2010 INFINITI G37 headlight bulb

SEDAN 1. Hood (P. 3-17)
2. Headlight and turn signal
— Operation (P. 2-32)
— Bulb replacement (P. 8-16) 3. Windshield wiper and washer
— Operation (P. 2-30)
— Maintenance (P. 8-18)
4. Moonroof (if so equipped) (P. 2-52)
5. Power windows (P. 2-49)
6. Recovery hook (P. 6-13) 7. Fog light (P. 2-37)
8. Tires
— Wheel and tires (P. 8-28, P. 9-9)
— Flat tire ( 6-2)
— Tire pressure monitoring system
(TPMS) (P. 2-14, P. 5-3)
9. Outside mirrors (P. 3-26)
10. Doors
— Keys (P. 3-2)
— Door locks (P. 3-4)
— Intelligent Key system (P. 3-7)
— Remote keyless entry system (P. 3-14)
SSI0643EXTERIOR FRONT
Illustrated table of contents
0-3
 —
—
10/12/09—tbrooks


COUPE 1. Hood (P. 3-17)
2. Headlight and turn signal
— Operation (P. 2-32)
— Bulb replacement (P. 8-23)
— Fog light (P. 2-37) 3. Windshield wiper and washer
— Operation (P. 2-30)
— Maintenance (P. 8-18)
4. Moonroof (if so equipped) (P. 2-52)
5. Power windows (P. 2-49)
6. Recovery hook (P. 6-13) 7. Tires
— Wheel and tires (P. 8-28, P. 9-9)
— Flat tire ( 6-2)
— Tire pressure monitoring system (TPMS)
(P. 2-14, P. 5-3)
8. Outside mirrors (P. 3-26)
9. Doors
— Keys (P. 3-2)
— Door locks (P. 3-4)
— Intelligent Key system (P. 3-7)
— Remote keyless entry system (P. 3-14)
SSI0342
0-4 Illustrated table of contents
 —
—
10/12/09—tbrooks


2 Instruments and controls Cockpit ........................................... 2-2
Instrument panel .................................. 2-3
Meters and gauges ................................ 2-4
Speedometer and odometer ..................... 2-5
Tachometer .................................... 2-6
Engine coolant temperature gauge ............... 2-6
Fuel gauge ..................................... 2-7
Compass (if so equipped) .......................... 2-8
Zone variation change procedure ................ 2-9
Warning/indicator lights and audible reminders ...... 2-11
Checking bulbs ................................ 2-11
Warning lights ................................ 2-12
Indicator lights ................................ 2-16
Audible reminders ............................. 2-18
Dot matrix liquid crystal display ................... 2-19
Indicators for operation ........................ 2-21
Indicators for maintenance ..................... 2-23
Trip computer ................................. 2-24
Security systems ................................. 2-27
Vehicle security system ........................ 2-27
INFINITI Vehicle Immobilizer System ............ 2-29
Windshield wiper and washer switch ............... 2-30 Rain-sensing auto wiper system
(if so equipped) ............................... 2-31
Rear window and outside mirror defroster switch . . . 2-32
Headlight and turn signal switch .................. 2-32
Xenon headlights ............................. 2-32
Headlight switch .............................. 2-33
Turn signal switch ............................. 2-37
Fog light switch ............................... 2-37
Hazard warning flasher switch ..................... 2-37
Horn ............................................ 2-38
Heated seats (if so equipped) ..................... 2-38
SNOW mode switch (if so equipped) ............... 2-40
Vehicle Dynamic Control (VDC) OFF switch .......... 2-40
Clock ............................................ 2-40
Adjusting the time ............................. 2-40
Power outlet ..................................... 2-41
Cigarette lighter and ashtrays (if so equipped) ...... 2-42
Front ......................................... 2-42
Rear ......................................... 2-42
Storage ......................................... 2-43
Cup holders .................................. 2-43
Sunglasses holder ............................. 2-45
 —
—
10/12/09—tbrooks


When the xenon headlight is initially turned on,
its brightness or color varies slightly. However,
the color and brightness will soon stabilize.
● The life of xenon headlights will be shortened
by frequent on-off operation. It is generally
desirable not to turn off the headlights for
short intervals (for example, when the ve-
hicle stops at a traffic signal). Even when the
daytime running lights are active (Canada
only), the xenon headlights do not turn on.
This way the life of the xenon headlights is
not reduced.
● If the xenon headlight bulb is close to burn-
ing out, the brightness will drastically de-
crease, the light will start blinking, or the
color of the light will become reddish. If one
or more of the above signs appear, contact an
INFINITI retailer.
HEADLIGHT SWITCH
Lighting
 1
Turn the switch to the position:
The front park, side marker, tail, license
plate and instrument lights will come on.
 2
Turn the switch to the position:
Headlights will come on and all the other
lights remain on. Autolight system (if so equipped) The autolight system allows the headlights to
be set so they turn on and off automatically.
To set the autolight system:
1. Make sure the headlight switch is in the
AUTO position
 1
.
2. Push the ignition switch to the ON posi-
tion.
3. The autolight system automatically turns
the headlights on and off.
To turn the autolight system off, turn the switch
to the OFF, or position.SIC3267 SIC3268
Instruments and controls
2-33
 —
—
10/12/09—tbrooks


HEADLIGHTS
Replacing Xenon headlight bulb :
WARNING
HIGH VOLTAGEWhen xenon headlights are on, they produce a
high voltage. To prevent an electric shock,
never attempt to modify or disassemble. Al-
ways have your xenon headlights replaced at
an INFINITI retailer. For additional information,
see “HEADLIGHT AND TURN SIGNAL SWITCH” in
the “2. Instruments and controls” section.
Use the same number and wattage shown in the
following chart as originally installed.
If replacement is required, see an INFINITI re-
tailer.
Fog may temporarily form inside the lens of the
exterior lights in the rain or in a car wash. A
temperature difference between the inside and
the outside of the lens causes the fog. This is
not a malfunction. If large drops of water collect
inside the lens, contact an INFINITI retailer. EXTERIOR AND INTERIOR LIGHTS
Sedan Item Wattage (W) Bulb No.
Headlight*
High/Low beams (xenon) 35 D2S
Front turn signal light* 28 7444NA
Front fog light* 35 H8
Clearance light* 8 7444NA
Front side marker light* 5 WY5W
Rear combination light*
back-up 16 W16W
turn signal 21 W21W
stop/tail/side marker LED —
License plate light* 5 W5W
Map light 8 —
Rear personal light 8 —
Vanity mirror light 2 —
Step light* 8 —
Trunk light* 3.4 —
High-mounted stop light* LED —
*: See an INFINITI retailer for replacement.
NOTE: Always check with the Parts Department at an INFINITI retailer for the latest information about
parts.
Maintenance and do-it-yourself
8-25
 —
—
04/21/10—debbie


Coupe Item Wattage (W) Bulb No.
Headlight*
High/Low beams (xenon) 35 D2S
Front turn signal light* 21 WY21W
Front fog light* 55 H1
Clearance light* 5 W5W
Front side marker light* 5 W5W
Rear combination light*
back-up 16 W16W
turn signal 21 W21W
stop/tail/side marker LED —
License plate light* 5 W5W
Map light 8 —
Vanity mirror light 2 —
Step light* 8 —
Trunk light* 3.4 —
High-mounted stop light* LED —
*: See an INFINITI retailer for replacement.
NOTE: Always check with the Parts Department at an INFINITI retailer for the latest information about
parts.
8-26 Maintenance and do-it-yourself
 —
—
04/21/10—debbie


Engine start operation indicator (Manual
Transmission models) ........... 2-22
If your vehicle overheats ......... 6-10
Starting the engine ............. 5-11
Engine coolant temperature gauge ..... .2-6
Entry/exit function .............. .3-28
Event Data Recorders (EDR) ......... .9-25
Exhaust gas (carbon monoxide) ....... .5-2
F
F.M.V.S.S./C.M.V.S.S. certification label . . .9-13
Filter
Air cleaner housing filter ........ .8-17
Changing engine oil and filter .......8-9
Flashers (See hazard warning
flasher switch) ................ .2-37
Flat tire ..................... .6-2
Flat towing .................. .9-21
Floor mat cleaning ............... .7-5
Fluid
Automatic transmission fluid (ATF) . . . .8-11
Brake and clutch fluid ........... 8-12
Capacities and recommended fuel/
lubricants ..................9-2
Engine coolant ...............8-7
Engine oil ..................8-8
Power steering fluid ............ 8-11
Window washer fluid ........... 8-13
FM-AM-SAT radio with Compact Disc (CD)
player ..................... .4-54
Fog light switch ............... .2-37
Front passenger air bag and status light . .1-47
Front power seat adjustment ......... .1-3
Front seat, Front seat adjustment ...... .1-3 Front-seat active head restraints ...... .1-11
Fuel
Capacities and recommended fuel/
lubricants .................. .9-2
Fuel economy ............... 5-42
Fuel economy information (display) ....4-9
Fuel octane rating .............9-4
Fuel recommendation ...........9-4
Fuel-filler cap ................ 3-21
Fuel-filler door ............... 3-21
Gauge ....................2-7
Fuses ..................... .8-20
Fusible links ................. .8-21
G
Garage
door opener, HomeLink  Universal
Transceiver .................. .2-57
Gascap .................... .3-21
Gauge ...................... .2-4
Gauge
Engine coolant temperature gauge . . . .2-6
Fuel gauge ..................2-7
Odometer ..................2-5
Speedometer ................2-5
Tachometer .................2-6
Trip computer ............... 2-24
General maintenance ............. .8-2
Glove box ................... .2-45
Golf bag stowing ............... .2-48 H
Hands-free phone system, Bluetooth
(with navigation system) .......... .4-85
Hands-free phone system, Bluetooth
(without navigation system) ........ .4-96
Hazard warning flasher switch . . ..... .2-37
Head restraints ................. .1-9
Headlights
Bulb replacement ............ .8-25
Headlight switch .............. 2-33
Xenon headlights ............. 2-32
Heated seats ................. .2-38
Heater
Automatic climate control ........ .4-28
Engine block heater ............ 5-56
HomeLink  Universal Transceiver ...... .2-57
Hood release ................. .3-17
Hook, Coat hooks .............. .2-48
Horn ...................... .2-38
Ignition switch
Automatic transmission models ..... .5-12
Manual transmission models . . . . . . . 5-16
I
Ignition switch (Push-button) ......... .5-7
Immobilizer system ............. .2-29
In-cabin microfilter .............. .4-38
Indicator
lights ................ .2-16
Indicator,
Dot matrix display ........ .2-19
INFINITI Vehicle Immobilizer System .... .2-29
INFINITI voice recognition standard
mode ..................... .4-109
10-3
 —
—
04/30/10—diane


INFINITI voice recognition system ..... .4-109
INFO button .................. .4-8
Inside mirror ................. .3-25
Inspection/maintenance (I/M) test ..... .9-24
Instrument brightness control ....... .2-36
Instrument panel ............... .2-3
Intelligent cruise control (ICC) system . . . .5-21
Intelligent cruise control (ICC) system main
switch indicator ............... .2-23
Intelligent Cruise Control (ICC) system
warning light ................. .2-14
Intelligent cruise control (ICC) system,
Preview function ............... .5-42
Intelligent Key ................. .3-2
Intelligent Key battery discharge
indicator .................... .2-22
Intelligent Key insertion indicator ..... .2-21
Intelligent Key removal indicator ...... .2-21
Intelligent Key system ............. .3-7
Intelligent Key system
Battery replacement ........... .8-22
Key operating range ............3-8
Key operation ............... 3-10
Warning light ................ 2-14
Warning signals .............. 3-12
Intelligent Key warning light ........ .2-14
Interior light control switch ......... .2-55
Interior light replacement .......... .8-25
Interior lights ................. .2-54
Interior trunk lid release .......... .3-20
iPod  player operation ............ .4-71
ISOFIX child restraint ............. .1-22 J
Jump starting .................. .6-7
K
Keyless entry (See remote keyless entry
system) .................... .3-14
Keys ....................... .3-2
Keys, For Intelligent Key system ....... .3-7
Labels
Air bag warning labels .......... .1-53
Air conditioner specification label .... 9-14
Emission
control
information label .... 9-13
Engine serial number ........... 9-12
F.M.V.S.S./C.M.V.S.S. certification
label ..................... 9-13
Tire and Loading information label . . . 9-14
Vehicle identification number (VIN) . . . 9-12
L
LATCH system ................. .1-22
License plate, Installing front license plate .9-15
Light
Air bag warning light ........... .1-53
Bulb replacement ............. 8-23
Fog light switch .............. 2-37
Headlight switch .............. 2-33
Headlights bulb replacement ....... 8-25
Indicator lights ............... 2-16
Interior light control switch ........ 2-55
Interior lights ............... 2-54 Map lights ................. 2-54
Trunk light ................. 2-56
Vanity mirror lights ............ 2-56
Warning/indicator lights and audible
reminders .................. 2-12
Xenon headlights ............. 2-32
Light replacement .............. .8-23
Lights, Exterior and interior light
replacement ................. .8-25
Loading information (See vehicle loading
information) .................. .9-17
Lock
Automatic door locks ........... .3-6
Door locks ..................3-4
Power door lock ...............3-4
Trunk lid .................. 3-18
Locking with mechanical key ......... .3-4
Low fuel warning ............... .2-22
Low outside temperature warning ..... .2-22
Low tire pressure warning light . . ..... .2-14
Low tire pressure warning system (See tire
pressure monitoring system (TPMS)) .... .5-3
Low washer fluid warning .......... .2-22
Maintenance
Battery ................... .8-13
General maintenance ............8-2
Indicators for maintenance
(dot
matrix) ................ 2-23
Inside
the vehicle ..............8-3
Maintenance precautions .........8-5
Maintenance requirements . . ......8-2
Outside the vehicle .............8-2
Seat belt maintenance .......... 1-20
10-4
 —
—
04/30/10—diane
