Electric child lock Remote control system to prevent opening of the rear doors using their interior controls and use of the rear electric windows . The control is located on the dashboard, driver’s side.
Switching on
 Press this button. The indicator lamp in the button comes on, accompanied by a message in the screen. This indicator lamp remains on until the child lock is switched off.
Switching off
 Press this button again. The indicator lamp on button A goes off, accompanied by a message in the screen. This indicator lamp remains on while child lock is switched on.
This system is independent and in no circumstances does it take the place of
the central locking control. Check the status of the child lock each time you switch on the ignition. Always remove the key from the ignition when leaving the vehicle, even for a shor t time. In the event of a serious impact, the electric child lock is switched off automatically to permit the exit of the rear passengers.
Any other status of the indicator lamp indicates a fault with the electric child lock. Have it checked by a CITROËN dealer or a qualified workshop.

Front airbags
System which protects the driver and front passenger in the event of a serious front impact in order to limit the risk of injury to the head and thorax. The driver's airbag is fitted in the centre of the steering wheel; the front passenger's airbag is fitted in the dashboard above the glove box.
Deployment
The airbags are deployed simultaneously, unless the passenger's front airbag is deactivated, in the event of a serious front impact to all or par t of the front impact zone A , in the longitudinal centreline of the vehicle on a horizontal plane and directed from the front to the rear of the vehicle.
The front airbag inflates between the thorax and head of the front occupant of the vehicle and the steering wheel, driver's side, and the
dashboard, passenger's side to cushion their for ward movement.

For the airbags to be fully effective, observe the following safety rules:
Front airbags
Do not drive holding the steering wheel by its spokes or resting your hands on the centre par t of the wheel.
Passengers must not place their feet on the dashboard. If possible, do not smoke as deployment of the airbags can cause burns or the risk of injury from a cigarette or pipe. Never remove or pierce the steering wheel or hit it violently.
Lateral airbags
Use only approved covers on the seats, compatible with the deployment the lateral airbags. For information on the range of seat covers suitable for your vehicle, you can contact a CITROËN dealer (see "Practical information - § Accessories"). Do not fix or attach anything to the seat backs (clothing...). This could cause injury to the chest or arms if the lateral airbag is deployed. Do not sit with the upper par t of the body any nearer to the door than necessary.
Curtain airbags
Do not fix or attach anything to the roof. This could cause injury to the head if the cur tain airbag is deployed.
Do not remove the grab handles installed on the roof, they play a par t in securing the cur tain airbags.
Sit in a normal upright position. Wear a correctly adjusted seat belt. Do not leave anything between the occupants and the airbags (a child, pet, object...). This could hamper the operation of the airbags or injure the occupants. After an accident or if the vehicle has been stolen or broken into, have the airbag systems checked. All work on the airbag system must be carried out by a CITROËN dealer or a qualified workshop. Even if all of the precautions mentioned are obser ved, a risk of injury or of minor burns to the head, chest or arms when an airbag is deployed cannot be ruled out. The
bag inflates almost instantly (within a few milliseconds) then deflates within the same time discharging the hot gas via openings provided for this purpose.

For the airbags to be fully effective, observe the following safety rules:
Front airbags
Do not drive holding the steering wheel by its spokes or resting your hands on the centre par t of the wheel.
Passengers must not place their feet on the dashboard. If possible, do not smoke as deployment of the airbags can cause burns or the risk of injury from a cigarette or pipe. Never remove or pierce the steering wheel or hit it violently.
Lateral airbags
Use only approved covers on the seats, compatible with the deployment the lateral airbags. For information on the range of seat covers suitable for your vehicle, you can contact a CITROËN dealer (see "Practical information - § Accessories"). Do not fix or attach anything to the seat backs (clothing...). This could cause injury to the chest or arms if the lateral airbag is deployed. Do not sit with the upper par t of the body any nearer to the door than necessary.
Curtain airbags
Do not fix or attach anything to the roof. This could cause injury to the head if the cur tain airbag is deployed.
Do not remove the grab handles installed on the roof, they play a par t in securing the cur tain airbags.
Sit in a normal upright position. Wear a correctly adjusted seat belt. Do not leave anything between the occupants and the airbags (a child, pet, object...). This could hamper the operation of the airbags or injure the occupants. After an accident or if the vehicle has been stolen or broken into, have the airbag systems checked. All work on the airbag system must be carried out by a CITROËN dealer or a qualified workshop. Even if all of the precautions mentioned are obser ved, a risk of injury or of minor burns to the head, chest or arms when an airbag is deployed cannot be ruled out. The
bag inflates almost instantly (within a few milliseconds) then deflates within the same time discharging the hot gas via openings provided for this purpose.

257Practical information
Changing a fuse
The extraction tweezer is fitted to a carrier clipped to the dashboard fusebox cover. For access to it:  open the glove box lid,  unclip the carrier on the fusebox cover by pulling on the right
Access to the tools
 remove the tweezer,  open the fusebox cover by pulling at top right,
 fold down completely the fusebox cover.
Changing foglamp bulbs
These bulbs are replaced from outside the rear bumper:  pass your hand under the bumper, turn the bulb holder a quarter turn and remove it, turn the bulb a quar ter turn, pull it out and fit a new bulb.
For reassembly, carry out these operations in reverse order.
Take care not to touch the silencer; there is a risk of burns if changing a bulb within a few minutes of switching off the ignition.

257Practical information
Changing a fuse
The extraction tweezer is fitted to a carrier clipped to the dashboard fusebox cover. For access to it:  open the glove box lid,  unclip the carrier on the fusebox cover by pulling on the right
Access to the tools
 remove the tweezer,  open the fusebox cover by pulling at top right,
 fold down completely the fusebox cover.
Changing foglamp bulbs
These bulbs are replaced from outside the rear bumper:  pass your hand under the bumper, turn the bulb holder a quarter turn and remove it, turn the bulb a quar ter turn, pull it out and fit a new bulb.
For reassembly, carry out these operations in reverse order.
Take care not to touch the silencer; there is a risk of burns if changing a bulb within a few minutes of switching off the ignition.

259Practical information
Dashboard fuses
The fusebox is placed in the lower dashboard (left-hand side).
Access to the fuses
 Refer to the paragraph "Access to the tools".
Fuse tables
Removable
relay N°RatingFunctions
R1- Not used.
R2- 12 V socket in boot.
Fuse N°RatingFunctions
F320 A Parking lamps, trailer hazard warning lamps
F420 A Interior lighting, trailer inter face.
F530 A Front one-touch electric windows.
F6- Not used.
F1120 A 12 V trailer socket.
F12- Not used.
F1330 A Hi-Fi amplifier.
F2220 A Trailer signalling.

281Technical data

Identifi cation markings
Various visible markings for the identification of yo ur vehicle.
A. Vehicle identification number (VIN) under the bonnet. This number is engraved on the bodywork near the engine mounting.
B. Vehicle identification number on the dashboard. This number is indicated on a self-adhesive label which is visible through the windscreen.
D. Tyre/paint label. This label is affixed to the driver's front pillar.
Wheels which are fitted with 225/40 R18 tyres cannot be fitted with snow chains. For more information, contact a CITROËN dealer or a qualified workshop.
Low tyre pressures increase fuel consumption.
The tyre pressures must be checked
when the tyres are cold, at least once a month.
C. Manufacturer's label. The VIN is indicated on a self-destroying label affixed to the driver's centre pillar.
It bears the following information: - the tyre pressures, for unladen and laden conditions, - the wheel rim and tyre sizes, - the brands of tyre recommended by the manufacturer, - the spare tyre inflation pressure, - the paint colour code.
