2009 TOYOTA YARIS HATCHBACK clock

222 3-5. Other interior features
nThe clock is displayed when
The engine switch is in the ON position.
n When disconnecting and reco nnecting battery termi
nals
The time display will automatically be set to 1:00.
n Adjusting to a full hour (vehic
les without tachometer)
If you press the clock reset button, the minute values will be rounded to the
neares
t hour. So, minute values from “:00” to “:29” are rounded down, and
values from “:30” to “:59” are rounded up.*
*: e.g.
1:00 to 1:29 → 1:0
0
1:30 to 1:59 → 2:0
0
Vehicles without tachometer
Press and hold the clock reset button to enter the adjust-
ment mode for the clock.
Press the clock reset button to adjust the minutes.
After adjusting the minutes, wait 5 seconds to allow the minutes to
be automatically input.
Press the clock reset button to adjust the hours.
After adjusting the hours, wait 5 seconds to allow the hours to be
automatically input and then return to normal mode.

247
4-3. Do-it-yourself maintenance
4
Maintenance and care
n
Adding engine oil
If the oil level is below or near
the
low level mark, add engine
oil of the same type as already in
the engine.
Make sure to check the oil type a
nd prepare the items needed before
adding oil.
Remove the oil filler cap, turning it counterclockwise.
Add engine oil slowly.
Checking the dipstick.
Reinstall the filler cap, turning it clockwise.
The approximate quantity of oil needed to raise the level between low and
full on the dipstick is indicated as follows:
1.6 qt. (1.5 L, 1.3 lmp. qt.)
Oil grade ILSAC multigrade engine oil
ItemsClean funnel

289
4-3. Do-it-yourself maintenance
4
Maintenance and care
Unplug the connector while
depressing the lock release.
Turn the bulb counterclockwise.
n Front sid
e marker lights
Turn the bulb base counterclock -
wise.
Remove the light bulb.

290 4-3. Do-it-yourself maintenance
nFront turn signal lights
Turn the bulb base counterclock-
wise.
Remove the light bulb.
n Parking ligh
ts
Turn the bulb base counterclock -
wise.

291
4-3. Do-it-yourself maintenance
4
Maintenance and care
Remove the light bulb.
n Ba
ck-up lights, stop/tail and rear side marker lights and rear
turn signal lights
Open the back door and remove
the cover
.
Use a flathead screwdriver which
is wrapped with a cloth.
Turn the bulb base counterclock -
wise.
Stop/tail and rear side marker
lights
Rear turn signal light
Back-up light
Remove the light bulb. Stop/tail and rear side marker
lights
Rear turn signal light
Back-up light

292 4-3. Do-it-yourself maintenance
nLicense plate light
Disengage the claws and
re
move the license plate light.
Use a flathead screwdriver which
is wrapped with a cloth.
Turn the bulb base counterclock -
wise.
Remove the light bulb.
n Light
s other than the above
If any of the lights listed below h
as burnt out, have it replaced by
your Toyota dealer.
• Side turn signal lights
• High mounted stoplight

382 Alphabetical index
Child restraint systemBooster seats, definition .......... 98
Booster seats, installation ..... 102
Convertible seats, definition .... 98
Convertible seats,
installation ........................... 102
Front passenger occupant classification system .............93
Infant seat, definition ............... 98
Infant seats, installation......... 102
Installing CRS with LATCH
system ................................ 104
Installing CRS with seat
belts .................................... 105
Installing CRS with top
tether straps ........................ 109
Child safety
Airbag precautions .................. 88
Battery precautions ....... 255, 336
Child restraint system
.............. 98
Child-protectors ....................... 34
How your child should wear
the seat belt ..........................58
Installing child restraints ........ 102
Power window lock switch....... 68
Power window precautions ..... 69
Removed key battery
precautions ......................... 274
Seat belt extender
precautions ...........................61
Seat belt precautions .............. 59
Child-protectors ......................... 34
Cleaning Exterior .................................. 228
Interior ................................... 230
Seat belts .............................. 231
Clock ......................... 135, 137 , 221
Clutch
Fluid ...................................... 350
Pedal .............................. 116,130
Comfort guide ............................ 55
Condenser ................................ 252
CRS ............................................. 98Cruise control
Cruise control ........................ 152
Indicator ................................ 152
Cup holders .............................. 214
Curtain shield airbags ............... 81
Customizable features ............ 369
Daytime running light
system .................................... 146
Defogger
Rear window ......................... 185
Side mirrors........................... 185
Dimension ................................ 344
Do-it-yourself maintenance .... 239
Doors Back door ................................ 36
Door glasses ........................... 67
Door lock ................................. 31
Side doors ............................... 31
Side mirrors............................. 64
Warning light ......................... 310
Driver's seat belt reminder
light ......................................... 310
Driving Break-in tips .......................... 118
Correct posture ....................... 79
Procedures............................ 116
Winter driving tips ................. 161
Electric power steering Electric power steering.......... 155
Warning light .........................
308
Emergency flashers
Switch ................................... 296
Emergency, in case of If the engine will not start ...... 329
If the shift lever cannot be
shifted from P ..................... 331
If the vehicle battery is
discharged .......................... 333
If the warning buzzer
sounds ................................ 307
D
E

1
2
3
4
5
6
7
3
2-4. Using other driving
systems
Cruise control ...................... 152
Driving assist systems ........ 155
2-5. Driving information Cargo and luggage ............. 157
Vehicle load limits ............... 160
Winter driving tips ............... 161
Trailer towing (except
Canada) ............................ 164
Trailer towing (Canada) ...... 165
Dinghy towing (vehicles with an automatic
transmission) .................... 173
Dinghy towing (vehicles with a manual
transmission) .................... 174
3-1. Using the air conditioning
system and defogger
Air conditioning system ....... 178
Rear window and outside
rear view mirror
defoggers .......................... 185
3-2. Using the audio system Audio system type............... 187
Using the radio .................... 189
Using the CD player ............ 195
Playing back MP3 and
WMA discs ........................ 200
Optimal use of the audio
system .............................. 207
Using the AUX adapter ....... 209 3-3. Using the interior lights
Interior lights list ................. 210
•Interior light ...................... 211
• Personal lights................... 211
3-4. Using the storage features List of storage features
....... 212
• Glove boxes ..................... 212
• Cup holders ...................... 214
• Bottle holders ................... 215
• Auxiliary boxes ................. 217
3-5. Other interior features
Sun visors........................... 219
Vanity mirrors ..................... 220
Clock .................................. 221
Power outlet ....................... 223
Floor mat ............................ 224
Luggage compartment features ............................ 225
4-1. Maintenance and care Cleaning and protecting
the vehicle exterior ........... 228
Cleaning and protecting
the vehicle interior ............ 230
4-2. Maintenance Maintenance
requirements .................... 233
General maintenance ......... 235
Emission inspection and
maintenance (I/M)
programs .......................... 238
3Interior features
4Maintenance and care
