2010.5 Peugeot 508 Dag display

291
1
2
04 AUDIO
Radio text is information transmitted by the radio station related to the current programme or song.
With the radio displayed on the screen, press OK to display the contextual menu.
Select " RadioText (TXT) display " and confi rm OK to save.
DISPLAY RADIO TEXT
Screen C

294
04
1
3
2
4
5
CD, USB
AUDIO
PLAYING A COMPILATION
Insert an MP3 compilation in the CD player or connect a memory stick to the USB port, directly or via an extension lead.
The system creates playlists (temporary memory) the creation time for which can take from a few seconds to several minutes.
The playlists are updated every time the ignition is switched off or a USB memory stick is connected.
Play starts automatically after a period which depends on the capacity of the USB memory stick.
At a fi rst connection, the order suggested is by folder. When connecting again, the order previously chosen is retained.
To play a disc or memory stick which has already been inserted, press SOURCE several times in succession and select " CD " or " USB ".
Press one of the buttons to select the next or previous track.
Press one of the buttons to select the next or previous folder in the order chosen.
Press and hold one of the buttons for fast forwards or backwards.
Press LIST to display the menu of folders in the compilation.

302


1
2
3
4
05
5
USING THE TELEPHONE
The telephone connection automatically includes hands free operation and audio streaming.
Press MENU .
Select " Bluetooth connection " and confi rm.
Indicates connection of the audio steaming profi le.
MANAGING CONNECTIONS
Select " Connections management " and confi rm. The list of paired telephones is displayed.
Select a telephone and confi rm.
Indicates connection of the hands-free profi le.
Then select and confi rm:
- " Connect telephone "/" Disconnect telephone ": to connect/disconnect the telephone or the hands-free connection only.
- " Connect media player "/Connect media player" Disconnect media player ": to Disconnect media playerconnect/disconnect only streaming.
- " Connect telephone + media player "/" playerDisconnect telephone + media player ": to connect/disconnect media playerthe telephone (hands-free and streaming).
- " Delete connection ": to delete the pairing.
Indicates that a device is connected.

303


1
2
1
4
2
33
05
USING THE TELEPHONE
To display the " TELEPHONE " menu: - Make along press on SOURCE . - Or, press OK to display the contextual menu. Select " Call " and confi rm. - Or, press MENU , select " Telephone " and confi rm. Select " Call " and confi rm.
Select " Dial " to enter a number and confi rm.
Repeat the previous step 1 to display the " TELEPHONE " menu.
Select OK and confi rm to start the call.
Select " Calls list " and confi rm.
MAKING A CALL - DIALLING
Select numbers one at a time using the  and  buttons and confi rm.
MAKING A CALL - RECENTLY CALLED
NUMBERS *
Select the number and confi rm to start the call.
The calls list includes calls sent and received in the vehicle
using the connected telephone.
* Depending on the compatibility of the telephone.
Correction allows numbers to be deleted one at a time.

304


1
2
1
4
2
3
05 USING THE TELEPHONE
Repeat the previous step 1 to display the " TELEPHONE " menu.
Select " Directory " and confi rm.
An incoming call is announced by a ring and a superimposed di splay in the multifunction screen.
Mobile
(depending on the information available in the contact records of the telephone connected).
" YES " " " to accept the call is selected by default.
Press OK to accept the call.
Select " NO " and confi rm to reject the call.
or
Press SOURCE to accept the call.
MAKING A CALL - FROM THE
DIRECTORY
Select a contact then confi rm.
RECEIVING A CALL
Select the number and confi rm. A long press on ESC or on SOURCE also rejects an incoming call.
Business
Home

305

1
2a2c
2b
05 USING THE TELEPHONE
During a call, press OK to display the contextual menu.
Hang up
In the contextual menu:
- select " Telephone mode " to transfer the call to the telephone.
- deselect " Telephone mode " to transfer the call to the vehicle.
In the contextual menu:
- select " Micro OFF " to switch off the microphone.
- deselect " Micro OFF " to switch the microphone on.
In certain cases, the combined mode has to activated from the telephone.
If the contact has been cut off, when you reconnect on returning to the vehicle, the Bluetooth connection will be restored automatically (depending on the compatibility of the telephone).
MANAGING CALLS
A long press on SOURCE or TEL also ends the call.
In the contextual menu, select " Hang up " to end the call.
Secret - Mute
(so that the caller cannot hear)
Combined mode
(to leave the vehicle without ending the call)

309
5
63
4
07
2
1
CONFIGURATION
SETTING THE DATE AND TIME
Select the setting to be modifi ed. Confi rm by pressing OK , then make the change and confi rm again to save the modifi cation.
Using the arrows, select " Display confi guration " and confi rm.
Press the MENU button.
Using the arrows, select " Personalisation-confi guration " and confi rm.
SCREEN C
Using the arrows, select " Date and time adjustment " and confi rm.
Adjust the settings one by one, confi rming by pressing the OKbutton. Next select the " OK " tab on the screen then confi rm to exit from the " Date and time adjustment " menu.

312
09 SCREEN MENU MAP
Personalisation-
Configuration
Choice of language
Display confi guration
Trip computer
Vehicle diagnosis *
Bluetooth connection
Connections management
Search for a device
* The parameters vary according to the vehicle.
Choice of units
Date and time adjustment
Display parameters
Brightness
1
1
2
2
2
2
1
1
1
