing conditions.
- When TCM does not receive the proper voltage signal from the sensor.
- After ignition switch is turned “ON”, irregular signal input from vehicle speed signal before the vehicle starts
moving.
Possible CauseINFOID:0000000005148559
• Harness or connectors (The sensor circuit is open or shorted.)
• Output speed sensor
• Vehicle speed signal
DTC Confirmation ProcedureINFOID:0000000005148560
CAUTION:
• Always drive vehicle at a safe speed.
• Be careful not to rev engine into the red zone on the tachometer.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following proc edure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Drive vehicle and check for an increase of “VHCL/ S SE-A/T” value in response to “VHCL/S SE-MTR”
value.
If the check result is NG, go to TM-51, "
Diagnosis Procedure".
If the check result is OK, go to following step.
4. Select “DATA MONITOR” mode for “ENGINE” with CONSULT-III.
5. Start engine and maintain the following conditions for at least 5 consecutive seconds. VHCL/S SE-A/T: 30 km/h (19 MPH) or more
ACCELE POSI: More than 1.0/8
SLCT LVR POSI: “D” position
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving
conditions required for this test.
If the check result is NG, go to TM-51, "
Diagnosis Procedure".
If the check result is OK, go to following step.
6. Maintain the following conditions for at least 5 consecutive seconds. ENGINE SPEED: 3,500 rpm or more
ACCELE POSI: More than 1.0/8
SLCT LVR POSI: “D” position
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving
conditions required for this test.
If the check result is NG, go to TM-51, "
Diagnosis Procedure".
Item name Condition Display value (km/h)
VHCL/S SE-A/T During driving Approximately matches the speedometer reading.
Revision: April 20092010 QX56

P0720 OUTPUT SPEED SENSORTM-51
< COMPONENT DIAGNOSIS >
CEF
G H
I
J
K L
M A
B
TM
N
O P
WITH GST
Follow the procedure “With CONSULT-III”.
Diagnosis ProcedureINFOID:0000000005148561
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Turn ignition switch “ON”.
2. Select “ECU INPUT SIGNALS” in “DATA MONITO R” mode for “TRANSMISSION” with CONSULT-III.
3. Start the engine.
4. Read out the value of “VHCL /S SE·A/T” while driving.
Check the value changes according to driving speed.
OK or NG
OK >> GO TO 6.
NG >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to TM-94, "
Diagnosis Procedure".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTIONING ITEM
Check the following items:
• The A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4.CHECK SUB-HARNESS
1. Remove control valve with TCM. Refer to TM-172, "
Control Valve with TCM and A/T Fluid Temperature
Sensor 2 and Plug".
2. Disconnect transmission range switch connector and TCM connector.
3. Check continuity between transmission range switch connector (A) terminals and TCM connector (B) terminals.
4. If OK, check harness for short to ground and short to power.
5. Reinstall any part removed.
OK or NG
OK >> GO TO 5.
NG >> Replace open circuit or short to ground and short to power in harness or connectors.
Item name Condition Display value (km/h)
VHCL/S SE-A/T During driving Approximately matches the speedometer reading.
ItemConnector Terminal Continuity
Transmission range switch connector F505
8
Ye s
TCM connector F50320
Transmission range switch connector F505
9
Ye s
TCM connector F50317
Transmission range switch connector F505
10
Ye s
TCM connector F50316
JSDIA1329GB
Revision: April 20092010 QX56

TM-52
< COMPONENT DIAGNOSIS >
P0720 OUTPUT SPEED SENSOR
5.REPLACE THE OUTPUT SPEED SENSOR AND CHECK DTC
1. Replace the output speed sensor. Refer to TM-204, "
Disassembly".
2. Perform “DTC Confirmation Procedure”. Refer to TM-50, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> Replace the control valve with TCM. Refer to TM-172, "
Control Valve with TCM and A/T Fluid
Temperature Sensor 2 and Plug".
6.CHECK DTC
Perform “DTC Confirmation Procedure”.
• Refer to TM-50, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> GO TO 2.
Revision: April 20092010 QX56

TM-54
< COMPONENT DIAGNOSIS >
P0725 ENGINE SPEED
NG >> Check the ignition signal circuit. Refer to EC-407, "Diagnosis Procedure".
3.CHECK DTC
Perform "DTC Confirmation Procedure".
• Refer to TM-53, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> GO TO 4.
4.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to TM-94, "
Diagnosis Procedure".
OK or NG
OK >> GO TO 5.
NG >> Repair or replace damaged parts.
5.DETECT MALFUNCTIONING ITEM
Check the following items:
• The A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the control valve with TCM. Refer to TM-172, "Control Valve with TCM and A/T Fluid
Temperature Sensor 2 and Plug".
NG >> Repair or replace damaged parts.
Revision: April 20092010 QX56

TM-56
< COMPONENT DIAGNOSIS >
P0731 1GR INCORRECT RATIO
Diagnosis Procedure
INFOID:0000000005148572
1.CHECK CAN COMMUNICATION LINE
Perform self-diagnosis. Refer to TM-32, "
CONSULT-III Functi on (TRANSMISSION)".
Is a malfunction in the CAN communication indicated in the results?
YES >> Check CAN communication line. Refer to TM-40, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to TM-94, "
Diagnosis Procedure".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTION ITEM
Check A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4.REPLACE CONTROL VALVE WITH TCM
1. Replace control valve with TCM. Refer to TM-172, "
Control Valve with TCM and A/T Fluid Temperature
Sensor 2 and Plug".
2. Perform TM-55, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> Confirm malfunction phenomena by “ROAD TEST” to repair malfunctioning part. Refer to TM-159,
"Description".
Revision: April 20092010 QX56

TM-58
< COMPONENT DIAGNOSIS >
P0732 2GR INCORRECT RATIO
Diagnosis Procedure
INFOID:0000000005148577
1.CHECK CAN COMMUNICATION LINE
Perform self-diagnosis. Refer to TM-32, "
CONSULT-III Functi on (TRANSMISSION)".
Is a malfunction in the CAN communication indicated in the results?
YES >> Check CAN communication line. Refer to TM-40, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to TM-94, "
Diagnosis Procedure".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTION ITEM
Check A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4.REPLACE CONTROL VALVE WITH TCM
1. Replace control valve with TCM. Refer to TM-172, "
Control Valve with TCM and A/T Fluid Temperature
Sensor 2 and Plug".
2. Perform TM-57, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> Confirm malfunction phenomena by “ROAD TEST” to repair malfunctioning part. Refer to TM-159,
"Description".
Revision: April 20092010 QX56

TM-60
< COMPONENT DIAGNOSIS >
P0733 3GR INCORRECT RATIO
Diagnosis Procedure
INFOID:0000000005148582
1.CHECK CAN COMMUNICATION LINE
Perform self-diagnosis. Refer to TM-32, "
CONSULT-III Functi on (TRANSMISSION)".
Is a malfunction in the CAN communication indicated in the results?
YES >> Check CAN communication line. Refer to TM-40, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to TM-94, "
Diagnosis Procedure".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTION ITEM
Check A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4.REPLACE CONTROL VALVE WITH TCM
1. Replace control valve with TCM. Refer to TM-172, "
Control Valve with TCM and A/T Fluid Temperature
Sensor 2 and Plug".
2. Perform TM-59, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> Confirm malfunction phenomena by “ROAD TEST” to repair malfunctioning part. Refer to TM-159,
"Description".
Revision: April 20092010 QX56
