FAMILIARISATION
INTERIOR
Interior mood lighting
This subdued passenger compart-
ment lighting improves visibility inside
the vehicle in low lighting conditions. It
comprises 4 lamps, located in the au-
tomatic day/night mirror support, in the
footwells and in the lower dashboard
storage compartment.
81
G e a r e f fi c i e n c y i n d i c a t o r
Associated with the manual gearbox,
this system suggests when to change
up to obtain optimum fuel consumption.
106
Scented air freshener
The scented air freshener diffuses the
selected fragrance throughout the pas-
senger compartment from its location in
the ventilation system.
54
Digital air conditioning
After setting the desired level of com-
fort, the system then automatically con-
trols this level according to the ambient
conditions.
51
Audio and communication systems
T h e s e s y s t e m s b e n e fi t f r o m t h e l a t e s t
technology: MP3 compatible Audio sys-
tem, USB port, Bluetooth hands-free
system, MyWay with 16/9 colour screen,
auxiliary inputs, Hi-Fi audio system.
MyWay
171
Audio system
203
Page 6 of 240
FAMILIARISATION
INSTRUMENTS AND CONTROLS
1. S t e e r i n g w h e e l a d j u s t m e n t c o n t r o l .
2. H e a d l a m p h e i g h t a d j u s t m e n t .
3. Cruise control/speed limiter
switches.
4. Lighting and direction indicator
control stalk.
5. Microphone.
6. Central locking button.
7. Multifunction screen.
8. Hazard warning lamps switch.
9. C e n t r a l a d j u s t a b l e a i r v e n t s .
10. Sunshine sensor.
Hi-Fi audio system central speaker.
11. Passenger’s airbag.
12. Glove box/Passenger’s airbag
deactivation/Fusebox.
13. Bonnet release lever.
14. 12 V accessory socket.
USB port/auxiliary socket.
15. Upper and lower storage.
16. MyWay or Audio system.
17. Heating/air conditioning controls.
Page 93 of 240
6
FITTINGS
SUN VISOR
Component which protects against sun-
light from the front or the side.
Version without Zenith windscreen
GLOVE BOX
To open the glove box, raise the
handle.
It houses the front passenger airbag de-
activation switch A .
It gives access to the dashboard fuse-
box (see the "Practical information - §
Changing a fuse" section).
CENTRE ARMREST
Comfort and storage system for the
driver and front passenger.
Storage
For access to the closed storage
box, lift the lever to open the lid.
For access to the open storage box
below the armrest, lift the complete
armrest towards the rear.
These can be used for portable devices
(mobile phone, MP3 player...) which can
be connected to the USB port/auxiliary
socket or charged from the 12 V socket
in the centre console.
Version with Zenith windscreen
Refer to the "Familiarisation - § Zenith
windscreen" section.
T h e s u n v i s o r s a r e fi t t e d w i t h a c o u r t e s y
m i r r o r , w i t h c o n c e a l i n g fl a p f o r t h e d r i v e r
and a ticket/card holder.
Page 96 of 240
6
FITTINGS
SUN VISOR
Component which protects against sun-
light from the front or the side.
Version without Zenith windscreen
GLOVE BOX
To open the glove box, raise the
handle.
It houses the front passenger airbag de-
activation switch A .
It gives access to the dashboard fuse-
box (see the "Practical information - §
Changing a fuse" section).
CENTRE ARMREST
Comfort and storage system for the
driver and front passenger.
Storage
For access to the closed storage
box, lift the lever to open the lid.
For access to the open storage box
below the armrest, lift the complete
armrest towards the rear.
These can be used for portable devices
(mobile phone, MP3 player...) which can
be connected to the USB port/auxiliary
socket or charged from the 12 V socket
in the centre console.
Version with Zenith windscreen
Refer to the "Familiarisation - § Zenith
windscreen" section.
T h e s u n v i s o r s a r e fi t t e d w i t h a c o u r t e s y
m i r r o r , w i t h c o n c e a l i n g fl a p f o r t h e d r i v e r
and a ticket/card holder.
Page 138 of 240
1 0
CHECKS
PETROL ENGINES
1. S c r e e n w a s h fl u i d r e s e r v o i r .
