2010 CITROEN DS4 Owners Manual

87
1. Left hand front window control.
2. Right hand front electric window control. The electric window controls remain
operational for approximately
45
seconds after the ignition is
switched off or until the vehicle is
locked after a door is opened.
If the passenger 's window cannot be
operated from the driver's door control
panel, carry out the operation from the
passenger's door control panel, and
vice versa.
Electric windowsFitted with a safety anti-pinch system.
One-touch electric windows
Manual mode
After approximately ten consecutive
complete opening/closing movements
of the window, a protection function is
activated which only authorises closing
of the window to prevent damage to the
electric window motor.
Once the window is closed, the controls
will become available again after
approximately 40 minutes.
F

P
ress or pull the control firmly.
The window opens or closes fully
when the control is released.
F

P
ressing the control again stops
the movement of the window.
Automatic mode F

P
ress or pull the control gently.
The window stops when the
control is released.
02
Access

88
Safety anti-pinch
When the window rises and meets an obstacle,
it stops and partially lowers again.
Reinitialisation
If a window does not rise automatically, its
operation must be reinitialised.
F
P
ull the control until the window stops.
F

R
elease the control and pull it again until
the window closes fully.
F

C
ontinue to hold the control for
approximately one second after the window
has closed.
F

P
ress the control to lower the window
automatically to the low position.
F

W
hen the window has reached the low
position, press the control again for
approximately one second.
The safety anti-pinch function is not
operational during these operations.
If the window cannot be closed (for
example, in the presence of ice), once
the window has lowered:
F

p

ress and hold the control until the
window opens fully,
F

t

hen pull the control immediately
and hold it until the window closes,
F

c

ontinue to hold the control for
approximately one second after the
window has closed.
The safety anti-pinch function is not
operational during these operations. If an obstacle is encountered during
operation of the electric windows, you
must reverse the movement of the
window. To do this, press the control
concerned.
When the driver operates the
passenger's electric window control,
they must ensure that nothing is
preventing the windows closing
c o r r e c t l y.
The driver must ensure that the
passengers use the electric windows
c o r r e c t l y.
Be particularly aware of children when
operating the windows.
Be aware of passengers and/or other
persons present when closing the
windows with the key or the "Keyless
Entry and Starting" system.
Always remove the key from the ignition
when leaving the vehicle, even for a
short time.
02
Access

89
02
Access

ERGONOMY AND C OMFORT

03

92
Front seats
Manual adjustments
F Raise the control and slide the seat for wards or backwards.
F

R
elease the control to lock the position. F
P ull the control upwards to raise or push
it downwards to lower, as many times as
necessary, to obtain the position required. F
T urn the control knob to adjust the seat
backrest angle.
As a safety measure, seat adjustments should only be done when stationary.
Before moving the seat backwards, ensure that there is nothing that might prevent the full travel of the seat.
There is a risk of trapping or pinching passengers if present in the rear seats or jamming the seat if large objects are placed on the floor behind
the seat.
Forwards-backwards Seat height Seat backrest angle
03
Ease of use and comfort

93
Driver's seat electric
adjustments
F Push the control for wards or rear wards to slide the seat. F
T ilt the rear part of the control upwards or
downwards to obtain the required height.
F

T
ilt the front part of the control upwards or
downwards to obtain the required angle. F
T ilt the control for wards or rear wards to
adjust the angle of the seat backrest.
The electrical functions of the driver's seat are deactivated approximately one minute after
the ignition is switched off.
To reactivate them, switch on the ignition.
Before moving the seat backwards, ensure that there is nothing that might prevent the full travel of the seat.
There is a risk of trapping or pinching passengers if present in the rear seats or jamming the seat if large objects are placed on the floor behind
the seat.
Forwards-backwards Cushion height and angleSeat backrest angle
03
Ease of use and comfort

94
Additional adjustments
F To raise a head restraint, pull it upwards.
F T o lower the head restraint, press the lug A
and the head restraint at the same time.
F

T
o adjust the angle of the head restraint, tilt
its lower part for wards or rear wards. The head restraint is fitted with a frame
with notches which prevents it from
lowering; this is a safety device in case
of impact.
The adjustment is correct when the
upper edge of the head restraint is
level with the top of the head.
Removing a head restraint
F To remove the head restraint, press the
lug A and pull the head restraint upwards.
F

T
o put the head restraint back in place,
engage the head restraint stems in the
openings keeping them in line with the seat
back and press the lug A at the same time.
Never drive with the head restraints
removed; they must be in place and
adjusted correctly.
Head restraint height and angle
03
Ease of use and comfort
