System which prevents the vehicle from exceeding the speed programmed by the driver. When the programmed speed limit is reached, pressing the accelerator pedal no longer has any effect.
Speed limiter
The speed limiter cannot, in any circumstances, replace the need to respect speed limits, nor can it replace the need for vigilance and responsibility on the part of the driver.
The functions of this system are grouped together on the steering mounted controls. 1. Speed limiter mode selection dial. 2. Programmed value decrease button. 3. Programmed value increase button. 4. Speed limiter on/off button. 5. List of memorised speeds display button. (see "Memorising speeds")
Steering mounted controls
The programmed information is grouped together in the instrument panel screen. 6. Speed limiter on/off indication. 7. Speed limiter mode selection indication. 8. Programmed speed value. 9. Selection of a memorised speed. (see "Memorising speeds")
Displays in the instrument panel
Operation
The speed limiter is switched on manually: it requires a programmed speed of at least20 mph (30 km/h). The speed limiter is switched off by manual d offoperation of the control. The programmed speed can be exceeded temporarily by pressing the accelerator firmly beyond the point of resistance. To return to the programmed speed, simply release the accelerator pedal. The programmed speed remains in the memory when the ignition is switched off.
Page 192 of 342
215Driving
Turn dial 1 to the "LIMIT" position: the speed limiter mode is selected but is not switched on (Pause). You do not have to switch the speed limiter on
in order to set the speed. Set the speed value by pressing button 2or 3 (e.g.: 55 mph (90 km/h)).
Programming
You can then change the programmed speed using buttons 2 and 3 : - by + or - 1 mph (km/h) = shor t press, - in steps of + or - 5 mph (km/h) = maintained press. If speed memorisation is available and activated on your vehicle, the programmed speed will stop at the closest memorised speed; refer the the corresponding paragraph. Switch the speed limiter on by pressing button 4 . Switch the speed limiter off by pressing button 4 : the display confirms that it has been switched off (Pause). Switch the speed limiter back on by pressing button 4 again.
Exceeding the programmed speed
Pressing the accelerator pedal to exceed the programmed speed will not have any effect unless you press the pedal firmly past the mlypoint of resistance . The speed limiter is deactivated temporarily and the programmed speed,
which is still displayed, flashes. Returning to the programmed speed, by means of inten tional or unintentional deceleration of the vehicle, automatically cancels the flashing of the programmed speed.
On a steep descent or in the event of sharp acceleration, the speed limiter will not be able to prevent the vehicle from
exceeding the programmed speed. To avoid any risk of jamming of the pedals: - ensure that the mat is positioned correctly, - do not fit one mat on top of another.
Exiting the speed limiter mode
Turn dial 1 to the "0" position: the speed limiter mode is deselected. It disappears from the screen.
Operating fault
In the event of a fault with the speed limiter, the speed is cleared resulting in flashing of the dashes. Have it checked by a CITROËN dealer or a qualified workshop.
Page 193 of 342
Cruise control
System which automatically maintains the speed of the vehicle at the value programmed by the driver, without any action on the accelerator pedal.
The functions of this system are grouped together on the steering mounted controls. 1. Cruise control mode selection dial. 2. Speed programming/value decrease button. 3. Speed programming/value increase button. 4. Cruise control off/resume button. 5. Stored speeds display button. (see "Storing speeds")
Steering mounted controls
The cruise control system cannot, in any circumstances, replace the need to respect speed limits, nor can it replace the need for vigilance and responsibility on the par t of the driver. You are advised to keep your feet near the pedals at all times.
The programmed information is grouped together in the instrument panel screen. 6. Cruise control off/resume indication. 7. Cruise control mode selection indication. 8. Programmed speed value. 9. Selecting a stored speed. (see "Storing speeds")
Displays in the instrument panel
Operation
The cruise control is switched on manually: it requires a minimum vehicle speed of 25 mph (40 km/h) and engagement of: - four th gear on the manual gearbox, - second gear on the electronic gearbox system, in sequential driving mode, - position A on the electronic gearbox system. The cruise control is switched off manually d offor by pressing the brake or clutch pedal or on triggering of the ESP system for safety reasons. It is possible to exceed the programmed speed temporarily by pressing the accelerator pedal. To return to the programmed speed, simply
release the accelerator pedal. Switching off the ignition cancels any programmed speed value.
Page 195 of 342
Parking space sensors
System which measures the parking space available between two vehicles or obstacles. It measures the size of the space and gives you information on: - the possibility of fitting into a free space,
depending on the dimensions of your vehicle and the distances needed for manoeuvring, - the level of difficulty of the manoeuvre to be per formed. The system does not measure spaces which
are clearly much smaller or larger than the size of the vehicle.
Displays in the instrument panel You have identified a parking space: Press button A to select the function. Operate the direction indicator on the side where the space is to be measured; a message is displayed to confirm that measurement is in progress. During measurement, go for ward the length of the space, at a speed less than 12 mph (approx. 20 km/h), to prepare for your manoeuvre. Once the measurement has been completed, the system informs you of the level of difficulty of the manoeuvre by a message in the multifunction screen
accompanied by an audible signal.
Operation
The parking space sensor function warning lamp can have two different states:
- on fixed: the function is selected by a press on control A . - off: the function is not selected,
Page 196 of 342
219Driving
The function displays the following types of message: The function deselects itself automatically: - when you engage reverse gear, - when you switch off the ignition, - if measuring is not requested,
- within five minutes of selection of the function, - if the vehicle speed exceeds the threshold of 45 mph (approx. 70 km/h) for one minute.
If the lateral distance between your vehicle and the parking space is too large, the system may not be able to measure the space.
The system remains available after each measurement and can therefore measure several spaces in succession. In poor or wintry weather, ensure that the
sensors are free of dir t, ice or snow. The parking space sensor system deactivates the front parking sensors when measuring for wards.
Parking possible
Parking difficult
Parking not advised
If there is a fault, have the system checked by a CITROËN dealer or a qualified workshop.
Page 197 of 342
Parking sensors
This system indicates the proximity of an obstacle (person, vehicle, tree, gate, etc.) which comes within the field of detection of sensors located in the bumper. Cer tain types of obstacle (stake, roadworks cone, etc.) detected initially will no longer be detected at the end of the manoeuvre due to
the presence of blind spots.
This function cannot, in any circumstances, take the place of the vigilance and responsibility of the driver.
The system is switched on by engaging reverse gear. This is accompanied by an audible signal. The system is switched off when you exit reverse gear.
Rear parking sensors
Audible assistance
The proximity information is given by an intermittent audible signal, the frequency of which increases as the vehicle approaches the obstacle. The sound emitted by the speaker (right or left) indicates the side on which the obstacle is located. When the distance between the vehicle and the obstacle becomes less than approximately thir ty centimetres, the audible signal becomes continuous.
Visual assistance
This supplements the audible signal by displaying bars in the multifunction screen which move progressively nearer to the vehicle. When the obstacle is near, the "Danger" symbol is also displayed in the screen.
Page 198 of 342
221Driving
Front parking sensors Operating fault
If an operating fault occurs, when reverse gear is engaged this warning lamp is displayed in the
instrument panel and/or a message appears in the screen, accompanied by an audible signal (shor t beep). Contact a CITROËN dealer or a qualified workshop.
In addition to the rear parking sensors, the front parking sensors are triggered when an obstacle is detected in front and the speed of the vehicle
is still below 6 mph (10 km/h). The sound emitted by the speaker (front or rear) indicates whether the obstacle is in front or behind. The front parking sensors are interrupted if the vehicle stops for more than three seconds in for ward gear, if no fur ther obstacles are detected or when the speed of the vehicle exceeds 6 mph (10 km/h).
The function will be deactivated automatically if a trailer is being towed or a bicycle carrier is fitted (vehicle fitted with a towbar or bicycle carrier recommended by CITROËN).
In bad weather or in winter, ensure that the sensors are not covered with mud, ice or snow. When reverse gear is engaged, an audible signal (long beep) indicates that the sensors may be dir ty. When the vehicle is moving at a speed below 6 mph (10 km/h), cer tain sound sources (motorcycle, lorry, pneumatic drill, etc.) may trigger the audible signals of the parking sensor system.
Deactivation/Activation of the front and rear parking sensors
The function is deactivated by pressing this button. The indicator lamp in the button
comes on. Pressing this button again reactivates the function. The indicator lamp in the button goes off.
Page 259 of 342
289
01
1. Rotary control:
- S h o r t p r e s s e n g i n e n o t r u n n i n g : o n / o f f .
- S h o r t p r e s s e n g i n e r u n n i n g : m u t e o n / o f f .
- Rotation: volume adjustment (each source i s i n d e p e n d a n t , i n c l u d i n g T A m e s s a g e s a n d n a v i g a t i o n i n f o r m a t i o n ) .
2. Radio source, access to the FM/AM bandmenu and display the list of stations.
3 . A c c e s s t o t h e MEDIA menu and display the list of tracks.
4 . A c c e s s t o t h e Navigation - guidance menu and display the last destinations.
5 . A c c e s s t o t h e T r a f fi c i n f o r m a t i o n menu and d i s p l a y t h e c u r r e n t t r a f fi c a l e r t s .
6 . A c c e s s t o t h e " Telephone " m e n u a n d d i s p l a y the recent calls list.
2 - 3 . L o n g p r e s s : a c c e s s t o t h e Audio settings : music ambiance, bass, treble, loudness, l e f t / r i g h t b a l a n c e , f r o n t / r e a r f a d e r , a u t o m a t i c volume adjustment.
7 . A c c e s s t o t h e " C o n fi g u r a t i o n " m e n u .
L o n g p r e s s : a c c e s s t o t h e G P S c o v e r a g e a n d t h e n a v i g a t i o n d e m o n s t r a t i o n m o d e .
8 . M O D E b u t t o n :
Selection of the type of permanent display.
L o n g p r e s s : b l a c k s c r e e n ( D A R K ) .
9 . E S C : a b a n d o n t h e o p e r a t i o n i n p r o g r e s s , u p one level in the menu.
L o n g p r e s s : r e t u r n t o p e r m a n e n t d i s p l a y .
1 0 . C D e j e c t .
Continuous press: reinitialisation of the system.
1 1 . A c c o r d i n g t o c o n t e x t :
S e l e c t i o n o f t h e p r e v i o u s / n e x t l i n e i n a l i s t o r menu.
S e l e c t i o n o f t h e p r e v i o u s / n e x t m e d i a f o l d e r .
S t e p b y s t e p s e l e c t i o n o f t h e p r e v i o u s / n e x t radio frequency.
M o v e u p / d o w n i n Move the map mode.
1 2 . A c c o r d i n g t o c o n t e x t :
A u t o m a t i c s e l e c t i o n o f t h e n e x t l o w e r / h i g h e r radio frequency .
S e l e c t i o n o f t h e p r e v i o u s / n e x t C D o r m e d i a track .
S e l e c t i o n o f l e f t / r i g h t o n t h e s c r e e n w h e n a menu is displayed.
M o v e l e f t / r i g h t i n Move the map mode.
13. Buttons 1 to 6:
Short press: selection of the stored radio station.
L o n g p r e s s : s t o r e t h e c u r r e n t r a d i o s t a t i o n .
1 4 . D i a l f o r s e l e c t i o n a n d O K c o n fi r m a t i o n :
Selection of an item on the screen or in a l i s t i n a m e n u , t h e n c o n fi r m a t i o n w i t h a s h o r t press.
Other than for menus and lists, a short press d i s p l a y s a c o n t e x t u a l m e n u d e p e n d i n g o n t h e current screen.
Rotation with map displayed: zoom the map scale in and out.
FIRST STEPS
