265
SOUND SYSTEM
SPEED VOLUME function
(variation of volume
dependent on speed)
(excluding versions
with Bose HI-FI system)
This function allows the volume level to be
adjusted automatically depending on the
speed of the vehicle, increasing it as the
speed increases to maintain the same bal-
ance with the noise level inside the passen-
ger compartment. To turn the function
on/off, press buttons
/. The words
Speed volume should appear on the display
followed by the current status of the func-
tion:
❍Off: function deactivated
❍Low:function activated
(low setting)
❍High:function activated
(high setting).
RADIO ON VOL function
(radio volume maximum limit
activation/deactivation)
This function makes it possible to acti-
vate/deactivate the maximum volume lim-
it when turning the radio on.
The display shows the function status:
❍“Radio on vol – Limit on”: when the
radio is switched on the volume level
will be:
– if the volume level is equal to or high-
er than the maximum value, the ra-
dio will come on at the maximum vol-
ume;
– if the volume level is between the
minimum and maximum values, the
radio will come on at the same vol-
ume as before it was switched off;
– if the volume level is equal to or low-
er than the minimum value, the radio
will come on at the minimum volume.
❍“Radio on vol – Limit off”: the radio will
come on at the volume level it was at
before switching off. The volume may
be between 0 and 40.
To change the setting use buttons
/.NOTES
❍Using the MENUit is only possible to ad-
just the activation/deactivation of the
function and not the minimum or max-
imum volume setting.
❍If the “TA” or “TEL” functions or an out-
side audio source are activated when the
radio is turned on, the radio will come
on at the volume set for these sources.
When the outside audio source is deac-
tivated, the volume can be adjusted be-
tween the minimum and maximum lev-
els.
❍If the battery charge is low, it will not
be possible to adjust the volume be-
tween the minimum and maximum
levels.
247-280 Alfa Giulietta EN 3ed 13-04-2010 11:52 Pagina 265

266
SOUND SYSTEM
SPEECH VOLUME function
(telephone volume
adjustment)
This function makes it possible to adjust (set-
ting from 1 to 40), by turning the left knob
A-fig. 1 or pressing buttons
/or ex-
clude (OFF setting) the volume of the Tele-
phone and Blue&Me
™(except the Media
Player function).
The display shows the current function status:
❍“Speech Off”: function deactivated.
❍“Speech Volume 23”: function activat-
ed with volume set to 23.
RADIO OFF function
(on and off mode)
This function is used to select the mode for
switching off the radio between two differ-
ent procedures. To turn the function on use
buttons
or.
The selected mode will appear on the dis-
play:
❍“00 MIN”: the radio turns off automat-
ically in connection with the ignition key;
the radio turns off automatically as soon
as the key is turned to the STOP posi-
tion;
❍“20 MIN”: the radio turns off indepen-
dently from the ignition key; the radio
remains on for a maximum period of 20
minutes after the key has been turned
to the STOP position.
SYSTEM RESET function
This function is used to restore all settings
to their preset factory values. The options
are:
❍NO: no restore operation;
❍YES: the default parameters are re-
stored. The display will show “Reset-
ting” during this operation. At the end
of the operation, the source does not
change and the previous situation will
be displayed.
247-280 Alfa Giulietta EN 3ed 13-04-2010 11:52 Pagina 266

269
SOUND SYSTEM
R R
A A
D D
I I
O O

( (
T T
u u
n n
e e
r r
) )
INTRODUCTION
When the radio is turned on the last func-
tion selected before it was switched off is
activated: Radio, CD, CD MP3 or Media
Player (only with Blue&Me™).
To select the Radio function whilst listening
to another audio source, press the FM
ASor
AM buttons briefly, depending on the desired
band.
Once the Radio mode has been activated,
the display will show the name (RDS sta-
tions only) and the frequency of the select-
ed radio station, the frequency band select-
ed (e.g. FM1) and the preselect button num-
ber (e.g. P1).
FREQUENCY BAND
SELECTION
With the Radio mode activated, press the FMAS
or AM button briefly and repeatedly to select
the desired reception band.
Each time the button is pressed the follow-
ing bands are selected cyclically:
❍Pressing the FMASbutton: “FM1”,
“FM2” or “FMA”;
❍Pressing the AM button: “MW1” and
“MW2”.
Each band is highlighted by the name in the
display. The last station selected on the re-
spective frequency band will be tuned into.
The FM band is divided into sections: FM1,
FM1 or “FMA”; the FMA reception band is
reserved for broadcasters stored automati-
cally using the AutoSTore function.
PRESET BUTTONS
The buttons numbered from 1 to 6 can used
to set the following presettings:
❍18 on the FM band FM (6 on FM1, 6
on FM2, 6 on FMT or “FMA” (on some
versions);
❍12 on the MW band (6 on MW1, 6 on
MW2).
To listen to a preset station, select the desired
frequency band and then briefly press the cor-
responding preset button (from 1 to 6).
By pressing the preset button for more than
2 seconds, the station tuned into will be
stored. The storing phase is confirmed by an
acoustic signal.
247-280 Alfa Giulietta EN 3ed 13-04-2010 11:52 Pagina 269

270
SOUND SYSTEM
STORING THE LAST STATION
LISTENED TO
The radio automatically stores the last sta-
tion that was selected for each reception
band, which is then tuned into when the
radio is turned on or when the reception
band is changed.
AUTOMATIC TUNING
Briefly press buttons orto start the
automatic tuning search for the next station
that can be received in the selected direc-
tion.
If the
orbuttons are pressed down for
longer, the fast search starts. When the but-
ton is released, the tuning will stop at the
next station that can be received.
If the TA function (traffic information) is on,
the tuner will only search for stations that
broadcast traffic updates.
MANUAL TUNING
This allows a manual search for stations on
the preselected band.
Select the desired frequency band and then
press the
or button briefly and repeat-
edly to start to the search in the desired di-
rection. If the
or buttons are pressed
for longer, the fast search will start and then
stop when the button is released.
247-280 Alfa Giulietta EN 3ed 13-04-2010 11:52 Pagina 270

271
SOUND SYSTEM
AUTOSTORE FUNCTION
To activate the AutoSTore function, keep the
FM
ASbutton pressed until the acoustic con-
firmation signal. With this function, the ra-
dio automatically stores the 6 stations with
the strongest signal in a decreasing order on
the FMA frequency band.
During the automatic storing process,
“Autostore” will appear flashing on the dis-
play. To interrupt the Autostore function, press the
FM
ASbutton again: the radio will again tune
into the station listened to before the activa-
tion of the function.
When the AutoSTore function is over, the ra-
dio automatically tunes into the first prese-
lected station on the FMA band on the pre-
setting 1 side.
The stations that have a strong signal at that
moment are then automatically stored in the
preselected band in the buttons numbered
1 to 6.
When the AutoSTore function is activated
within the MW band, the FMA band is au-
tomatically selected and the function is per-
formed.IMPORTANT Sometimes the AutoSTore func-
tion does not manage to find 6 stations with
a strong signal
. In this case, the strongest
stations will be duplicated in the free pre-
set buttons.
IMPORTANT When the AutoSTore function is
activated, the stations that were previously
stored on the FMA band are deleted.
247-280 Alfa Giulietta EN 3ed 13-04-2010 11:52 Pagina 271

282
GETTING
TO KNOW
YOUR CAR
SAFETY
STARTING
AND DRIVING
IN AN
EMERGENCY
SERVICING AND
MAINTENANCE
TECHNICAL
SPECIFICATIONS
CONTENTS
– courtesylights ................... 83
– front ceiling light................ 81
– glove compartment light ...... 84
– puddle lights ..................... 84
Changing awheel ................... 162
Changing bulbs
– exteriorlights .................... 177
– interiorlights ..................... 182
Checking liquid
levels ............. 208-209-210-211
Child safety lock ..................... 96
Child seat (compliance for use) .. 141
Child seat assembly
“Universal model”................ 139
Cigar lighter ............................ 90
Cleaning and maintenance
– bodywork ......................... 221
– engine compartment ........... 222
– interiors ............................ 223
– leather upholstery .............. 224
– plastic parts........................ 223– seats................................. 223
– windows............................ 222
Climate control system ............. 57
– air vents ..................... 57-58
Climatic comfort ..................... 59
Clutch .................................... 230
CO
2emissions ......................... 245
CODE card ............................. 41
Control buttons ....................... 23
Controls ................................. 85
Courtesy lights ........................ 76
Cruise Control ......................... 79
D.R.L. (Daytime Running Lights) 74
Dashboard ............................. 3
Dimensions of the car .............. 236
Dipped beam headlights
– bulb replacement ................ 178
– control............................... 74Dipped beam headlights
– bulb replacement ................ 178
– control............................... 74
Direction indicators
– bulb replacement........... 178-179
– control............................... 75
Direction indicators
– bulb replacement ................ 178
– control............................... 75
Display
– Multifunction display ........... 20
– Reconfigurable multifunction
display ............................. 21
Door locks ............................. 86
Doors..................................... 95
– child safety lock ................. 95
– emergency rear door
locking device .................... 97
– remote locking/unlocking ... 95
DPF (Diesel Particulate Filter) ... 129
DST system............................. 112
281-292 Alfa Giulietta EN 5ed 26-07-2010 16:37 Pagina 282

DASHBOARD
1. Fixed vent for sending air to side windows - 2. Adjustable air vent - 3. Passenger front air bag - 4. Upper adjustable vents - 5. Hazard warning
lights - 6. Radio navigator display (for versions/markets, where provided) - 7. External light control stalk - 8. Instrument panel - 9. Windscreen
wiper/rear window wiper/trip computer stalk - 10. Headlight alignment corrector (for versions/markets, where provided) and Set Up Menu
access buttons - 11. Ignition device - 12. Driver's front air bag - 13. Cruise Control stalk (for versions/markets, where provided) - 14. Control
buttons: fog lights/rear fog light, Start&Stop system (for versions/markets, where provided), door locking/unlocking, AFS light on/off (for
versions/markets, where provided) - 15. “Alfa DNA” system - 16. Gear lever - 17. Heating/ventilation/air conditioning controls - 18. Sound sys-
tem (for versions/markets, where provided) - 19. Central adjustable air vents - 20. Glove compartment.
A0K0225m
19.522.0cACAAUT O
MONOC
123
4
56
4789
21
20
19
1817
16
1514
1312
1110
288
RIGHT-HAND DRIVE VERSIONS
281-292 Alfa Giulietta EN 5ed 26-07-2010 16:37 Pagina 288
