Power Outlets
The vehicle has two accessory
power outlets; one is located below
the climate control system and
the other is inside the center storage
console.
The accessory power outlets do not
work when the key is removed
from the ignition and the driver door
is opened, this helps to preserve
the battery life of the vehicle.
Certain power accessory plugs may
not be compatible to the accessory
power outlet and could result in
blown vehicle or adapter fuses.
If you experience a problem,
see your dealer/retailer for additional
information on the accessory
power plugs.Notice:Adding any electrical
equipment to the vehicle can
damage it or keep other
components from working as
they should. The repairs would
not be covered by the vehicle
warranty. Each outlet is rated to
a maximum output of 120W.
Usage of equipment exceeding
an amperage rating of 20A may
require fuse replacement. Check
with your dealer/retailer before
adding electrical equipment.
When adding electrical equipment,
be sure to follow the proper
installation instructions included
with the equipment.
Notice:Improper use of the
power outlet can cause damage
not covered by the warranty.
Do not hang any type of
accessory or accessory bracket
from the plug because the
power outlets are designed for
accessory power plugs only.
Warning Lights,
Gages, and Indicators
Warning lights come on when
there could be a problem with a
vehicle function. Some warning
lights come on briefly when
the engine is started to indicate
they are working.
Gages can indicate when there
could be a problem with a vehicle
function. Often gages and warning
lights work together to indicate
a problem with the vehicle.
When one of the warning lights
comes on and stays on while
driving, or when one of the gages
shows there may be a problem,
check the section that explains what
to do. Follow this manual’s advice.
Waiting to do repairs can be
costly and even dangerous.
Instruments and Controls 4-9

Speedometer
The speedometer shows the
vehicle’s speed in both kilometers
per hour (km/h) and miles per
hour (mph).
Odometer
The odometer shows how far the
vehicle has been driven, in
either kilometers or miles.
This vehicle has a tamper-resistant
odometer. If the vehicle needs a
new odometer installed, the new
one is set to the mileage of the old
odometer. If this is not possible, it is
set at zero and a label is put on the
driver’s door to show the old mileage
reading.
Trip Odometer
The trip odometer shows how far the
vehicle has been driven since the trip
odometer was last set to zero.
Set the odometer using the Driver
Information Center (DIC).To set the trip odometer to zero,
press and hold the SET button while
the trip odometer display is showing.
Tachometer
The tachometer displays the
engine speed in revolutions per
minute (rpm).
Fuel Gage
When the ignition is on, the fuel
gage shows about how much fuel
the vehicle has left in the fuel tank.
An arrow on the fuel gage
indicates which side of the vehicle
the fuel door is located.
The gage indicates empty before
the vehicle is out of fuel, to show
that the vehicle’s fuel tank should be
filled soon. United States
Canada
Instruments and Controls 4-11

When the fuel tank is low on fuel,
a Fuel Level Low message will
appear on the Driver Information
Center (DIC). For more information
seeFuel System Messages on
page 4-33.
Here are some situations that can
occur with the fuel gage. None of
these indicate a problem with
the fuel gage.
•At the gas station, the fuel pump
shuts off before the gage
reads full.
•It takes a little more or less fuel to
fill up than the fuel gage indicated.
For example, the gage may have
indicated the tank was half full,
but it actually took a little more or
less than half the tank’s capacity
to fill the tank.
•The pointer on the fuel gage is on
empty when the ignition is off.
Engine Oil
Pressure Gage
The oil pressure gage, located in
front of the shifter, shows the engine
oil pressure in psi (pounds per
square inch) when the engine is
running. Canadian vehicles indicate
pressure in kPa (kilopascals).
Oil pressure may vary with engine
speed, outside temperature and oil
viscosity, but readings above the low
pressure zone indicate the normal
operating range. When the oil
pressure reaches the low pressure
zone, a message appears in the
Driver Information Center (DIC). United States
Canada
4-12 Instruments and Controls

SeeEngine Oil Messages on
page 4-32andEngine Oil on
page 9-10for more information.
{WARNING
Do not keep driving if the oil
pressure is low. The engine can
become so hot that it catches fire.
Someone could be burned.
Check the oil as soon as possible
and have the vehicle serviced.
Notice:Lack of proper engine oil
maintenance can damage the
engine. The repairs would not be
covered by the vehicle warranty.
Always follow the maintenance
schedule in this manual for
changing engine oil.
A reading in the low pressure zone
can be caused by a dangerously
low oil level or some other problem
causing low oil pressure. Check
the oil as soon as possible.
Engine Oil
Temperature Gage
This gage, located in front of the
shifter, shows the engine oil
temperature.
If the gage pointer moves into the
red area, it means that the engine oil
has overheated. If the vehicle has
been operated under normal driving
conditions, pull off the road, stop
the vehicle and turn off the engine
as soon as possible.
SeeEngine Oil on page 9-10for
more information. United States
Canada
Instruments and Controls 4-13

Engine Coolant
Temperature Gage
This gage shows the engine coolant
temperature.
If the gage pointer moves towards
the H, the engine is too hot.
This reading indicates the same
thing as the warning message.
It means that the engine coolant has
overheated. If the vehicle has been
operating under normal driving
conditions, pull off the road, stop the
vehicle, and turn off the engine as
soon as possible. SeeEngine
Overheating on page 9-24for more
information.
Transmission
Temperature Gage
United States
Canada
United States
4-14 Instruments and Controls

This gage, located in front of the
shifter, shows the transmission
oil temperature when the ignition is
on. If the gage is reading in the
red area and/or a message appears
in the DIC, the vehicle must be
stopped and the cause checked.
One possible cause is a low level in
the transmission.For information on the DIC
messages seeTransmission
Messages on page 4-36.
Notice:If the vehicle is driven
with the transmission temperature
gage above the normal operating
range, the transmission can be
damaged. This could lead to
costly repairs that would not be
covered by the vehicle warranty.
Do not drive the vehicle while the
transmission temperature gage
reading is above normal. See your
dealer/retailer for service.
Voltmeter Gage
This gage, located in front of the
shifter, shows the battery’s state of
charge in DC volts.
When the engine is running, but the
ignition is on, this gage shows
the condition of the charging system.
The vehicle’s charging system
regulates voltage based on the state
of charge of the battery. It is normal
for the voltmeter to fluctuate. Canada
United States Version Shown,
Canada Similar
Instruments and Controls 4-15
