01 SafetyChild safety
0133
WARNING
•
Do not use child safety seats or child
booster cushions/backrests in the front
passenger's seat. We also recommend
that children under 4 feet 7 inches
(140 cm) in height who have outgrown
these devices sit in the rear seat with the
seat belt fastened.
•
Keep vehicle doors and trunk locked
and keep keys out of a child's reach.
Unsupervised children could lock them-
selves in an open trunk and risk injury.
Children should be taught not to play in
vehicles.
•
On hot days, the temperature in the
vehicle interior can rise very quickly.
Exposure to these high temperatures for
even a short period of time can cause heat-
related injury or death. Small children are
particularly at risk.
Automatic Locking Retractor/
Emergency Locking Retractor (ALR/
ELR)To make child seat installation easier, each
seat belt (except for the driver's belt) is equip-
ped with a locking mechanism to help keep the
seat belt taut.
When attaching the seat belt to a child seat:1. Attach the seat belt to the child seat
according to the child seat manufacturer's
instructions.
2. Pull the seat belt out as far as possible.
3. Insert the seat belt latch plate into the
buckle (lock) in the usual way.
4. Release the seat belt and pull it taut around
the child seat. A sound from the seat belt
retractor will be audible at this time and
is normal.
The belt will now be locked in place.
This function is automatically disabled when
the seat belt is unlocked and the belt is fully
retracted.
WARNING
Do not use child safety seats or child
booster cushions/backrests in the front
passenger's seat. We also recommend that
children who have outgrown these devices
sit in the rear seat with the seat belt properly
fastened.Volvo's recommendationsWhy does Volvo believe that no child should sit
in the front seat of a vehicle? It's quite simple
really. A front airbag is a very powerful device
designed, by law, to help protect an adult.Because of the size of the airbag and its speed
of inflation, a child should never be placed in
the front seat, even if he or she is properly bel-
ted or strapped into a child safety seat. Volvo
has been an innovator in safety for over sev-
enty-five years, and we'll continue to do our
part. But we need your help. Please remember
to put your children in the back seat, and
buckle them up.
Volvo has some very specific
recommendations:•
Always wear your seat belt.
•
Airbags are a SUPPLEMENTAL safety
device which, when used with a three-
point seat belt can help reduce serious
injuries during certain types of accidents.
Volvo recommends that you do not dis-
connect the airbag system in your vehicle.
•
Volvo strongly recommends that everyone
in the vehicle be properly restrained.
•
Volvo recommends that ALL occupants
(adults and children) shorter than 4 feet
7 inches (140 cm) be seated in the back
seat of any vehicle with a front passenger
side airbag.
Drive safely!

06 Starting and drivingHandling and road holding
06128
Weight distribution affects handlingAt the specified curb weight your vehicle has a
tendency to understeer, which means that the
steering wheel has to be turned more than
might seem appropriate for the curvature of a
bend.
This ensures good stability and reduces the
risk of rear wheel skid. Remember that these
properties can alter with the vehicle load.
The heavier the load in the trunk (max. 220 lbs,
100 kg), the less the tendency to understeer.Handling, roadholdingVehicle load, tire design and inflation pressure
all affect vehicle handling. Therefore, check
that the tires are inflated to the recommended
pressure according to the vehicle load. See
"Tire pressure" section.
Loads should be distributed so that capacity
weight or maximum permissible axle loads are
not exceeded.
Speed-sensitive power steering
(Option on certain models)With this feature, the steering is most respon-
sive at lower speeds to make parking, driving
in city traffic, etc., easier. The effect of the
power steering diminishes as you accelerate
for greater stability at highway speeds.Driving through waterThe vehicle can be driven through water up to
a depth of approximately 9 in. (25 cm), at a
maximum speed of 6 mph (10 km/h).
Take particular care when driving through flow-
ing water.
Clean the electrical connections for trailer wir-
ing after driving in mud or water.
When driving through water, maintain low
speed and do not stop in the water.
WARNING
After driving through water, press lightly on
the brake pedal to ensure that the brakes
are functioning normally. Water or mud can
make the brake linings slippery, resulting in
delayed braking effect.
CAUTION
•
Engine damage will occur if water is
drawn into the air cleaner.
•
If the vehicle is driven through water
deeper than 9 in (25 cm), water may
enter the differential and the transmis-
sion. This reduces the oil's lubricating
capacity and may shorten the service
life of these components.
•
Do not allow the vehicle to stand in
water up to the door sills longer than
absolutely necessary. This could result
in electrical malfunctions.
•
If the engine has been stopped while the
car is in water, do not attempt to restart
the engine. Have the car towed out of
the water.

06 Starting and drivingTowing
06140
Emergency towing
ABC
G028091
Front towing eyeletThe towing eyelet is located in the tool bag,
under the floor of the trunk, with the spare tire.
This eyelet must be screwed into the positions
provided on the right sides of either the front or
rear bumper (B, see illustrations).
WARNING
Do not use the towing eyelets to pull the
vehicle up onto a flat bed tow truck.
To attach the towing eyelet:A. Use a coin to pry open the lower edge of
the cover (A)
1.
B. Screw the towing eyelet (C) in place, first
by hand and then using the tire iron until it
is securely in place.
After the vehicle has been towed, the eyelet
should be removed and returned to the tool
bag. Press the cover back into position.A
B
C
G028093
Rear towing eyelet
Precautions when the vehicle is in tow•
The steering wheel must be unlocked. Turn
the ignition key to position I or II.
•
The gear selector must be in position N.
•
Maximum speed: 50 mph (80 km/h). Do not
exceed the maximum allowable towing
speed.
•
Maximum distance with front wheels on
ground: 50 miles (80 km).
•
While the vehicle is being towed, try to
keep the tow rope taut at all times.
•
The vehicle should only be towed in for-
ward direction.
1The opening in the cover may vary.

06 Starting and driving
Towing
06
141
CAUTION
•
Please check with state and local
authorities before attempting this type
of towing, as vehicles being towed are
subject to regulations regarding maxi-
mum towing speed, length and type of
towing device, lighting, etc.
•
If the vehicle's battery is dead, do not
attempt to start the vehicle by pushing
or pulling it as this will damage the
three-way catalytic converter(s). The
engine must be jump started using an
auxiliary battery (see page 142).
•
If the vehicle is being towed on a flat bed
truck, the towing eyelets must not be
used to secure the vehicle on the flat
bed. Consult the tow truck operator.
WARNING
•
Remember that the power brakes and
power steering will not function when
engine is not running. The braking and
steering systems will function but the
brake pedal pressure required is
3 – 4 times above normal and greater
steering effort must be exerted.
•
The towing eyelets must not be used for
pulling another vehicle out of a ditch or
for any similar purpose involving severe
strain.
•
Do not use the towing eyelets to pull the
vehicle up onto a flat bed tow truck.
Towing vehicles with front wheel drive/
All Wheel DriveVolvo recommends the use of flat bed equip-
ment.
If wheel lift equipment must be used, please
use extreme caution to help avoid damage to
the vehicle. In this case, the vehicle should
be towed with the rear wheels on the ground
if at all possible.
If it is absolutely necessary to tow the vehicle
with the front wheels on the ground, please
refer to the towing information on the previous
page.
CAUTION
•
Sling-type equipment applied at the
front will damage radiator and air con-
ditioning lines.
•
It is equally important not to use sling-
type equipment at the rear or apply lift-
ing equipment inside the rear wheels;
serious damage to the rear axle may
result.
•
If the vehicle is being towed on a flat bed
truck, the towing eyelets must not be
used to secure the vehicle on the flat
bed. Consult the tow truck operator.WARNING
Do not use the towing eyelets to pull the
vehicle up onto a flat bed tow truck.

07 Wheels and tires
Changing wheels
07``169
G020331
Insert flat end of lug wrench and turn/pull straight
outThe spare wheel is located under the carpet on
the trunk floor. The jack and crank are secured
in the wheel recess.
There are two jack attachment points on each
side of the vehicle (see illustration below).To change a wheel:1. Engage the parking brake.
2.
Put the gear selector in P (automatic trans-
mission) or reverse (manual transmission).
G020332
Loosen the wheel bolts3. Remove the wheel cap (where applicable)
using the lug wrench in the tool bag.
4. With the vehicle still on the ground, use the
lug wrench to loosen the wheel bolts 1/2 -
1 turn by exerting downward pressure.
Turn the bolts counterclockwise to loosen.
CAUTION
•
The vehicle must not be driven with
wheels of different dimensions or with a
spare tire other than the one that came
with the vehicle. The use of different size
wheels can seriously damage your vehi-
cle's transmission.
•
Correct tightening torque on wheel
bolts must be observed. The wheel
bolts should never be greased or lubri-
cated. The extended, chromed wheel
bolts must not be used with steel rims,
as they make it impossible to fit the hub
caps.
•
Locking wheel bolts can be used on
both aluminum and steel wheels. If hub
caps are used on steel wheels, the lock-
ing wheel bolt should be mounted in the
hole as far from the tire's inflation valve
as possible. It would otherwise not be
possible to mount the hub cap on the
wheel.

12 Index
12
251
Roof racks (load carriers)......................... 146
Rotating tires........................................... 168SSafety defects, reporting
Canada................................................. 17
USA....................................................... 16
Seat belt..................................................... 18
Service.....................................................184
Service key.............................................. 108
Shiftlock...................................................124
Side impact protection (SIPS) airbags....... 28
Ski hatch.................................................. 103
Snow chains............................................ 166
Snow tires................................................ 166
Spare wheel............................................. 105
Stability systems...................................... 138
Starting the car........................................ 124
Steering wheel lock.................................125
Stone chips, touching up......................... 180
Storage compartments..............99, 100, 101
Studded tires........................................... 166Suspension.............................................. 246
TTemperature control.................................. 89
Three-way catalytic converter................. 245
Tire designations.....................................160
Tire economy, improving......................... 155
Tire inflation............................................. 156
Tire inflation pressure, checking.............. 157
Tire inflation pressure table
Canadian models................................ 159
US models.......................................... 158
Tire Pressure Monitoring System............ 172
Tires
rotation............................................... 168
Towing - cars with All Wheel Drive.......... 141
Towing the car......................................... 140
Trailer hitch - detachable......................... 145
Transmission - automatic........................130
Tread wear indicator................................ 155
Trunk
opening from the inside...................... 113
unlocking/locking................................ 112
UUniform Tire Quality Grading................... 165
Unlocking the car..................................... 112
Unlocking the trunk.................................. 112
Upholstery, cleaning................................ 177VValet key.................................................. 108
Vanity mirror............................................... 98
Vehicle dimensions.................................. 236
Vehicle Event Data................................... 184
Vehicle Identification Number (VIN)......... 235
Vehicle loading......................................... 163
Volvo Inflatable Curtain.............................. 29
Volvo On Call Roadside Assistance........ 247WWarranties................................................ 184
Washer fluid reservoir......................189, 192
Washing the car....................................... 176
