2010 INFINITI G37 bluetooth

Bluetooth  Audio player (models with
navigation system) ● Some Bluetooth  audio devices may not be
recognized by the in-vehicle audio system.
● It is necessary to set up the wireless connec-
tion between a compatible Bluetooth  audio
device and the in-vehicle Bluetooth  module
before using the Bluetooth  audio player.
● Operating procedure of the Bluetooth  audio
player will vary depending on the device.
Make sure it is understood how to operate
an audio device before using it with this
system.
● The Bluetooth  audio player may be stopped
under the following conditions:
– Receiving a hands-free call.
– Checking the connection to the hands-
free phone.
● Do not place a Bluetooth  audio device in an
area surrounded by metal or far away from
the in-vehicle Bluetooth  module to prevent
tone quality degradation and wireless con-
nection disruption.
● While an audio device is connected through
a Bluetooth  wireless connection, the bat-
tery power of the device may discharge
quicker than usual. ● This system supports the Bluetooth  Audio
Distribution Profile (A2DP, AVRCP).
● Bluetooth  is a trademark owned by
Bluetooth SIG, Inc. and licensed to Clarion
Co., Ltd.
Music Box hard drive Recording :
● Note that data that is lost and not stored to
the hard disk drive due to system damage,
improper operation or malfunction is not
under warranty.
● Vehicle owners are not permitted to record
music without permission of the owner of
the copyright except for personal use.
● Check if the music is appropriately recorded
to the hard disk drive after recording when
the compact disc cannot be rerecorded.
● Some music cannot be recorded depending
on the disc condition due to high-speed
recording.
● Jumping sounds may be recorded when a
compact disc is recorded while driving on
rough roads and excessive vibration occurs.
● A mark indicating jumping sounds is dis-
played if jumping sounds are recorded. ● No sounds may be recorded if jumping
sounds occurs or the disc is in poor condi-
tion.
● Tracks that include Serial Copy Management
System (SCMS) are not recorded.
● If a compact disc is scratched or dirty, it may
not be recorded, jumping sounds may occur
or it may take a long time to record.
Automatic title download :
● The title information that is automatically
downloaded may differ from the actual title.
● When newly released compact discs are
recorded, their title information may not be
downloaded.
● The title information in the hard disk can be
updated. (See “Playing recorded songs”
later in this section.
Monitor, climate, audio, phone and voice recognition systems
4-51
 —
—
04/21/10—debbie


This vehicle has some sound effect functions as
follows:
● Speed Sensitive Vol.
● Precision Phased Audio (if so equipped)
● Driver’s Audio Stage (if so equipped)
For more details, see “VEHICLE INFORMATION
AND SETTINGS” earlier in this section.
Switching the display (Type A) :
● Models with navigation system
Pushing the DISC·AUX button will switch the
displays as follows:
iPod  /USB → CD/DVD → Music Box →
Bluetooth  Audio → iPod  /USB
● Models without navigation system
Pushing the DISC button will switch the display
as follows:
CD → Music Box → CD
Pushing the AUX button will switch the display
as follows:
USB/iPod → XM1 → XM2 → XM3 → USB/iPod
FM-AM-SAT radio operation When the radio band select button is pushed
while the ignition switch is in the ACC or ON
position, the radio will come on at the channel
last played. The last channel played will also come on when
the ON·OFF button is pushed to ON.
The satellite radio is not available in Alaska,
Hawaii and Guam.
If another audio source is playing when the
radio or satellite band select button is turned to
ON, the audio source will automatically be
turned off and the last radio channel played will
come on.
When the stereo broadcast signal is weak, the
radio will automatically change from stereo to
monaural reception.
or radio (FM/AM/SAT) band
select (Type A) :
Pushing the RADIO AM·FM or FM·AM radio band
select button will change the band as follows:
● Models with navigation system
AM → FM1 → FM2 → XM1 → XM2 → XM3 → AM
● Models without navigation system
AM → FM1 → FM2 → AM
radio (SAT) band select (Type A) :
Push the satellite band select button to select
the satellite radio mode XM1, XM2 or XM3. radio (FM/AM/SAT) band select
(Type B) :
Pushing the radio band select button will
change the band as follows:
AM → FM → XM → AM
When the radio band select button is pushed
while the ignition switch is in the ACC or ON
position, the radio will come on at the station
last played.
TUNE (Tuning) :
● For AM and FM radio
Turn the radio TUNE knob for manual tuning.
● For XM Satellite Radio
Turn the radio TUNE knob to seek channels
from all of the categories when any category
is not selected.
SEEK tuning/CATEGORY
(CAT) :
● For AM and FM radio
Push the SEEK·CAT or TRACK button
or to tune from low to high or high to
low frequencies and to stop at the next
broadcasting station.
Monitor, climate, audio, phone and voice recognition systems
4-55
 —
—
04/21/10—debbie


Settings :
Select the “Settings” key to adjust the following
settings.
● Audio File Playback
Switch to the audio playback mode. This
item is displayed only when the USB
memory contains the audio files.
● Play Mode
Select the “Normal” or “1 Track Repeat” play
mode. ● 10 Key Search
Select the “10 Key Search” key to open the
number entry screen.
Input the number to be searched and select
the “OK” key.
The specified folder/file will be played.
● Display
To adjust the image quality of the screen,
select the preferred adjustment items.
● DRC
DRC (Dynamic Range Compression) auto-
matically adjusts the soundtrack volume
level to maintain a more even sound to the
speakers.
● Audio
Select the preferred language for audio.
● Subtitle
Select the preferred language for subtitle.
● Display Mode
Select the “Normal”, “Wide”, “Cinema” or
“Full” mode. BLUETOOTH  STREAMING AUDIO
(models with navigation system) Your INFINITI is equipped with Bluetooth  Stream-
ing Audio. If you have a compatible Bluetooth
device with streaming audio (A2DP profile), you
can set up the wireless connection between your
Bluetooth  device and the in-vehicle audio sys-
tem. This connection allows you to listen to the
audio from the Bluetooth  device using your
vehicle speakers. It also may allow basic control
of the device for playing and skipping audio files
using the AVRCP Bluetooth  profile. All
Bluetooth  Devices do not have the same level of
controls for AVRCP. Please consult the manual for
your Bluetooth  Device for more details.
Once your Bluetooth  device is connected to
the in-vehicle audio system, it will automati-
cally reconnect whenever the device is present
in the vehicle and you select Bluetooth  Audio
from your audio system. You do not need to
manually reconnect for each usage.
Regulatory information FCC Regulatory information :
– CAUTION: To maintain compliance with FCC’s
RF exposure guidelines, use only the sup-
plied antenna. Unauthorized antenna, modi-
fication, or attachments could damage the
transmitter and may violate FCC regulations.Example SAA2504
4-66 Monitor, climate, audio, phone and voice recognition systems
 —
—
04/21/10—debbie


– Operation is subject to the following two
conditions:
1) This device may not cause interference
and
2) This device must accept any interference,
including interference that may cause
undesired operation of the device
IC Regulatory information :
– Operation is subject to the following two
conditions:
1) This device may not cause interference,
and
2) This device must accept any interference,
including interference that may cause
undesired operation of the device.
– This Class B digital apparatus meets all
requirements of the Canadian Interference-
Causing Equipment Regulations.
Bluetooth trademark:
Bluetooth  is a trademark
owned by Bluetooth SIG,
Inc. and licensed to
Clarion Co., Ltd. Connecting procedure 1. Push the SETTING button and select the
“Bluetooth” key. 2. Select the “Connect Bluetooth” key. SAA2505 SAA2506
Monitor, climate, audio, phone and voice recognition systems
4-67
 —
—
04/21/10—debbie


3. A confirmation screen will be displayed.
Select “No”.
Note: Selecting “Yes” will only connect the
hands free phone portion of a Bluetooth
device. 4. Choose a PIN code to use with the com-
patible Bluetooth  audio device using the
number input screen. The PIN code will
need to be entered into the Bluetooth
audio device after step 5. Select the “OK”
key. 5. The standby message screen will appear.
Operate the compatible Bluetooth  audio
device. For the connecting procedure of
the audio device, see the Bluetooth  au-
dio instructions.
When the connecting is completed, the
screen will return to the Bluetooth  setup
display.SAA2507 SAA3005 SAA2509
4-68 Monitor, climate, audio, phone and voice recognition systems
 —
—
04/21/10—debbie


Audio main operation Push the ignition switch to the ACC or ON
position. Then, push the DISC·AUX button re-
peatedly to switch to the Bluetooth  audio
mode. If the system has been turned off while
the Bluetooth  audio device was playing, push-
ing the ON·OFF/VOL control knob will start the
Bluetooth  audio device.
The ability to pause, change tracks, fast for-
ward, rewind, randomize and repeat music may
be different between devices. Some or all of
these functions may not be supported on each
device. DISC·AUX button :
When the DISC·AUX button is pushed with the
system off and the Bluetooth  audio device
connected, the system will turn on. If another
audio source is playing and the Bluetooth
audio device is connected, push the DISC·AUX
button repeatedly until the display changes to
the Bluetooth  audio mode.
Next/Previous Track and
Fast Forward/Rewind :
When the or button is pushed for
more than 1.5 seconds while a Bluetooth  audio
file is being played, the Bluetooth  audio de-
vice will play while forwarding or rewinding.
When the button is released, the Bluetooth
audio device will return to normal play speed.
When the or button is pushed for
less than 1.5 seconds while a Bluetooth  audio
file is being played, the next track or the
beginning of the current track on the
Bluetooth  audio device will be played. The
INFINITI controller can also be used to select
tracks when the Bluetooth  audio play mode
screen is shown on the display. (“Bluetooth
audio” will be indicated on the header of the
screen.) REPEAT (RPT), RANDOM (RDM) :
To change the play mode, push the
button repeatedly and the mode changes as
follows.
Normal → Shuffle All Tracks → Shuffle Group →
Repeat 1 Track → Repeat All Tracks → Repeat
Group → Normal
Operation keys :
To operate a Bluetooth  audio device, select a
key displayed on the operation screen using the
INFINITI controller.
Play
Select the “
” key to start playing when
pausing. Select this key again to pause the
audio play.
Pause
Select the “
” key to pause the Bluetooth
audio device. Select this key again to resume
playing.
Play Mode :
The play mode setting display will appear when
the “Menu” key is selected.SAA2510
Monitor, climate, audio, phone and voice recognition systems
4-69
 —
—
04/21/10—debbie


Choose the preferred play mode from the fol-
lowing items.
● Shuffle
Choose “Shuffle OFF”, “Shuffle All Tracks”
and “Shuffle Group”.
● Repeat
Choose from “Repeat OFF”, “Repeat 1 Track”,
“Repeat All Tracks” and “Repeat Group”.
Bluetooth  settingsTo set up the Bluetooth  device system to the
preferred settings, push the SETTING button
and select the “Bluetooth” key.
Bluetooth :
If this setting is turned off, the connection
between the Bluetooth  devices and the in-
vehicle Bluetooth  module will be canceled.
Connect Bluetooth :
Connects to the Bluetooth  device. See “Con-
necting procedure” earlier in this section. Up to
5 devices can be registered. Connected Devices :
Registered devices are shown on the list. Select
a Bluetooth  device from the list, the following
options will be available.
● Select
Select “Select” to connect the selected de-
vice to the vehicle. If there is a different
device currently connected, the selected de-
vice will replace the current device.
● Edit
Rename the selected Bluetooth  device us-
ing the keypad displayed on the screen. (See
“HOW TO USE TOUCH SCREEN (models with
navigation system)” earlier in this section.)
● Delete
Delete the selected Bluetooth  device.
Edit Bluetooth Info :
Change the name broadcasted by this system
over Bluetooth  . Change the PIN code that is
entered when connecting a hands free device to
this system. SAA2511
4-70 Monitor, climate, audio, phone and voice recognition systems
 —
—
04/21/10—debbie


Replace Connected Phone :
Replace the Bluetooth  connection with a con-
nected Bluetooth  cellular phone. For details
about Hands-Free Phone System, see
“BLUETOOTH  HANDS-FREE PHONE SYSTEM
(models with navigation system)” later in this
section.
IPOD  PLAYER OPERATION (if so
equipped)
Connecting iPod  Open the console lid and connect the iPod
cable to the USB connector. If compatible, the
battery of the iPod  is charged while the con-
nection to the vehicle.
Depending on the version of the iPod  , the
display on the iPod  shows an INFINITI or
Accessory Attached screen when the connection
is completed. When the iPod  is connected to
the vehicle, the iPod  music library can only be
operated by the vehicle audio controls.
* iPod  is a trademark of Apple Inc., registered
in the U.S. and other countries.
Compatibility The following models are available:
Models with navigation system :
● Fifth generation iPod  (version 1.2.3 or later)
● iPod Classic  (version 1.1.1 or later)
● First generation iPod touch  (version 2.0.0
or later)
● Second generation iPod touch  (version
1.2.3 or later)Automatic transmission models SAA2974
Manual transmission models SAA2426
Monitor, climate, audio, phone and voice recognition systems
4-71
 —
—
04/21/10—debbie
