2010 Alfa Romeo 159 Owner handbook (in English)

OWNER’S MANUALALFA
159
SERVICE
ENGLISH
Alfa 159 cop. LUM GB 1-10-2007 9:40 Pagina 1

This booklet describes all the versions of the Alfa 159, so you should only consider the infor-
mation concerning the trim level, engine and version purchased by you. Dear Customer,
thank you for choosing Alfa Romeo.
Yo u r
Alfa 159has been designed to guarantee the safety, comfort and driving pleasure typical of
Alfa Romeo.
This booklet will help you to get to know the characteristics and operation of your car.
The following pages contain all the indications necessary for you to be able to maintain the high standards of per-
formance, quality, safety and respect for the environment which characterize this
Alfa 159.
The enclosed Warranty Booklet also contains the regulations, the warranty certificate and a guide to the services of-
fered by Alfa Romeo.
Services which are essential and precious because, when you purchase an Alfa Romeo you are not only acquiring a
car, but the tranquillity that comes from knowing that an efficient, willing and widespread organization is at your ser-
vice for any assistance problems you may have.
Have a good trip.
001-045 Alfa 159 GB 8-04-2009 10:47 Pagina 1

MUST BE READ!
REFUELLING
Petrol engines: only refuel with unleaded petrol with octane rating (RON) not less than 95.
Diesel engines: only refuel with diesel fuel conforming to the European specification EN590. The use of
other products or mixtures may irreparably damage the engine with invalidation of the warranty due to the
damage caused.
K
ENGINE STARTING
Petrol engines: ensure that the handbrake is up, fully press the clutch pedal, without pressing the accelerator, put
the gear lever neutral, fit the electronic key into the ignition device to stop limit, briefly press the START/STOPbut-
ton.
Diesel engines:ensure that the handbrake is up, fully press the clutch pedal, without pressing the accelerator, put
the gear lever neutral, fit the electronic key down into the ignition device until it stops. The instrument panel warning
light
mwill turn on, wait for the warning light mto turn off. The hotter the engine is, the quicker this will happen,
briefly press the START/STOPbutton as soon as the warning light
mturns on.
PARKING ON FLAMMABLE MATERIAL
While working, the catalyst develops a very high temperature. Do not park the car over grass, dry leaves, pine
needles or any other inflammable materials: risk of fire.

RESPECTING THE ENVIRONMENT
A system for continuously monitoring emission system components to ensure greater environmental protec-
tion is fitted in your car.
001-045 Alfa 159 GB 8-04-2009 10:47 Pagina 2

ELECTRICAL ACCESSORIES
If, after buying the car, you decide to add electrical accessories (that will gradually drain the battery), contact Al-
fa Romeo Authorized Services. They can calculate the overall electrical requirement and check that the car’s elec-
tric system can support the required load.

CODE CARD(for versions/markets, where provided)
Keep the code card in a safe place, not in the car.
SCHEDULED SERVICING
Correct maintenance of the car is essential for ensuring it stays in tip-top condition and safeguards its safety fea-
tures, its environmental friendliness and low running costs for a long time to come.
THE OWNER’S MANUAL CONTAINS…
…information, tips and important warnings regarding the safe, correct driving of your car, and its mainte-
nance. Pay particular attention to the symbols
"(personal safety) #(environmental protection) â(car well-be-
ing).
001-045 Alfa 159 GB 8-04-2009 10:47 Pagina 3

Any queries concerning servicing should be forwarded to the showroom from which the car was purchased, the sub-
sidiary company or to our branch offices or any point of the Alfa Romeo Network.
Warranty Booklet
The Warranty Booklet is delivered together with every new car and contains the regulations tied to the services giv-
en by Alfa Romeo Services and to the warranty conditions.
Correctly carrying out the scheduled services specified by the manufacturer is the best way to maintain the perfor-
mance, safety characteristics and low running costs of your car. It is also necessary to maintain warranty cover.
“Service” guide
This contains the Alfa Romeo Authorized Services. The services can be recognized by the presence of the Alfa Romeo
badge and logo.
The Alfa Romeo organization in Italy can be found in the telephone book under the letter “A” Alfa Romeo.
Not all the models described in this booklet are available in all countries. Only some of the fittings described in this
booklet are fitted as standard to the car. The list of available accessories should be requested from the Alfa Romeo
Dealers.
001-045 Alfa 159 GB 8-04-2009 10:47 Pagina 4

THE SYMBOLS USED IN THIS BOOKLET
The symbols illustrated in these pages show the subjects which should,
in particular, be closely studied.
Warning: partially or
fully ignoring these rules may lead
to serious injury.This indicates the correct procedures
to be followed to prevent
the car from damaging the environment.Warning: partially or fully ignoring these
rules may lead to serious damage
being caused to the car which, in some
circumstances, may cause forfeiture of the
warranty cover.
The texts, illustrations and specifications given in this booklet refer to the car at the time of going to press.
As part of our ongoing striving to improve our products, Alfa Romeo may introduce technical changes during production, there-
fore the specifications and fittings may be altered without prior notice.
For details on this subject, please apply to the manufacturer's sales network.
PERSONAL
SAFETYPROTECTING THE
ENVIRONMENT CAR SAFETY
001-045 Alfa 159 GB 8-04-2009 10:47 Pagina 5

6
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
D D
A A
S S
H H
B B
O O
A A
R R
D D

A A
N N
D D

C C
O O
N N
T T
R R
O O
L L
S S
CRUISE CONTROL ............................................. 76
CEILING LIGHTS................................................ 78
CONTROLS....................................................... 81
INTERIOR FITTINGS............................................ 83
SUNROOF........................................................ 93
DOORS ........................................................... 96
POWER WINDOWS ........................................... 99
BOOT .............................................................. 101
BONNET.......................................................... 105
ROOF RACK/SKI RACK ...................................... 106
HEADLIGHTS..................................................... 106
ABS SYSTEM ................................................... 108
VDC SYSTEM ................................................... 110
EOBD SYSTEM ................................................. 115
SOUND SYSTEM PRESETTING .............................. 116
ACCESSORIES PURCHASED BY THE OWNER .......... 116
INSTALLATION OF ELECTRIC/ELECTRONIC DEVICES .. 117
PARKING SENSORS ........................................... 118
TYRE PRESSURE MONITORING SYSTEM
(T.P.M.S.) ........................................................ 122
AT THE FILLING STATION .................................... 125
PROTECTING THE ENVIRONMENT ........................ 127 DASHBOARD.................................................... 7
INSTRUMENT PANEL ......................................... 8
SYMBOLS ....................................................... 9
ALFA ROMEO CODE SYSTEM ............................... 9
ELECTRONIC KEY .............................................. 11
ALARM ........................................................... 17
IGNITION DEVICE............................................... 19
INSTRUMENTS.................................................. 21
MULTIFUNCTION DISPLAY ................................... 25
RECONFIGURABLE MULTIFUNCTION DISPLAY .......... 30
SEATS ............................................................ 45
HEAD RESTRAINTS............................................. 48
STEERING WHEEL ............................................. 49
REARVIEW MIRRORS ......................................... 50
CLIMATE CONTROL SYSTEM ............................... 53
MANUAL CLIMATE CONTROL SYSTEM ................... 55
AUTOMATIC TWO-/THREE-ZONE
CLIMATE CONTROL SYSTEM ............................... 58
ADDITIONAL HEATER ......................................... 69
EXTERNAL LIGHTS............................................. 70
WINDOW WASHING ......................................... 73
001-045 Alfa 159 GB 8-04-2009 10:48 Pagina 6
