2010 CHRYSLER 300 SRT remote start

CAUTION!
Failure to follow these procedures could result in
damage to the charging system of the booster vehicle
or the discharged vehicle.
1. Connect the positive (+)end of the jumper cable to the
remote positive (+)post of the discharged vehicle.
2. Connect the opposite end of the positive (+)jumper
cable to the positive (+)post of the booster battery.
3. Connect the negative end (-)of the jumper cable to the
negative (-)post of the booster battery.
4. Connect the opposite end of the negative (-)jumper
cable to the remote negative (-)post of the vehicle with
the discharged battery.
WARNING!
Do not connect the cable to the negative post (-) of the
discharged battery. The resulting electrical spark
could cause the battery to explode and could result in
personal injury.
5. Start the engine in the vehicle that has the booster
battery, let the engine idle a few minutes, and then start
the engine in the vehicle with the discharged battery.
Once the engine is started, remove the jumper cables in
the reverse sequence:
6. Disconnect the negative (-)jumper cable from the
remote negative (-)post of the vehicle with the dis-
charged battery.
7. Disconnect the negative end (-)of the jumper cable
from the negative (-)post of the booster battery.
358 WHAT TO DO IN EMERGENCIES

8. Disconnect the opposite end of the positive(+)jumper
cable from the positive (+)post of the booster battery.
9. Disconnect the positive (+)end of the jumper cable
from the remote positive (+)post of the discharged
vehicle.
If frequent jump-starting is required to start your vehicle
you should have the battery and charging system in-
spected at your authorized dealer.
CAUTION!
Accessories that can be plugged into the vehicle
power outlets draw power from the vehicle’s battery,
even when not in use (i.e., cellular phones, etc.).
Eventually, if plugged in long enough, the vehicle’s
battery will discharge sufficiently to degrade battery
life and/or prevent the engine from starting.
FREEING A STUCK VEHICLE
If your vehicle becomes stuck in mud, sand, or snow, it
can often be moved by a rocking motion. Turn your
steering wheel right and left to clear the area around the
front wheels. Then shift back and forth between RE-
VERSE and DRIVE. Using minimal accelerator pedal
pressure to maintain the rocking motion, without spin-
ning the wheels, is most effective.
NOTE: Turn off the Electronic Stability Program (ESP)
— if equipped, or Traction Control System (TCS) — if
equipped before rocking the vehicle. Refer to “Electronic
Brake Control” in “Starting and Operating” for further
information.
6
WHAT TO DO IN EMERGENCIES 359

ENGINE COMPARTMENT — 6.1L
1 — Remote Jump Start (Positive Battery Post)6 — Power Steering Fluid Reservoir
2 — Integrated Power Module 7 — Air Cleaner Filter
3 — Coolant Pressure Cap 8 — Engine Oil Fill
4 — Brake Fluid Reservoir Access Cover 9 — Engine Oil Dipstick
5 — Engine Coolant Reservoir 10 — Washer Fluid Reservoir
7
MAINTAINING YOUR VEHICLE 365

used to assure most efficient service. MOPARengine air
cleaner filters are a high quality filter and are
recommended.
Maintenance-Free Battery
Your vehicle is equipped with a maintenance-free battery.
You will never have to add water, nor is periodic main-
tenance required.
NOTE: The battery is stored under an access cover in
the trunk. Remote battery terminals are located in the
engine compartment for jump starting. Refer to “Jump-
Starting Procedures” in “What To Do In Emergencies” for
further information.
Battery Location
7
MAINTAINING YOUR VEHICLE 373

Disabled Vehicle Towing................... 360
Disposal Antifreeze (Engine Coolant) ............... 386
Engine Oil ........................... 372
Door Locks ............................. 27
Door Locks, Automatic .................... 29
Door Opener, Garage ..................... 164
Driving On Slippery Surfaces ................... 290
Through Flowing, Rising, or Shallow
Standing Water ........................ 291
DVD Player (Video Entertainment System™) .... 258
Electric Rear Window Defrost ............... 181
Electric Remote Mirrors .................... 92
Electrical Power Outlets ................... 174
Electronic Brake Control System ............. 300
Electronic Speed Control (Cruise Control) ...... 155
Electronic Stability Program (ESP) ............ 302Electronic Throttle Control Warning Light
...... 195
Electronic Vehicle Information Center (EVIC) .... 199
Emergency Deck Lid Release ................ 42
Emergency, In Case of Freeing Vehicle When Stuck ............... 359
Hazard Warning Flasher ................. 344
Jump Starting ......................... 355
Overheating .......................... 344
Towing ............................. 360
Emergency Trunk Release ................... 42
Emission Control System Maintenance ......367,416
Engine ............................... 365
Air Cleaner .......................... 372
Block Heater ......................... 280
Break-In Recommendations ................ 78
Checking Oil Level ..................... 370
Compartment ......................... 365
Coolant (Antifreeze) ................. 382,413
Cooling ............................. 382
448 INDEX

PretensionersSeat Belts ............................ 50
Programmable Electronic Features ............ 216
Programming Transmitters
(Remote Keyless Entry) .................... 20
Radial Ply Tires ......................... 320
Radiator Cap (Coolant Pressure Cap) .......... 385
Radio Operation ........................ 263
Radio Remote Controls .................... 260
Radio, Satellite (Uconnect studios)........... 252
Rain Sensitive Wiper System ................ 150
Rear Cupholder ......................... 177
Rear Park Sense System ................... 158
Rear Seat, Folding ....................... 134
Rear Window Defroster ................... 181
Rear Window Features .................... 181
Reclining Front Seats ..................... 129
Recreational Towing ...................... 342 Reformulated Gasoline
.................... 333
Refrigerant ............................ 376
Release, Hood .......................... 140
Reminder, Lights On ..................... 144
Reminder, Seat Belt ....................... 51
Remote Control Starting System ........................ 24
Remote Keyless Entry (RKE) ................. 20
Remote Sound System (Radio) Controls ........ 260
Remote Starting System .................... 24
Remote Trunk Release ..................... 40
Replacement Bulbs ....................... 406
Replacement Keys ........................ 16
Replacement Parts ....................... 368
Replacement Tires ....................... 322
Reporting Safety Defects ................... 438
Restraint, Head ......................... 130
Restraints, Child ......................... 69
Restraints, Occupant ...................... 42
10
INDEX 457

Tilting.............................. 128
Security Alarm (Theft Alarm) .............17,195
Selection of Coolant (Antifreeze) ..........383,413
Selection of Oil ......................... 371
Sentry Key (Immobilizer) ................... 15
Sentry Key Programming ................... 17
Sentry Key Replacement ................... 16
Service Assistance ....................... 435
Service Contract ......................... 437
Service Engine Soon Light
(Malfunction Indicator) .................... 198
Service Manuals ........................ 439
Setting the Clock .............221,222,224,227,236
Settings, Personal ........................ 216
Shifting ............................... 280
Automatic Transmission ..............280,285
Shoulder Belt Upper Anchorage .............. 49
Shoulder Belts ........................... 44
Side View Mirror Adjustment ................ 91Signals, Turn
...................... 83,145,189
Slippery Surfaces, Driving On ............... 290
SmartBeams ........................... 143
Snow Tires ............................ 323
Sound System Kicker .............................. 257
Spark Plugs ............................ 413
Specifications Fuel (Gasoline) ........................ 413
Oil ................................ 413
Speed Control (Cruise Control) .............. 155
Speedometer ........................... 189
Starting ............................. 24,275
Automatic Transmission ................. 275
Cold Weather ......................... 278
Engine Fails to Start .................... 278
Remote .............................. 24
Starting and Operating .................... 275
Starting Procedures ...................... 275
10
INDEX 459

SteeringColumn Controls ...................... 145
Power ........................... 293,294
Tilt Column .......................... 152
Wheel, Tilt ........................... 152
Steering Wheel Mounted Sound
System Controls ......................... 260
Storage ............................ 178,405
Storage, Vehicle ...................... 269,405
Storing Your Vehicle ...................... 405
Stuck, Freeing .......................... 359
Sun Roof .............................. 171
Sunglasses Storage ....................... 164
Sunroof Maintenance ..................... 173
Supplemental Restraint System - Airbag ........ 53
Synthetic Engine Oil ...................... 371
System, Remote Starting .................... 24
Tachometer ............................ 190 Telescoping Steering Column
............... 152
Temperature Control, Automatic (ATC) ........ 263
Temperature Gauge, Engine Coolant .....193,194,345
Tether Anchor, Child Restraint ............... 73
Theft Alarm (Security Alarm) ................ 17
Theft System (Security Alarm) ............... 17
Tilt Steering Column ..................... 152
Time Delay, Headlight .................... 144
Tire and Loading Information Placard ......... 313
Tire Identification Number (TIN) ............. 311
Tire Markings .......................... 307
Tire Safety Information .................... 307
TIREFIT .............................. 345
Tires ............................ 83,317,441
Aging (Life of Tires) .................... 322
Air Pressure .......................... 317
General Information .................... 317
High Speed .......................... 319
Inflation Pressures ..................... 318
460 INDEX
