2010 HONDA ODYSSEY washer fluid

This indicator comes on when the
washer f luid level is low. Add washer
f luid when you see this indicator
come on (see page ).
You will also see a ‘‘WASHER
FLUID LOW’’ message on the multi-
inf ormation display (see page ).This indicator is in the f uel gauge. It
comesonasareminderthatyou
must ref uel soon.
When the indicator comes on, there
are about 3.0 US gal (11.4
)of fuel
remaining in the tank.
When the needle reaches E, there is
a very small amount of f uel in the
tank. You will also see a ‘‘FUEL LOW’’
message on the multi-information
display (see page ).
This indicator comes on f or a f ew
seconds when you turn the ignition
switch to the ON (II) position. If it
comes on at any other time, there is
a problem in the power tailgate
system. Have the system checked by
your dealer as soon as possible. You
can still open or close the tailgate
manually. For more inf ormation on
the power tailgate, see page .
89 89
148
432
On Canadian models
On Canadian Touring models On Touring models
On EX-L and Touring models
Instrument Panel Indicators
Low Fuel Indicator
Washer Level Indicator
Power Tailgate-open
Indicator
74
LOW FUEL INDICATOR
WASHER LEVEL INDICATOR
——
y

y
(yy
2010 Odyssey

If the brake f luid level is at or below
theMINmarkonthesideof the
brake f luid reservoir in the engine
compartment, you will see ‘‘BRAKE
FLUID LOW.’’ If you see this
message, have the brake system
checked by your dealer (see page). If the f luid level in the windshield
washer reservoir gets low, you will
see ‘‘WASHER FLUID LOW’’ on the
multi-inf ormation display.
If the level of the fuel in the tank
gets low, you will see ‘‘FUEL LOW’’
on the multi-information display, and
you must ref uel soon. The low f uel
indicator on the instrument panel will
also come on.
479On Canadian Touring model only
Brake Fluid L ow
Fuel L ow Washer Fluid L ow
Multi-Inf ormation Display
94
U.S.
Canada
——
y


y
(yy
2010 Odyssey

This section explains why it is
important to keep your vehicle well
maintained and how to f ollow basic
maintenance saf ety precautions.
This section also includes
instructions on how to read the
maintenance minder messages on
the inf ormation display or multi-
inf ormation display (depending on
models), and instructions f or simple
maintenance tasks you may want to
take care of yourself .
If you have the skills and tools to
perf orm more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer.......................
Maintenance Saf ety .414
....................
Maintenance Minder . 415
..............................
Fluid Locations .425
........................
Adding Engine Oil .426
Changing the Engine Oil and ...........................................
Filter .428
..............................
Engine Coolant .430
....................
Windshield Washers .432
....
Automatic Transmission Fluid . 433
....................................
Brake Fluid .435
....................
Power Steering Fluid . 436
....................................
Timing Belt .436
.............................................
Lights .437
................
Cleaning the Seat Belts . 444
.....................................
Floor Mats .444
..................
Dust and Pollen Filter . 444
.................................
Wiper Blades .445
...........................................
Wheels .450
...............................................
Tires .450
...................
Checking the Battery . 458
.............................
Vehicle Storage .459
511
Maintenance
Maint enance
413
——
y
y
(y
y
2010 Odyssey

Fluid Locations
Maint enance
425
ENGINE OIL DIPSTICK
(Orange loop)WASHER FLUID
(Blue cap) BRAKE FLUID
(Black cap)
ENGINE COOLANT RESERVOIR AUTOMATIC
TRANSMISSION
FLUID DIPSTICK
(Yellow loop)
POWER STEERING FLUID
(Red cap)
ENGINE OIL FILL CAP
RADIATOR CAP
——
y
y
(yy
2010 Odyssey

Check the f luid level in the
windshield washer reservoir at least
monthly during normal use. This
reservoir supplies the windshield and
rear window washers.
Check the f luid level by removing
the cap and looking at the level
gauge attached to the cap.The low washer
level indicator comes on when the
level is low (see page ).
You will also see a ‘‘WASHER
FLUID LOW’’ message on the multi-
inf ormation display (see page ). Fill the reservoir with a good-quality
windshield washer f luid. This
increases the cleaning capability and
prevents f reezing in cold weather.
When you ref ill the reservoir, clean
the edges of the windshield wiper
blades with windshield washer f luid
on a clean cloth. This will help to
condition the blade edges.
89
74
On Canadian models:
On Canadian Touring model:
Windshield Washers
432
LEVEL GAUGE
Do not use engine antif reeze or a
vinegar/water solution in the
windshield washer reservoir. Antif reeze
can damage your vehicle’s paint, while
a vinegar/water solution can damage
the windshield washer pump. Use only
commercially-available windshield
washer f luid.
——
y
y
(yy
2010 Odyssey

µµ
Î
Î
Î
Î
Î
Î
ÎÎ Î
Î
Î
Î
Î
Î Î Î
Î Î
Specif ications
492
Dimensions
Capacities Air Conditioning
Weights
Engine 202.0 in (5,132 mm)
77.1 in (1,958 mm)
66.8 in (1,697 mm) 66.7 in (1,694 mm)
118.1 in (3,000 mm) 68.8 in (1,748 mm)
70.0 in (1,778 mm)
Length
Width
Height
Wheelbase
Track
Excluding the oil remaining in the engine 0.190 US gal (0.72
)
Including the coolant in the reserve tank and that remaining in the
engine
Reserve tank capacity:
Fuel tank
Engine
coolant
Engine oil
Automatic
transmission
fluid
Windshield
washer
reservoir
2.6 US qt (2.5
)
8.0 US qt (7.6
)
3.3 US qt (3.1)
5.3 US qt (5.0)
4.2 US qt (4.0
)
4.5 US qt (4.3
)
2.56 US gal (9.7
)
1.85 US gal (7.0)
Refrigerant type
Charge quantity
Lubricant type
24.7 26.5 oz (700 750 g)
ND-OIL8
HFC-134a (R-134a)
4.8 US qt (4.5
)
Gross vehicle weight rating
Gross combined weight
rating (GCWR)
See the tire information label atta-
ched to the driver’s doorjamb.
8,410 lbs (3,815 kg)
3.50 x 3.66 in (89.0 x 93.0 mm) 212 cu-in (3,471 cm
)
10.0 : 1
Water cooled 4-stroke SOHC
VTEC or i-VTEC · VCM ,
6-cylinder (V6), gasoline engine
Type
BorexStroke
Displacement
Compression ratio
Spark plugs
10.5 : 1
SKJ16DR-M11 IZFR5K11
ILZKR7B11
SXU22HCR11
Front
Rear
1:
2:Approx.
21 US gal (80
)
Change
Total
Change Including
filter
Without
filter
Total
Change
Total
U.S. Vehicles
Canada Vehicles
NGK:
DENSO:
NGK:
DENSO:
1:
2:
U.S. LX and Canadian DX models
EX, EX-L, Touring and Canadian LX models
1:
2: LX, EX and Canadian DX models
EX-L and Touring models
12 1
2
1
2
1
2 1 1
2 2
——
y
y
(yy
2010 Odyssey

...............
Gas Mileage, Improving . 374.........................................
Gasoline .368
...............
Fuel Reserve Indicator . 74
...........................................
Gauge .77
................
Octane Requirement . 368
....................................
Ref ueling .369
................
Gas Station Procedures . 369
Gauges ...
Engine Coolant Temperature . 77
...............................................
Fuel .77
...............................
Speedometer .77
.................................
Tachometer .77
GAWR (Gross Axle Weight .......................................
Rating) .405
GCWR (Gross Combined Weight .......................................
Rating) .405
...................................
Glove Boxes .201
GVWR (Gross Vehicle Weight .......................................
Rating) .405
Fluids
..........
Automatic Transmission . 433
..........................................
Brake .435
..........................
Power Steering .436
................
Windshield Washers . 432
FM Stereo Radio ...................................
Reception .275
........
Folding the Third Row Seat . 181
........................
Four-way Flashers .140
..............................
Front Airbags .9 ,25
......................................
Front Seat .168
...................
Adjusting . 168,169,170
.......................................
Heaters .183
.....................................
Airbags .9, 25
.................................................
Fuel .368
......................
Fill Door and Cap .369
...........................................
Gauge .77
................
Octane Requirement . 368
....................................
Ref ueling .369
........................
Reserve Indicator .74
.....................
Fuses, Checking the .481 ...
Identif ication Number, Vehicle . 490
Ignition ............................................
Keys .142
.........................................
Switch .144
............
Timing Control System . 502
......................
Immobilizer System .143
.............
Halogen Headlight Bulbs . 437
...........................
HandsFreeLink
. 325
............
Hazard Warning Flashers . 140
.....................................
Headlights .136
........................................
Aiming .437 ............
Automatic Lighting Off . 138
.........
Daytime Running Lights . 138
..................
High Beam Indicator . 73
.......................
Reminder Chime .136
........
Replacing Halogen Bulbs . 437
.................................
Turning on .136
...................................
Headphones .315
............................
Head Restraints .171
...............................
Heated Mirror .192
...................................
Heater, Seat .183
.....................
Heating and Cooling .210
.............
High Altitude, Starting at . 385
...............
High-Low Beam Switch . 135
HomeLink
Universal ................................
Transceiver .322
.......................
Hood, Opening the .370
...........................................
Horn .4,133
Index
H I
G
IV
——
y
y
(y
y
2010 Odyssey

.....................................
XMRadio .238
.........
Vehicle Capacity Load . 379,404
......................
Vehicle Dimensions .492
....
Vehicle Identif ication Number . 490
Vehicle Stability Assist .................................
(VSA
) .70, 394
.............................
Vehicle Storage .459
.....................................
Ventilation .213
.................................................
VIN .490
..................................
Viscosity, Oil .427
.............
WARNING, Explanation of . ii
.........
Warning Labels, Location of . 61
....................
Warranty Coverages .509
Washer, Windshield ........
Checking the Fluid Level . 432
............................
Level Indicator .74
...................................
Operation .134
Wheels .............
Adjusting the Steering . 141
............
Alignment and Balance . 453
..........................
Compact Spare .462
......................................
Wrench .463
Windows .............................
Auto Reverse .186 ................
Operating the Power . 186
.........................
Rear, Def ogger .140
Windshield .....................................
Cleaning .134
...................................
Def roster .214
.....................................
Washers .134
Wipers, Windshield .......................
Changing Blades .445
...................................
Operation .134
Rear Windshield Wiper and ...................................
Washer .135
..................
Wireless Headphones . 315
....................................
Worn Tires .452
.....
Wrecker, Emergency Towing . 486
Index
W
X
X
——
y
y
(yy
2010 Odyssey
