2009 TOYOTA MATRIX turn signal bulb

117
2-1. Driving procedures
2
When driving
Turn signal lever
■Turn signals can be operated when
The engine switch is in the “ON” position.
■If the indicators flash faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned
out.
Left turn
Right turn
Move and hold the lever
partway to signal a lane
change.
The left hand signal will flash
until you release the lever.
Move and hold the lever
partway to signal a lane
change.
The right hand signal will flash
until you release the lever.

332
4-3. Do-it-yourself maintenance
Light bulbs
You may replace the following bulbs yourself. The difficulty level of
replacement varies depending on the bulb. If necessary bulb
replacement seems difficult to perform, contact your Toyota dealer.
For more information about replacing other light bulbs, contact your
Toyota dealer.
■Prepare a replacement light bulb.
Check the wattage of the light bulb being replaced. (→P. 404)
■Front bulb locations
Headlight high beam
Front turn signal/parking
and front side marker lights
Front fog lightsHeadlight low beam

333 4-3. Do-it-yourself maintenance
4
Maintenance and care
■Rear bulb locations
Stop/tail and rear
side marker lights Rear turn signal lights
Back-up lights
License plate lights

336 4-3. Do-it-yourself maintenance
Unplug the bulb while depress-
ing the lock release.
■Front turn signal/parking and front side marker lights
Turn the bulb base counterclock-
wise.
Remove the light bulb.STEP4
STEP1
STEP2

338 4-3. Do-it-yourself maintenance
Turn the bulb base counterclock-
wise.
Rear turn signal light
Back-up light
Stop/tail and rear side marker
light
Remove the light bulb.
Rear turn signal light
Back-up light
Stop/tail and rear side marker
lightSTEP3
STEP4

404 6-1. Specifications
Light bulbs
A: H11 halogen bulbs B: HB3 halogen bulbs
C: Wedge base bulbs (clear) D: Wedge base bulbs (amber)
E: Double end bulbs F: HB4 halogen bulbs
Light BulbsBulb No.WTy p e
ExteriorHeadlights
Low beam
High beam9006
900551
60F
B
Front turn signal/park-
ing and front side
marker lights3457NA 27/7 D
Front fog lights (if
equipped)⎯55 A
Rear turn signal lights⎯21 D
Stop/tail and rear side
marker lights 7443 21/5 C
License plate lights⎯5C
Back-up lights 921 16 C
InteriorPersonal lights⎯8C
Interior light⎯8E

432 Alphabetical index
Floor mat................................... 254
Fluid
Brake ..................................... 297
Washer .................................. 301
Fog lights
Replacing light bulbs ............. 332
Switch.................................... 128
Wattage ................................. 404
Front passenger occupant
classification system ..............77
Front passenger's seat belt
reminder light......................... 355
Front seats
Adjustment ..............................35
Front side marker lights
Replacing light bulbs ............. 332
Switch.................................... 125
Wattage ................................. 404
Front turn signal lights
Replacing light bulbs ............. 332
Switch.................................... 117
Wattage ................................. 404
Fuel
Capacity ................................ 394
Fuel gauge ............................ 119
Fuel pump shut off system .... 349
Gas station information ......... 440
Information ............................ 405
Refueling .................................56
Type ...................................... 394
Fuel door.....................................56
Fuel filler door ............................56
Fuel pump shut off system ..... 349
Fuses......................................... 323Gas station information .......... 440
Gauges...................................... 119
Glove box ................................. 237
Grocery bag hooks .................. 251
Hands-free phone system
(for cellular phone) ................ 200
Head restraints
Adjusting ................................ 40
Headlights
Replacing light bulbs ............. 332
Switch ................................... 125
Wattage................................. 404
Heaters
Side mirror ............................ 168
Hood.......................................... 283
Hooks
Cargo hooks.......................... 255
Grocery bag hooks................ 251FG
H

433 Alphabetical index
I/M test ...................................... 278
Identification number
Engine .................................. 391
Vehicle.................................. 391
Ignition switch ......................... 106
Illuminated entry system ........ 233
Indicator lights ........................ 122
Initialization
Items to initialize ................... 422
Inside rear view mirror.............. 47
Interior lights
Interior lights ......................... 232
Switch ................................... 233
Wattage ................................ 404
Jack
Positioning a floor jack ......... 285
Replacing the wheel ............. 362
Jack handle.............................. 362
Keyless entry ............................. 26
Keys
Engine switch ....................... 106
If you lose your keys............. 378
Ignition switch ....................... 106
Key number ............................ 24
Keyless entry .......................... 26
Keys ....................................... 24
Wireless remote control key ... 26License plate lights
Replacing light bulbs .............332
Switch....................................125
Wattage .................................404
Light bulbs
Replacing ..............................332
Wattage .................................404
Lights
Fog light switch .....................128
Headlights switch ..................125
Interior light switch ................233
Personal light switch .....234, 235
Replacing light bulbs .............332
Turn signal lever....................117
Wattage .................................404
Load capacity ...........................143
Lock steering column ..............108
Maintenance
Do-it-yourself
maintenance .......................279
General maintenance ............275
Maintenance data..................390
Maintenance requirements....273
Manual transmission
Manual transmission .............115
Meter
Instrument panel light
control .................................121
Meters ...................................119
Mirrors
Inside rear view mirror.............47
Side mirror heater .................168
Side mirrors .............................49
Vanity mirrors ........................245
Moon roof ...................................53
MP3 disc ...................................185I
J
K
L
M
