2010 FIAT LINEA RHD interior lights

4
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLSDASHBOARD ........................................................................ 5
SYMBOLS ............................................................................... 6
THE FIAT CODE SYSTEM .................................................. 6
THE KEYS .............................................................................. 8
IGNITION DEVICE .............................................................. 12
INSTRUMENT PANEL ........................................................ 13
INSTRUMENTS ..................................................................... 14
DIGITAL DISPLAY ............................................................... 16
MULTIFUNCTION DISPLAY ............................................ 21
TRIP COMPUTER ................................................................ 30
FRONT SEATS ..................................................................... 32
REAR SEATS .......................................................................... 33
HEAD RESTRAINTS............................................................. 33
STEERING WHEEL .............................................................. 35
REARVIEW MIRRORS ......................................................... 36
HEATING AND VENTILATION ...................................... 37
MANUAL CLIMATE CONTROL SYSTEM .................... 38
AUTOMATIC CLIMATE CONTROL SYSTEM ............ 44
EXTERNAL LIGHTS ............................................................ 51
WINDSCREEN WASHING .............................................. 53CEILING LIGHTS .................................................................. 54
CONTROLS ........................................................................... 57
FUEL CUT-OFF SWITCH .................................................. 59
INTERIOR FITTINGS........................................................... 60
DOORS .................................................................................. 64
POWER WINDOWS ........................................................... 65
BOOT....................................................................................... 67
BONNET................................................................................. 68
HEADLIGHTS ........................................................................ 70
ABS SYSTEM ......................................................................... 71
SOUND SYSTEM .................................................................. 73
ACCESSORIES PURCHASED BY THE OWNER ..........
74
AT THE FILLING STATION .............................................
75
PROTECTING THE ENVIRONMENT................................
76
D D
A A
S S
H H
B B
O O
A A
R R
D D
A A
N N
D D
C C
O O
N N
T T
R R
O O
L L
S S
LINEA Owner HAND BOOK RHD.pdf 4LINEA Owner HAND BOOK RHD.pdf 48/21/09 2:15:58 PM8/21/09 2:15:58 PM

60
fig. 50F0R0077m
fig. 49F0R0104m
fig. 51F0R0078m
INTERIOR FITTINGS
ODDMENT DRAWER fig. 49-50
To open the drawer operate handle A-
fig. 49.
Inside the drawer there is a space A-fig.
50to keep documents.
ODDMENT COMPARTMENTS
Oddment compartment A-fig. 51, is lo-
cate d on the dashb oard, on the left of
the steering wheel. Re-arming the fuel cut-off switch
Before resetting the fuel cut-
off switch carefully inspect
the car for fuel leaks.
WARNING
To reset the fuel cut-off switch, press but-
ton A-fig. 48.
fig. 48F0R0208m
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
LINEA Owner HAND BOOK RHD.pdf 60LINEA Owner HAND BOOK RHD.pdf 608/21/09 2:16:07 PM8/21/09 2:16:07 PM

IMPORTANT The front air bags may be
deployed if the car is subject to heavy kno-
cks or accidents involving the underbody
area, such as for example violent shocks,
against steps, kerbs of low obstacles, fall-
ing of the car in big holes or sags in the
road.
IMPORTANT A small amount of dust will
be rele ase d when the airb ags are de-
ployed. The dust is not harmful and does
not indicate the beginning of a fire. Fur-
thermore, the surface of the deployed bag
and the interior of the car may be covered
in a dusty residue: this dust may irritate
the skin and the eyes. Wash with mild
soap and water in the event of exposure.
The expiration date of the explosive
charge and the clock wire are shown on a
specific label contained in the oddment
compartment. Go to a Fiat Dealership
to have the devices replaced when
the expiration date approaches.
IMPORTANT Should an accident occur in
which any of the safety devices is activat-
ed, take the car to a Fiat Dealership
to have the devices activated replaced
and to have the system checked.
All inspection, repair and replacement op-
erations concerning the air bags must on-
ly be carried out c/o Fiat Dealership.If you are having the car scrapped, have
the air bag system deactivated at a Fiat
Deal ers hi p firs t. If the car chang es
ownership, the new owner must be info-
rmed of the meth od of us e of ai r ba gs
and the above warnings and also be gi-
ven this “Owner’s Handbook”.
IMPORTANT Pretensioners, front airbags
are deployed according to different logics
on the basic of the type of collision. Non
depl oym ent of one of the de vi ces does
not therefore indicate a system fault.
Never rest head, arms and
elbows on the door, on the
windows area to prevent possible in-
juries during inflation phase.
WARNING
Never lean head, arms and
elbows out of window.
WARNING
GENERAL WARNINGS
If when turning the key to
MAR the warning light
does not turn on or if it stays on when
travelling (together with the message
on the multifunctional display, where
provided) there could be a failure in
safety systems; in this event air bags
or pretensioners could not trigger in
case of impact or, in a minor number
of cases, they could trigger acciden-
tally. Contact Fiat Dealership im-
mediately to have the system checked.
WARNING
Do not cover the backrest of
front and rear sea ts with
trims or covers that are not suitable
to be used with side bags.
WARNING
Never travel with objects on
your lap , in front of your
chest or with a pipe, pencil, etc. be-
tween your lips; injury may result in
the event of the air bag being trig -
gered.
WARNING
90
AND CONTROLS
DEVICES
CORRECT USE
OF THE
CAR
MESSAGES
EMERGENCY
MAINTENANCE
SPECIFICATIONS
INDEX
DASHBOARD
SAFETY
LIGHTS AND
CAR
IN AN
TECHNICAL
WARNING
LINEA Owner HAND BOOK RHD.pdf 90LINEA Owner HAND BOOK RHD.pdf 908/21/09 2:16:13 PM8/21/09 2:16:13 PM

111
STARTING THE ENGINE ................................................... 112
REPLACING A WHEEL ...................................................... 113
WHEN NEEDING TO CHANGE A BULB ..................... 119
IF AN EXTERIOR LIGHT BURNS OUT .......................... 121
IF AN INTERIOR LIGHT BURNS OUT .......................... 126
IF A FUSE BLOWS ................................................................ 128
IF THE BATTERY IS FLAT.................................................. 135
LIFTING THE CAR ............................................................... 135
TOWING THE CAR ........................................................... 135
II I
N N
A A
N N
E E
M M
E E
R R
G G
E E
N N
C C
Y Y
CORRECT USE
OF THE CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
LINEA Owner HAND BOOK RHD.pdf 111LINEA Owner HAND BOOK RHD.pdf 1118/21/09 2:16:16 PM8/21/09 2:16:16 PM

IF AN INTERIOR LIGHT
BURNS OUT
For the type of bulb and power rating, see
“When needing to change a bulb”.
FRONT CEILING LIGHT
To replace the bulbs proceed as follows:


work in the points shown by the ar-
rows and remove light A-fig. 21;
open the protection lid B-fig. 22;
replace bulbs Creleasing them from the
side contacts; make sure that new bulbs
are correctly clamped between contacts;
re-close the lid B-fig. 22and secure light
A-fig. 21into its housing locking it
properly.
REAR CEILING LIGHT
(where provided)
To replace the bulbs proceed as follows:

work in the points shown by the ar-
rows and remove light D-fig. 23;
open the protection lid E-fig. 24;change the bulb F-fig. 24releasing it
from the side contacts and making sure
the new bulb is correctly fastened be-
tween the contacts;re-close the protection lid E-fig. 24
and secure light D-fig. 23into its hous-
ing locking it properly.
fig. 21F0R0115m
fig. 22F0R0117m
fig. 23F0R0116m
fig. 24F0R0118m
126
CORRECT USE
OF THE CAR
AND CONTROLS
DEVICES
MAINTENANCE
SPECIFICATIONS
INDEX
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
DASHBOARD
SAFETY
CAR
TECHNICAL
LINEA Owner HAND BOOK RHD.pdf 126LINEA Owner HAND BOOK RHD.pdf 1268/21/09 2:16:20 PM8/21/09 2:16:20 PM

SCHEDULED SERVICING ................................................ 138
SERVICE SCHEDULE
PETROL VERSIONS ............................................................. 139
REGULAR INSPECTIONS ................................................. 143
DEMANDING USE OF THE CAR ................................... 143
CHECKING FLUID LEVELS................................................ 144
AIR CLEANER ...................................................................... 149
POLLEN FILTER ................................................................... 149
BATTERY ................................................................................ 149
WHEELS AND TYRES ......................................................... 152
RUBBER HOSES .................................................................... 153
WINDSCREEN WIPERS ...................................................... 153
BODYWORK ........................................................................ 155
INTERIORS ............................................................................ 157
CC C
A A
R R
M M
A A
I I
N N
T T
E E
N N
A A
N N
C C
E E
137
CAR
MAINTENANCE
CORRECT USE
OF THE CAR
TECHNICAL
INDEX
DASHBOARD
SAFETY
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
SPECIFICATIONS
AND CONTROLS
DEVICESSERVICE SCHEDULE
VERSIONS ............................................................ 1 DIESEL . 41
LINEA Owner HAND BOOK RHD.pdf 137LINEA Owner HAND BOOK RHD.pdf 1378/21/09 2:16:21 PM8/21/09 2:16:21 PM

The fabric upholstery of your
car is designed to withstand
the normal wear and tear of
your car for a long time. Some
precautions are however needed. Avoid
prolonged rubbing against clothing ac-
cessories, such as metal buckles, Velcro
strips and the like, which by applying a
high pressure on the fabric in a small
area could cause the breakage of some
threads and damage the upholstery.
CLEANING SEATS AND FABRIC
PA RT S
Remove dust with a soft brush or a vacu-
um cleaner. It is advisable to use a moist
brush on velvet upholstery.
Rub the seats with a sponge moistened
with a solution of water and neutral de-
tergent.
Never use flammable prod-
ucts, such as petrol ether or
rectified petrol to clean inside the car.
The electrostatic charges which are
generated by rubbing during the
cleaning operation may cause a fire.
WARNING
Do not keep aerosol cans in
the car : risk of explosi on.
Aerosol cans must not be exposed to
temperatures higher than 50°C . The
temperature may raise well beyond
that figure when the car is left in the
sun.
WARNINGINTERIORS
Periodically check that water is not
trapped under the mats (due to water
dripping off shoes, umbrellas, etc.) which
could cause oxidisation of the sheet
metal.
157
CAR
MAINTENANCE
CORRECT USE
OF THE CAR
TECHNICAL
INDEX
DASHBOARD
SAFETY
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
SPECIFICATIONS
AND CONTROLS
DEVICES
LINEA Owner HAND BOOK RHD.pdf 157LINEA Owner HAND BOOK RHD.pdf 1578/21/09 2:16:36 PM8/21/09 2:16:36 PM

GENUINE LEATHER STEERING
WHEEL/GEAR LEVER KNOB
These components must be cleaned with
mild soap and water only.
Never use spirit and/or alcohol based
products.
Before using off-the-shelves products de-
signed for cleaning car interiors, make sure
that they do not contain spirit and/or al-
cohol based substances before using them.
If window cleaner accidentally drips onto
the steering wheel or gear lever knob,
wipe away immediately and then wash the
concerned area with mild soap and water. IMPORTANT Be carefully when arranging
a steering wheel lock device, where applic-
able, to prevent damaging the leather up-
holstery by rubbing. INTERIOR PLASTIC PARTS
It is advisable to clean interior parts with a
moist cloth and a solution of water and mild
soap. Use specific products for cleaning plas-
tic, without solvents and specifically de-
signed to prevent damage to the appearance
and colour of the treated parts to remove
grease and tough stains.
IMPORTANT Never use spirit or petro-
leum to clean the instrument panel.
158
CORRECT USE
OF THE CAR
AND CONTROLS
DEVICES
SPECIFICATIONS
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
DASHBOARD
SAFETY
TECHNICAL
LINEA Owner HAND BOOK RHD.pdf 158LINEA Owner HAND BOOK RHD.pdf 1588/21/09 2:16:36 PM8/21/09 2:16:36 PM
