I
20
INSTRUMENT PANEL WARNING LAMPS
Warning lamp is on Cause Actions/
Observations
Left-hand direction
indicator Flashing
with
audible
warning T h i s fl a s h e s w h e n y o u
press the lighting stalk
down. I f t h i s i n d i c a t o r l a m p fl a s h e s a b n o r m a l l y q u i c k l y ,
this could indicate that the bulb of one of the
direction indicators has blown. Change the bulb
or contact a CITROËN dealer.
Right-hand direction
indicator Flashing
with
audible
warning T h i s fl a s h e s w h e n y o u
push the lighting stalk up. I f t h i s i n d i c a t o r l a m p fl a s h e s a b n o r m a l l y q u i c k l y ,
this could indicate that the bulb of one of the
direction indicators has blown. Change the bulb
or contact a CITROËN dealer.
Main beam headlamps Fixed This comes on when
you pull the lighting stalk
towards you. Pull the stalk to return to dipped beam
headlamps.
Sidelamps Fixed This comes on when the
lighting stalk is in the
"Sidelamps" or "Dipped
beam headlamps"
position. Turn the stalk to the desired position.
Front foglamps Fixed This comes on when you
use the front foglamps. Turn the ring on the stalk forwards to switch on
the foglamps.
Rear foglamps Fixed This comes on when you
use the rear foglamps. Turn the ring on the stalk forwards to switch on
the foglamps.
Cruise control Fixed This comes on when the
mode is active. Press the "ON/OFF" button to activate/
deactivate the mode.
Page 8 of 217
I
M O N I T O R I N G
26
Message is on Cause Solution - action Observations
Dynamic stability control
system (ASC) Fixed
Dynamic stability control system
(ASC) fault. Consult a CITROËN
dealer.
Four wheel
drive system Fixed Four wheel drive transmission
system fault. Consult a CITROËN
dealer.
Four wheel
drive system temperature Fixed The temperature of the four
wheel drive transmission
system is too high. Stop the vehicle and
contact a CITROËN
dealer. The vehicle switches
to front wheel
drive (2 WD) mode
automatically.
Automatic headlamp
adjustment system Fixed
The automatic headlamp
adjustment is faulty. Consult a CITROËN
dealer. O n l y o n v e h i c l e fi t t e d
with xenon bulbs.
Battery charge Fixed Battery charge fault. Stop the vehicle and
contact a CITROËN
dealer.
Ambient
temperature Fixed The ambient temperature is
3 °C (37 °F) or below. Road icy.
Take care and drive
slowly. Caution: The road
may be icy even
when this screen is
not displayed.
Page 78 of 217
IV
V I S I B I L I T Y
84
LIGHTING STALK
Additional lighting
O t h e r l a m p s a r e i n s t a l l e d t o f u l fi l t h e r e -
q u i r e m e n t s o f p a r t i c u l a r d r i v i n g c o n d i -
tions:
- r e a r f o g l a m p s t o b e s e e n f r o m a d i s -tance,
- f r o n t f o g l a m p s f o r e v e n b e t t e r v i s - i b i l i t y ,
- d a y t i m e r u n n i n g l a m p s t o b e s e e n d u r i n g t h e d a y . Certain functions of the lighting stalk
(automatic illumination of headlamps,
s e n s i t i v i t y ) c a n b e c o n fi g u r e d v i a t h e
c o l o u r s c r e e n " E q u i p m e n t " m e n u .
Manual controls
T h e l i g h t i n g c o m m a n d s a r e i s s u e d d i r e c t l y
b y t h e d r i v e r b y m e a n s o f t h e r i n g
A and
the stalk B . L a m p s o f f .
Automatic illumination of
h e a d l a m p s .
S i d e l a m p s o n l y .
B. Stalk for switching headlamps: pull
t o s w i t c h t h e l i g h t i n g b e t w e e n d i p p e d
h e a d l a m p s / m a i n b e a m h e a d l a m p s .
In the lamps off and sidelamps modes,
t h e d r i v e r c a n s w i t c h o n t h e m a i n b e a m
h e a d l a m p s t e m p o r a r i l y ( " h e a d l a m p
fl a s h " ) b y m a i n t a i n i n g a p u l l o n t h e
s t a l k .
Displays
Lighting of the corresponding indicator
l a m p o n t h e i n s t r u m e n t p a n e l c o n fi r m s
t h e s w i t c h i n g o n o f t h e l i g h t i n g s e l e c t e d .
A. Main lighting mode selection ring:
t u r n i t t o p o s i t i o n t h e s y m b o l r e -
q u i r e d f a c i n g t h e m a r k .
Dipped headlamps or main
b e a m h e a d l a m p s .
Main lighting
The various front and rear lamps of the
v e h i c l e a r e d e s i g n e d t o a d a p t t h e d r i v -
e r ' s v i s i b i l i t y p r o g r e s s i v e l y i n r e l a t i o n t o
the climatic conditions:
- s i d e l a m p s , t o b e s e e n ,
- d i p p e d b e a m h e a d l a m p s t o s e e without dazzling other drivers,
- m a i n b e a m h e a d l a m p s t o s e e c l e a r l y w h e n t h e r o a d i s c l e a r .
Page 79 of 217
IV
!
V I S I B I L I T Y
85
Front and rear foglamps
C. f o g l a m p s s e l e c t i o n r i n g .
The foglamps operate with the dipped
a n d m a i n b e a m h e a d l a m p s . front and rear fog lamps
To switch on the front fog lamps,
turn the push ring C forwards one
n o t c h .
To switch on the rear fog lamps, turn
the push ring C f o r w a r d s t w o n o t c h e s .
To switch off the front fog lamps,
turn the push ring C rearwards one
n o t c h .
To switch off the rear fog lamps,
turn the push ring C rearwards
t w o n o t c h e s .
The ring C returns to its initial position
a u t o m a t i c a l l y .
T h e f r o n t f o g l a m p s a r e s w i t c h e d o n a u -
t o m a t i c a l l y w h e n y o u s w i t c h o n t h e r e a r
f o g l a m p s .
The rear fog lamps are switched off
a u t o m a t i c a l l y w h e n y o u s w i t c h o f f t h e
d i p p e d / m a i n b e a m h e a d l a m p s o r t h e
f r o n t f o g l a m p s .
O n v e h i c l e s fi t t e d w i t h d a y t i m e l i g h t s ,
t h e r e a r f o g l a m p s c a n b e s w i t c h e d o n
even if the lights stalk is in the "OFF"
p o s i t i o n . I n g o o d o r r a i n y w e a t h e r , b o t h
d a y a n d n i g h t , t h e f r o n t f o -
glamps and the rear foglamps
a r e p r o h i b i t e d . I n t h e s e s i t u a t i o n s ,
t h e p o w e r o f t h e i r b e a m s m a y d a z z l e
o t h e r d r i v e r s .
D o n o t f o r g e t t o s w i t c h o f f t h e f r o n t f o -
glamps and the rear foglamps when
t h e y a r e n o l o n g e r n e c e s s a r y .
Lighting on reminder
A n a u d i b l e s i g n a l w h e n t h e d r i v e r ' s
door is opened warns the driver if the
vehicle lighting is on, with the ignition
o f f .
Switching off the lighting stops the
a u d i b l e s i g n a l .
If condensation is present, switch the
headlamps on for a few minutes in
o r d e r t o c l e a r i t .
Page 80 of 217
IV
!
V I S I B I L I T Y
86
Automatic illumination of headlamps Daytime running lamps *
* A c c o r d i n g t o c o u n t r y .
Automatic switching off
W h e n t h e l i g h t s s t a l k i s a t " d i p p e d h e a d -
l a m p s o r m a i n b e a m h e a d l a m p s " , i f t h e
ignition switch is at "LOCK" or "ACC" or
i f t h e k e y h a s b e e n r e m o v e d f r o m t h e
i g n i t i o n s w i t c h , t h e l i g h t s s w i t c h o f f a u t o -
m a t i c a l l y when the driver's door is
opened . O n v e h i c l e s w h i c h a r e e q u i p p e d w i t h d a y -
t i m e r u n n i n g l a m p s , t h e d i p p e d b e a m h e a d -
l a m p s c o m e o n w h e n t h e v e h i c l e i s s t a r t e d .
This warning lamp comes on
i n t h e i n s t r u m e n t p a n e l .
T h e i n s t r u m e n t s a n d c o n t r o l s ( i n s t r u -
ment panel, multifunction screen, air
c o n d i t i o n i n g c o n t r o l p a n e l , . . . ) a r e i l l u -
m i n a t e d . T h e s i d e l a m p s a n d t h e d i p p e d b e a m
h e a d l a m p s c o m e o n a u t o m a t i c a l l y , w i t h -
o u t a n y a c t i o n o n t h e p a r t o f t h e d r i v e r ,
if a low level of exterior light is detected
o r i f t h e w i p e r s a r e s w i t c h e d o n .
W h e n t h e l i g h t r e t u r n s t o a s u f fi c i e n t
level or the wipers are switched off, the
l i g h t i n g i s s w i t c h e d o f f a u t o m a t i c a l l y .
T h e s e n s o r i s l o c a t e d a t t h e b a s e o f t h e
w i n d s c r e e n .
Contact a CITROËN dealer to adjust
t h e s e n s i t i v i t y o f t h e s e n s o r .
I n f o g g y w e a t h e r o r i n s n o w , t h e
s u n s h i n e s e n s o r m a y d e t e c t s u f -
fi c i e n t l i g h t . T h e l i g h t i n g w i l l n o t
c o m e o n a u t o m a t i c a l l y .
Do not cover the sunshine sensor, the
a s s o c i a t e d f u n c t i o n s w i l l n o l o n g e r b e
c o n t r o l l e d .
T h e s e n s i t i v i t y o f t h e a u t o m a t i c i l -
l u m i n a t i o n o f h e a d l a m p s c a n b e
c o n fi g u r e d v i a t h e c o l o u r s c r e e n
" E q u i p m e n t " m e n u .
Page 81 of 217
IV
!
V I S I B I L I T Y
86
Automatic illumination of headlamps Daytime running lamps *
* A c c o r d i n g t o c o u n t r y .
Automatic switching off
W h e n t h e l i g h t s s t a l k i s a t " d i p p e d h e a d -
l a m p s o r m a i n b e a m h e a d l a m p s " , i f t h e
ignition switch is at "LOCK" or "ACC" or
i f t h e k e y h a s b e e n r e m o v e d f r o m t h e
i g n i t i o n s w i t c h , t h e l i g h t s s w i t c h o f f a u t o -
m a t i c a l l y when the driver's door is
opened . O n v e h i c l e s w h i c h a r e e q u i p p e d w i t h d a y -
t i m e r u n n i n g l a m p s , t h e d i p p e d b e a m h e a d -
l a m p s c o m e o n w h e n t h e v e h i c l e i s s t a r t e d .
This warning lamp comes on
i n t h e i n s t r u m e n t p a n e l .
T h e i n s t r u m e n t s a n d c o n t r o l s ( i n s t r u -
ment panel, multifunction screen, air
c o n d i t i o n i n g c o n t r o l p a n e l , . . . ) a r e i l l u -
m i n a t e d . T h e s i d e l a m p s a n d t h e d i p p e d b e a m
h e a d l a m p s c o m e o n a u t o m a t i c a l l y , w i t h -
o u t a n y a c t i o n o n t h e p a r t o f t h e d r i v e r ,
if a low level of exterior light is detected
o r i f t h e w i p e r s a r e s w i t c h e d o n .
W h e n t h e l i g h t r e t u r n s t o a s u f fi c i e n t
level or the wipers are switched off, the
l i g h t i n g i s s w i t c h e d o f f a u t o m a t i c a l l y .
T h e s e n s o r i s l o c a t e d a t t h e b a s e o f t h e
w i n d s c r e e n .
Contact a CITROËN dealer to adjust
t h e s e n s i t i v i t y o f t h e s e n s o r .
I n f o g g y w e a t h e r o r i n s n o w , t h e
s u n s h i n e s e n s o r m a y d e t e c t s u f -
fi c i e n t l i g h t . T h e l i g h t i n g w i l l n o t
c o m e o n a u t o m a t i c a l l y .
Do not cover the sunshine sensor, the
a s s o c i a t e d f u n c t i o n s w i l l n o l o n g e r b e
c o n t r o l l e d .
T h e s e n s i t i v i t y o f t h e a u t o m a t i c i l -
l u m i n a t i o n o f h e a d l a m p s c a n b e
c o n fi g u r e d v i a t h e c o l o u r s c r e e n
" E q u i p m e n t " m e n u .
Page 82 of 217
IV
V I S I B I L I T Y
87
MANUAL HEADLAMP
ADJUSTMENT
To avoid dazzling other road users,
t h e h e i g h t o f t h e h e a d l a m p s m u s t b e
adjusted in relation to the load in the
v e h i c l e .
AUTOMATIC HEADLAMP
ADJUSTMENT
O n v e h i c l e s w i t h x e n o n b u l b s : when
stationary , t h e s y s t e m a u t o m a t i c a l l y
c o r r e c t s t h e h e i g h t o f t h e b e a m , w h a t -
e v e r t h e l o a d o f t h e v e h i c l e . T h e d r i v -
er is then assured of having optimum
lighting and not causing a nuisance to
o t h e r r o a d u s e r s .
In cases of malfunction ,
this message appears on
t h e m u l t i f u n c t i o n s c r e e n .
7-seat version
0. D r i v e r o n l y o r D r i v e r + 1 p a s s e n g e r
i n t h e f r o n t .
1 or 2. D r i v e r + 1 p a s s e n g e r i n t h e f r o n t
+ 2 p a s s e n g e r s o n t h e t h i r d
b e n c h s e a t .
3. 7 occupants (including the driver
with or without maximum authorised
l o a d ) .
4. D r i v e r + m a x i m u m a u t h o r i s e d l o a d .
5-seat version
0. D r i v e r o n l y o r D r i v e r + 1 p a s s e n g e r
i n t h e f r o n t .
1 or 2. 5 o c c u p a n t s ( i n c l u d i n g t h e d r i v e r ) .
3.
5 o c c u p a n t s ( i n c l u d i n g t h e d r i v e r ) +
m a x i m u m a u t h o r i s e d l o a d .
4.
D r i v e r + m a x i m u m a u t h o r i s e d l o a d .
D o n o t t o u c h t h e x e n o n b u l b s . C o n s u l t
a C I T R O Ë N d e a l e r .
Page 119 of 217
VIII
124
PETROL ENGINE
1. Screenwash and headlamp wash reservoir.
2. Coolant reservoir.
3 . P o w e r s t e e r i n g fl u i d r e s e r v o i r .
4 . B r a k e fl u i d r e s e r v o i r .
5. Fusebox.
6. Battery.
7. CVT gearbox dipstick.
8. Radiator cap.
9. Engine oil dipstick.
1 0 . E n g i n e o i l fi l l e r c a p .
1 1 . A i r fi l t e r .
A c c e s s f o r c h e c k i n g t h e l e v e l s o f t h e v a r i o u s fl u i d s a n d t h e r e p l a
c e m e n t o f c e r t a i n c o m p o n e n t s .
