2010 CHEVROLET CAMARO clock

Black plate (83,1)Chevrolet Camaro Owner Manual - 2010
Vehicle Care 9-83
{WARNING
Rust or dirt on a wheel, or on the
parts to which it is fastened, can
make wheel nuts become loose
after time. The wheel could come
off and cause an accident. When
changing a wheel, remove any
rust or dirt from places where
the wheel attaches to the vehicle.
In an emergency, use a cloth or a
paper towel to do this; but be sure
to use a scraper or wire brush
later, if needed, to get all the rust
or dirt off. SeeIf a Tire Goes Flat
on page 9‑71.
9. Remove any rust or dirt from the
wheel bolts, mounting surfaces
and spare wheel.
10. Place the compact spare tire on the wheel-mounting surface.
{WARNING
Never use oil or grease on bolts
or nuts because the nuts might
come loose. The vehicle's wheel
could fall off, causing a crash.
11. Reinstall the wheel nuts with the rounded end of the nuts
toward the wheel. Tighten each
nut as much as possible using
the wheel wrench until the
wheel is held firmly against
the hub.
Use your free hand to prevent
the wheel from turning while
you are tightening.
12. Lower the vehicle by turning the jack handle
counterclockwise. Lower
the jack completely.

Black plate (84,1)Chevrolet Camaro Owner Manual - 2010
9-84 Vehicle Care
13. Tighten the wheel nuts firmlyin a crisscross sequence, as
shown.
{WARNING
Wheel nuts that are improperly or
incorrectly tightened can cause
the wheels to become loose or
come off. The wheel nuts should
be tightened with a torque wrench
to the proper torque specification
(Continued)
WARNING (Continued)
after replacing. Follow the torque
specification supplied by the
aftermarket manufacturer when
using accessory locking wheel
nuts. SeeCapacities and
Specifications
on page 11‑2for
original equipment wheel nut
torque specifications.
Notice: Improperly tightened
wheel nuts can lead to brake
pulsation and rotor damage.
To avoid expensive brake repairs,
evenly tighten the wheel nuts
in the proper sequence and to
the proper torque specification.
See Capacities and Specifications
on page 11‑2for the wheel nut
torque specification.
Storing a Flat or Spare Tire
and Tools
{WARNING
Storing a jack, a tire, or other
equipment in the passenger
compartment of the vehicle could
cause injury. In a sudden stop or
collision, loose equipment could
strike someone. Store all these in
the proper place.
To store a flat or spare tire and
tools:
1. Replace the jack and tools.
2. Replace the spare tire cover.
3. Turn the retainer nut clockwise to tighten.
4. Replace the rear trunk carpet.
5. Place the flat tire face up on the load floor.

Black plate (2,1)Chevrolet Camaro Owner Manual - 2010
i-2 INDEX
B
Battery . . . . . . . . . . . . . . . . . . . . . . . . 9-29Jump Starting . . . . . . . . . . . . . . . . . 9-86
Load Management . . . . . . . . . . . . . 5-6
Power Protection . . . . . . . . . . . . . . 5-7
Voltage and ChargingMessages . . . . . . . . . . . . . . . . . . . 4-31
Blade Replacement, Wiper . . . . 9-32
Bluetooth . . . . . . . . . . 6-21, 6-22, 6-25
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . 9-27 Antilock . . . . . . . . . . . . . . . . . . . . . . . 8-31
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 8-33
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 9-28
Parking . . . . . . . . . . . . . . . . . . . . . . . 8-32
System Messages . . . . . . . . . . . . 4-32
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
Break-In, New Vehicle . . . . . . . . . 8-17
Bulb Replacement . . . . . . . . . . . . . 9-41
Fog Lamps . . . . . . . . . . . . . . . . . . . 9-40
Halogen Bulbs . . . . . . . . . . . . . . . . 9-36
Headlamp Aiming . . . . . . . . . . . . . 9-33
Headlamps . . . . . . . . . . . . . . . . . . . 9-36
Headlamps, FrontTurn Signal and
Parking Lamps . . . . . . . . 9-37, 9-38 Bulb Replacement (cont.)
High Intensity Discharge
(HID) Lighting . . . . . . . . . . . . . . . 9-36
License Plate Lamps . . . . . . . . . 9-41
Taillamps, Turn Signal and
Stoplamps . . . . . . . . . . . . . . . . . . 9-40
Buying New Tires . . . . . . . . . . . . . . 9-65
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 4-8
California Fuel Requirements . . . . . . . . . . . 8-45
Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . . 9-3
Warning . . . . . . . . . . . . . . . . . . . . . . . 9-3
Canadian Vehicle Owners . . . . . . . . iii
Capacities and
Specifications . . . . . . . . . . . . . . . . 11-2
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 8-25
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
Winter Driving . . . . . . . . . . . . . . . . 8-10
Cautions, Danger, and Warnings . . . . . . . . . . . . . . . . . . . . . . . . iv
CD Player . . . . . . . . . . . . . . . . . . . . . 6-14
Center Console Storage . . . . . . . . 3-1 Chains, Tire . . . . . . . . . . . . . . . . . . . 9-71
Charging System Light . . . . . . . . 4-20
Check
Engine Light . . . . . . . . . . . . . . . . . . 4-20
Ignition Transmission Lock . . . 9-32
Child Restraints Infants and Young
Children . . . . . . . . . . . . . . . . . . . . . 2-39
Lower Anchors and Tethers for Children . . . . . . . . . 2-45
Older Children . . . . . . . . . . . . . . . . 2-36
Securing . . . . . . . . . . . . . . . . 2-50, 2-52
Systems . . . . . . . . . . . . . . . . . . . . . . 2-41
Where to Put the Restraint . . . 2-43
Circuit Breakers . . . . . . . . . . . . . . . 9-42
Cleaning Exterior Care . . . . . . . . . . . . . . . . . 9-90
Interior Care . . . . . . . . . . . . . . . . . . 9-95
Climate Control Systems . . . . . . . 7-1
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Cluster, IP . . . . . . . . . . . . . . . . . . . . . 4-11
Clutch, Hydraulic . . . . . . . . . . . . . . 9-15
Collision Damage Repair . . . . . 12-10
Compact Spare Tire . . . . . . . . . . . 9-85
Compass . . . . . . . . . . . . . . . . . . . . . . . 4-8
Compass Messages . . . . . . . . . . . 4-32
